Luma LUM-520-IP-DFB 520 Series 5MP Dome IP Outdoor Camera, 2.8mm Fixed Lens, Black
Key Features
- Deliver crisp 2K security footage with 5MP resolution for faster identification and improved monitoring accuracy
- Reliable nighttime detection with IR illumination that avoids over-exposure for clear low-light surveillance
- Rugged outdoor protection (IP67, IK10) to withstand weather and vandalism, reducing downtime and maintenance
- Remote setup and management via OvrC plus Control4 and ONVIF integration to simplify deployments and system control
- Built-in intelligent analytics and push alerts to reduce false notifications and surface critical events faster
Quick Specifications
- Product Model
- LUM-520-IP-DFB
- Brand Name
- Luma
- OvrC Enabled
- Yes
- Product Line
- X20
Frequently Bought Together
Luma LUM-520-IP-DFB 520 Series 5MP Dome IP Outdoor Camera, 2.8mm Fixed Lens, Black
$230.38
5 items selected
Total: $905.42
Product Information Tabs
Overview
Protect perimeters and monitor high-value areas with the Luma LUM-520 IP dome outdoor camera—designed to deliver dependable, high-detail video for commercial security and property surveillance. This Luma 520 Series dome camera captures 5MP (2K) images on a 2.8mm fixed lens to make license-plate, face and incident review faster and more actionable. IR night viewing provides even illumination in low-light scenes while WDR handles challenging contrast for consistent footage. Built-in analytics reduce false alarms and provide instant push notifications for focused monitoring, and the camera supports H.264/H.265 streaming to optimize bandwidth and recording costs. With IP67 weatherproofing and IK10 impact resistance the unit stands up to harsh outdoor environments and vandal attempts. IT-friendly features like OvrC remote configuration, ONVIF compatibility, Control4 integration and local microSD storage (up to 256GB) cut installation time and simplify ongoing management. Ideal for retail, campus, and critical infrastructure surveillance—deploy the Luma LUM-520 to upgrade your security monitoring and streamline operations. Contact your reseller or add to cart to start protecting your site today.
Features
- Deliver crisp 2K security footage with 5MP resolution for faster identification and improved monitoring accuracy
- Reliable nighttime detection with IR illumination that avoids over-exposure for clear low-light surveillance
- Rugged outdoor protection (IP67, IK10) to withstand weather and vandalism, reducing downtime and maintenance
- Remote setup and management via OvrC plus Control4 and ONVIF integration to simplify deployments and system control
- Built-in intelligent analytics and push alerts to reduce false notifications and surface critical events faster
| General Information | |
|---|---|
| Brand Name | Luma |
| OvrC Enabled | Yes |
| Product Line | X20 |
| Product Type | IP Camera |
| Product Series | 520 |
| Manufacturer Part Number | LUM-520-IP-DFB |
| Technical Information | |
| Aperture | f/1.6 |
| Backlight | Yes |
| Lens Type | Fixed |
| Image Sensor | 5MP |
| Field of View | Horizontal, Vertical |
| Video Formats | H.264, H.265 |
| Motion Detection | Yes |
| Power Consumption | 6W |
| Maximum Frame Rate | 30fps |
| Built-in Microphone | Yes |
| Effective Camera Resolution | 5MP |
| Camera | |
| Camera Type | Dome |
| Wide Dynamic Range | Yes |
| Certifications | |
| NDAA Compliant | Yes |
| Ingress Protection Rating | IP67 |
| Environmental Conditions | |
| Operating Humidity | 95% (Non-condensing) |
| Operating Temperature (T-T) | -22-140°F |
| Exposure | |
| Minimum Illumination | 0 lux |
| Shortest Shutter Speed | 1/100000s |
| Interfaces/Ports | |
| Network (RJ-45) | Yes |
| Lens | |
| Focal Length | 2.8mm |
| Memory | |
| Memory Card Supported | 256GB |
| Physical Characteristics | |
| Color | Black |
| Dimensions | 119mm x 87.8mm |
| Form Factor | Dome |
| Miscellaneous | |
| Compatibility | Control4 |
| Certifications | ETL Listed, CE, FCC, NDAA Compliant, ONVIF Conformance |
| Indoor/Outdoor | Outdoor |
| Impact Protection Rating | IK10 |
