Potter LFH-24W LFH Series Low Frequency Audible Sounder, White
Image of 1
Key Features
- NFPA-compliant 520Hz low-frequency signaling for reliable sleeping-area alerts
- Super-Slide 4" mounting bracket and Checkmate voltage verification for faster, error-free installation and testing
- Jumper-selectable normal or loud output plus GTSM synchronization for flexible site-wide alarm coordination
- Low-profile, tamperproof design for clean wall or ceiling installation in security and monitoring deployments
- 33V DC operation with 84 dB output provides dependable audible performance for surveillance and life-safety systems
Quick Specifications
- Product Model
- LFH-24W
- Brand Name
- Potter Electric Signal, LLC
- Product Name
- LFH-24W Sounder
- Product Type
- Low Frequency Sounder
Explore the details
Product information
LFH-24W
Overview
Designed for life-safety and security applications, the Potter LFH-24W LFH Series low frequency audible sounder delivers NFPA-compliant 520Hz signaling specifically for sleeping areas. The Potter Electric Signal LFH-24W combines a low-profile, tamperproof form factor with contractor-friendly features — a universal 4" Super-Slide mounting bracket for fast pre-wiring and the Checkmate instant voltage verification to confirm voltage drop and current draw on site. The horn produces a 520Hz square-wave temporal 3 tone with a jumper-selectable normal or loud output and supports temporal 4 synchronization when used with the Potter GTSM module. With 33V DC input and an 84 dB emission, the LFH-24W is engineered for reliable audible performance in security, surveillance, and monitoring installations. Choose the LFH-24W to simplify installation, maintain code compliance, and reduce service calls. Contact sales or add to your project spec to ensure NFPA-compliant sleeping-area signaling on your next security or monitoring deployment.
Features
- NFPA-compliant 520Hz low-frequency signaling for reliable sleeping-area alerts
- Super-Slide 4" mounting bracket and Checkmate voltage verification for faster, error-free installation and testing
- Jumper-selectable normal or loud output plus GTSM synchronization for flexible site-wide alarm coordination
- Low-profile, tamperproof design for clean wall or ceiling installation in security and monitoring deployments
- 33V DC operation with 84 dB output provides dependable audible performance for surveillance and life-safety systems
| General Information | |
|---|---|
| Brand Name | Potter Electric Signal, LLC |
| Manufacturer | Potter Electric Signal, LLC |
| Product Name | LFH-24W Sounder |
| Product Type | Low Frequency Sounder |
| Product Model | LFH-24W |
| Product Series | LFH |
| Application/Usage | Signaling, Sleeping Area |
| Country of Origin | US |
| Manufacturer Part Number | LFH-24W |
| Technical Information | |
| Alarm Type | Audible |
| Connectivity Technology | Wired |
| Environmental Conditions | |
| Sound Emission | 84.0dB |
| Physical Characteristics | |
| Color | White |
| Depth | 1.60" |
| Width | 5.50" |
| Height | 6.10" |
| Durability | Tamperproof |
| Form Factor | Ceiling Mount, Wall Mount |
| Power Description | |
| Power Source | DC Power |
| Input Voltage | 33V DC |
| Product Information | |
| Mount Type | Ceiling Mount, Wall Mount |
| Warranty | |
| Limited Warranty | 5-Year |
| Miscellaneous | |
| Compatibility | Potter GTSM Synchronization Control Module |
