Luma LUM-121-NVR-8CH-0T 121 Series 8-Channel NVR, 8-PoE, 1-Bay
Image of 4
Key Features
- Simplifies installation and cabling with 8 PoE ports and a 120W PoE budget—power cameras directly from the NVR for faster deployments
- Delivers clear evidence-grade video with 4K output and 160 Mbps throughput to handle multiple high-resolution streams
- Scales recording retention with up to 18TB of expandable storage, so you can meet site-specific retention and compliance needs
- Built-in OvrC remote management and Luma View app provide real-time alerts, remote troubleshooting, and streamlined firmware updates
- NDAA-compliant and ONVIF-conformant for secure integration with Control4 and other third-party devices in commercial and residential systems
- Compact 1U rackmount design fits tight installations while offering enterprise-style monitoring and intelligent AI-filtered event detection
Quick Specifications
- Product Model
- LUM-121-NVR-8CH-0T
- Bandwidth
- 160Mbps
- Brand Name
- Luma
- Product Line
- X21
Frequently Bought Together
Luma LUM-121-NVR-8CH-0T 121 Series 8-Channel NVR, 8-PoE, 1-Bay
$641.34
5 items selected
Total: $2,047.70
Explore the details
Product information
LUM-121-NVR-8CH-0T
Overview
Designed for reliable small-site security and remote monitoring, the Luma LUM-121-NVR-8CH-0T (121 Series) 8-Channel NVR delivers the performance integrators need for residential and small business surveillance. This Luma network video recorder supports up to eight PoE cameras with a 120W power budget and handles up to 160 Mbps of throughput so multiple 4K streams record smoothly without dropping frames. Choose 0TB, 2TB, or 4TB factory configurations and expand storage up to 18TB to meet evidence retention and compliance requirements. Built-in OvrC integration and the Luma View app simplify deployments with remote management, push notifications, and AI-filtered event highlights—reducing truck rolls and speeding troubleshooting. Fully NDAA-compliant and ONVIF-conformant, the unit integrates with Control4 and common security ecosystems for centralized monitoring and automation. The compact 1U chassis fits rack or cabinet installs where space is tight. For contractors and IT teams seeking dependable, easy-to-manage surveillance, the Luma 121 Series NVR is a practical choice—specify it for secure, high-quality monitoring and contact sales to add it to your next project.
Features
- Simplifies installation and cabling with 8 PoE ports and a 120W PoE budget—power cameras directly from the NVR for faster deployments
- Delivers clear evidence-grade video with 4K output and 160 Mbps throughput to handle multiple high-resolution streams
- Scales recording retention with up to 18TB of expandable storage, so you can meet site-specific retention and compliance needs
- Built-in OvrC remote management and Luma View app provide real-time alerts, remote troubleshooting, and streamlined firmware updates
- NDAA-compliant and ONVIF-conformant for secure integration with Control4 and other third-party devices in commercial and residential systems
- Compact 1U rackmount design fits tight installations while offering enterprise-style monitoring and intelligent AI-filtered event detection
| General Information | |
|---|---|
| Bandwidth | 160Mbps |
| Brand Name | Luma |
| Product Line | X21 |
| Product Type | NVR |
| Product Series | 121 |
| Manufacturer Part Number | LUM-121-NVR-8CH-0T |
| Technical Information | |
| OvrC Enabled | Yes |
| Motion Detection | Yes |
| Power Consumption | 20.0000W |
| Maximum Frame Rate | 30fps |
| Number of Channels | 8 |
| Certifications | |
| Certifications & Standards | CE, ETL Listed, EU RoHS, FCC, REACH, WEEE |
| Environmental Conditions | |
| Operating Temperature (T-T) | 14-122°F |
| Interfaces/Ports | |
| Network (RJ-45) | Yes |
| Network & Communication | |
| Ethernet Technology | 1 Gbps (Gigabit Ethernet), 100 Mbps (Fast Ethernet) |
| Physical Characteristics | |
| Depth | 1.65" |
| Width | 17.24" |
| Height | 11.16" |
| Weight | 8.95lb |
| Power Description | |
| PoE Budget | 120W |
| Storage | |
| Hard Drive Capacity | No HDD |
| Number of Hard Drives | 1 |
| Video | |
| Maximum Resolution | 1280 x 1024 |
| Warranty | |
| Limited Warranty | 3-Year |
| Miscellaneous | |
| Compatibility | Control4 |
