Luma LUM-520-IP-DFW 520 Series 5MP Dome IP Outdoor Camera, 2.8mm Fixed Lens, White
Key Features
- Deliver crystal-clear evidence with 5MP (2K) resolution and a 2.8mm wide‑angle lens to reduce blind spots and improve incident identification.
- Reduce false alarms and accelerate investigations with built-in intelligent analytics that highlight key events and provide instant notifications.
- Maintain 24/7 monitoring with IR night vision (0 lux) and True WDR for balanced images in low light and high contrast scenes.
- Deploy faster and manage remotely via OvrC with Control4 and ONVIF compatibility for seamless integration into existing security and automation systems.
- Robust outdoor reliability: IP67 weatherproofing and IK10 impact protection safeguard the camera in harsh environments.
- Efficient H.265 compression and local microSD support (up to 256GB) minimize bandwidth and storage costs while keeping critical footage accessible.
Quick Specifications
- Product Model
- LUM-520-IP-DFW
- Brand Name
- Luma
- OvrC Enabled
- Yes
- Product Line
- X20
Frequently Bought Together
Luma LUM-520-IP-DFW 520 Series 5MP Dome IP Outdoor Camera, 2.8mm Fixed Lens, White
$230.38
5 items selected
Total: $951.09
Product Information Tabs
Overview
Protect perimeter assets and monitor critical outdoor areas with confidence using the Luma LUM-520-IP-DFW 520 Series 5MP Dome IP Outdoor Camera. Built for professional security and surveillance, this Luma dome camera delivers 5MP (2K) clarity through a 2.8mm fixed lens so teams can identify faces, license plates, and events with greater accuracy. Intelligent onboard analytics reduce nuisance alerts and surface only the most relevant incidents for faster review and response. Nighttime and low-light monitoring is assured with IR illumination (0 lux) and True WDR to prevent overexposure and preserve detail across challenging scenes. IT teams will appreciate OvrC remote configuration along with Control4 and ONVIF compatibility for streamlined integration into access control and automation platforms. Engineered for outdoor deployments, the camera’s IP67 and IK10 ratings resist weather and vandalism, while H.265 efficiency and optional microSD storage cut bandwidth and retention costs. Backed by Luma’s three‑year limited warranty, the LUM-520 is a practical choice for commercial, education, and municipal surveillance projects. Add it to your security solution or contact your integrator to schedule a site deployment.
Features
- Deliver crystal-clear evidence with 5MP (2K) resolution and a 2.8mm wide‑angle lens to reduce blind spots and improve incident identification.
- Reduce false alarms and accelerate investigations with built-in intelligent analytics that highlight key events and provide instant notifications.
- Maintain 24/7 monitoring with IR night vision (0 lux) and True WDR for balanced images in low light and high contrast scenes.
- Deploy faster and manage remotely via OvrC with Control4 and ONVIF compatibility for seamless integration into existing security and automation systems.
- Robust outdoor reliability: IP67 weatherproofing and IK10 impact protection safeguard the camera in harsh environments.
- Efficient H.265 compression and local microSD support (up to 256GB) minimize bandwidth and storage costs while keeping critical footage accessible.
| General Information | |
|---|---|
| Brand Name | Luma |
| OvrC Enabled | Yes |
| Product Line | X20 |
| Product Type | IP Camera |
| Product Series | 520 |
| Manufacturer Part Number | LUM-520-IP-DFW |
| Technical Information | |
| Aperture | f/1.6 |
| Backlight | Yes |
| Lens Type | Fixed |
| Image Sensor | 5MP |
| Field of View | Horizontal, Vertical |
| Video Formats | H.264, H.265 |
| Motion Detection | Yes |
| Power Consumption | 6W |
| Maximum Frame Rate | 30fps |
| Built-in Microphone | Yes |
| Effective Camera Resolution | 5MP |
| Camera | |
| Camera Type | Dome |
| Wide Dynamic Range | Yes |
| Certifications | |
| NDAA Compliant | Yes |
| Ingress Protection Rating | IP67 |
| Environmental Conditions | |
| Operating Humidity | 95% (Non-condensing) |
| Operating Temperature (T-T) | -22-140°F |
| Exposure | |
| Minimum Illumination | 0 lux |
| Shortest Shutter Speed | 1/100000s |
| Interfaces/Ports | |
| Network (RJ-45) | Yes |
| Lens | |
| Focal Length | 2.8mm |
| Memory | |
| Memory Card Supported | 256GB |
| Physical Characteristics | |
| Color | White |
| Dimensions | 119mm x 87.8mm |
| Form Factor | Dome |
| Miscellaneous | |
| Compatibility | Control4 |
| Certifications | ETL Listed, CE, FCC, NDAA Compliant, ONVIF Conformance |
| Indoor/Outdoor | Outdoor |
| Impact Protection Rating | IK10 |
