Luma LUM-520-IP-DFTW 520 Series Vandal 5MP Compact Dome IP Outdoor Camera, 2.8mm Fixed Lens, White
Key Features
- Deliver crisp 5MP (2K) video for clear identification and evidence capture
- Compact, low-profile dome ideal for discreet outdoor surveillance and tight mounting locations
- Built-in intelligent analytics reduce false alerts and speed incident review
- IP67 weatherproofing and IK10 vandal resistance protect critical assets in harsh environments
- IR night viewing and 2.8mm fixed lens provide reliable 24/7 monitoring with wide coverage
- OvrC remote management and Control4 compatibility streamline configuration and centralized control
Quick Specifications
- Product Model
- LUM-520-IP-DFTW
- Brand Name
- Luma
- OvrC Enabled
- Yes
- Product Line
- X20
Frequently Bought Together
Luma LUM-520-IP-DFTW 520 Series Vandal 5MP Compact Dome IP Outdoor Camera, 2.8mm Fixed Lens, White
$268.07
6 items selected
Total: $1,026.57
Product Information Tabs
Overview
Designed for reliable, professional security monitoring, the Luma LUM-520-IP-DFTW 520 Series vandal 5MP compact dome delivers high-resolution surveillance in a discreet, rugged package. This Luma outdoor dome camera produces 5MP (2K) imagery through a 2.8mm fixed lens, giving security teams sharper detail for identification and faster incident response. Built-in intelligent analytics reduce nuisance alerts so operators can focus on real events, while dual microphones capture audio context to complement video evidence.
Engineered for real-world deployments, the camera carries IP67 weatherproofing and IK10 impact protection, ensuring continuous operation in exposed locations. IR night viewing provides zero-lux performance for after-dark coverage, and H.264/H.265 compression keeps bandwidth and storage demands efficient. OvrC remote management and Control4 compatibility allow centralized configuration, live adjustments, and streamlined system integration—minimizing onsite service visits.
Ideal for retail, entrances, parking areas, and perimeter security, the Luma 520 Series dome is a practical choice for integrators and facility managers seeking dependable outdoor surveillance. Contact your distributor or add to your next security project to improve monitoring and incident capture.
Features
- Deliver crisp 5MP (2K) video for clear identification and evidence capture
- Compact, low-profile dome ideal for discreet outdoor surveillance and tight mounting locations
- Built-in intelligent analytics reduce false alerts and speed incident review
- IP67 weatherproofing and IK10 vandal resistance protect critical assets in harsh environments
- IR night viewing and 2.8mm fixed lens provide reliable 24/7 monitoring with wide coverage
- OvrC remote management and Control4 compatibility streamline configuration and centralized control
| General Information | |
|---|---|
| Brand Name | Luma |
| OvrC Enabled | Yes |
| Product Line | X20 |
| Product Type | IP Camera |
| Product Series | 520 |
| Manufacturer Part Number | LUM-520-IP-DFTW |
| Technical Information | |
| Aperture | f/1.6 |
| Backlight | Yes |
| Lens Type | Fixed |
| Image Sensor | 5MP |
| Field of View | Horizontal, Vertical |
| Video Formats | H.264, H.265 |
| Motion Detection | Yes |
| Power Consumption | 6W |
| Maximum Frame Rate | 30fps |
| Built-in Microphone | Yes |
| Effective Camera Resolution | 5MP |
| Camera | |
| Camera Type | Dome |
| Wide Dynamic Range | Yes |
| Certifications | |
| NDAA Compliant | Yes |
| Ingress Protection Rating | IP67 |
| Environmental Conditions | |
| Operating Humidity | 95% (Non-condensing) |
| Operating Temperature (T-T) | -22-140°F |
| Exposure | |
| Minimum Illumination | 0 lux |
| Shortest Shutter Speed | 1/100000s |
| Interfaces/Ports | |
| Network (RJ-45) | Yes |
| Lens | |
| Focal Length | 2.8mm |
| Memory | |
| Memory Card Supported | 256GB |
| Physical Characteristics | |
| Color | White |
| Dimensions | 4.33" x 2.36" |
| Form Factor | Dome |
| Miscellaneous | |
| Compatibility | Control4 |
| Certifications | ETL Listed, CE, FCC, NDAA Compliant, ONVIF Conformance |
| Indoor/Outdoor | Outdoor |
| Impact Protection Rating | IK10 |
