Luma LUM-820-IP-TMHB 820 Series 8MP Turret IP Outdoor Camera, 2.8-12mm Motorized Varifocal Lens, WDR 120 dB, IP67, Black

SKU: LUM-820-IP-TMHB Luma
Image of VM-LUM820TMH
Product images for Luma LUM-820-IP-TMHB 820 Series 8MP Turret IP Outdoor Camera, 2.8-12mm Motorized Varifocal Lens, WDR 120 dB, IP67, Black. 5 image(s) available. Click on image to view full size.
NDAA Compliant

Key Features

  • Deliver 4K/8MP clarity for reliable identification and evidence capture in commercial and residential security setups
  • Motorized 2.8–12mm varifocal lens lets installers and integrators fine-tune coverage remotely for fewer re-visits
  • Hybrid IR and Color‑at‑Night modes plus 120 dB WDR maintain usable images in low light and high-contrast scenes
  • Active Deterrence (built-in LEDs and audible alerts) reduces trespass and empowers proactive site protection
  • System‑ready: OvrC setup, Control4 integration, ONVIF conformance and NDAA compliance simplify deployment and long‑term management

Quick Specifications

Brand Name
Luma
OvrC Enabled
Yes
Product Line
X20
Product Type
Hybrid Active Deterrence Camera
View Full Technical Specifications

Frequently Bought Together

This Item
Luma LUM-820-IP-TMHB 820 Series 8MP Turret IP Outdoor Camera, 2.8-12mm Motorized Varifocal Lens, WDR 120 dB, IP67, Black

Luma LUM-820-IP-TMHB 820 Series 8MP Turret IP Outdoor Camera, 2.8-12mm Motorized Varifocal Lens, WDR 120 dB, IP67, Black

$620.48

Frequently Bought Together (5 items)

6 items selected

Total: $1,402.63

Product Information Tabs

Overview

Protect entrances, perimeters and high-value areas with the Luma LUM-820-IP-TMHB turret IP camera — a professional-grade outdoor surveillance solution built for clarity and deterrence. This Luma turret camera combines an 8MP (4K) CMOS sensor with 120 dB WDR to capture crisp, high-contrast footage for identification even in mixed lighting. The 2.8–12mm motorized varifocal lens provides remote, precise framing so integrators can optimize coverage without ladder work. For night and low-light monitoring, hybrid IR and Color‑at‑Night modes preserve critical color detail while maintaining broad scene coverage. Active Deterrence uses built-in white LEDs and customizable audible alerts to discourage intruders before incidents escalate. Network-ready with native OvrC support, Control4 compatibility and ONVIF conformance, the camera streamlines commissioning and remote management for security professionals. Built to withstand the elements (IP67, IK10) and backed by a 3-year limited warranty, it’s ideal for retail, multi-family, education and commercial monitoring applications. Choose the Luma 820 Series to upgrade your security posture — contact your systems provider to specify this turret camera for perimeter and entrance surveillance.

Features

  • Deliver 4K/8MP clarity for reliable identification and evidence capture in commercial and residential security setups
  • Motorized 2.8–12mm varifocal lens lets installers and integrators fine-tune coverage remotely for fewer re-visits
  • Hybrid IR and Color‑at‑Night modes plus 120 dB WDR maintain usable images in low light and high-contrast scenes
  • Active Deterrence (built-in LEDs and audible alerts) reduces trespass and empowers proactive site protection
  • System‑ready: OvrC setup, Control4 integration, ONVIF conformance and NDAA compliance simplify deployment and long‑term management
General Information
Brand Name Luma
OvrC Enabled Yes
Product Line X20
Product Type Hybrid Active Deterrence Camera
Product Series 820
Manufacturer Part Number LUM-820-IP-TMHB
Technical Information
Aperture f/1.4
Lens Type Varifocal
Image Sensor CMOS
Optical Zoom 2.8-12mm
Field of View Diagonal, Horizontal, Vertical
Video Formats H.264, H.265
Motion Detection Yes
Maximum Frame Rate 30fps
Built-in Microphone Yes
Effective Camera Resolution 8MP
Camera
Image Sensor Type CMOS
Wide Dynamic Range Yes
Certifications
NDAA Compliant Yes
Ingress Protection Rating IP66
Environmental Conditions
Operating Humidity 95% (Non-condensing)
Storage Temperature (T-T) -22-149°F
Operating Temperature (T-T) -22-140°F
Exposure
Minimum Illumination 0 lux
Shortest Shutter Speed 1/4s - 1/1000,000s
Interfaces/Ports
Network (RJ-45) Yes
Lens
Focal Length 2.8-12mm
Memory
Memory Card Supported 256GB
Physical Characteristics
Color Black
Form Factor Turret
Power Description
Maximum Power Consumption 12.5W
Product Information
Diameter 4.38"
Miscellaneous
Features Active Deterrence
Compatibility Control4
Certifications CE, ETL Listed, FCC, NDAA Compliant, ONVIF Conformance
Indoor/Outdoor Outdoor
Impact Protection Rating IK10
