Tripp Lite N206-SB01-IND Waterproof Electrical Junction Box, Surface Mount, Industrial, Single Gang, IP68, 2 Cutouts
Special Order: typically 2–6 weeks
Ships directly from the manufacturer. This is an estimated lead time, not a guaranteed delivery date.
Availability can change and lead times may be longer. If your project has a deadline, check with us before ordering.
A member of our team will check with the manufacturer and personally reply by email.
Image of 8
Key Features
- IP68-rated protection keeps network and surveillance connections safe from dust and up to 1.5m water immersion — ideal for outdoor and flood-prone sites
- Rugged, UL94V-0 polycarbonate housing resists impact and UV exposure to extend service life in harsh industrial environments
- Two M16 knockout cutouts with included cable glands provide a secure, watertight feed for Cat5e/6, USB 3.0 and other low-voltage cables
- Surface-mount design with included hardware simplifies installation on walls or equipment enclosures for fast field deployments
- TAA-compliant and backed by a lifetime warranty for federal procurement and long-term reliability in security and monitoring systems
- Designed to work with Tripp Lite industrial bulkhead couplers and keystone jacks for turnkey networking and surveillance cabling solutions
Quick Specifications
- Product Model
- N206-SB01-IND
- Brand Name
- Eaton Tripp Lite
- Product Name
- N206-SB01-IND Waterproof Electrical Junction Box
- Product Type
- Mounting Box
Frequently Bought Together
Tripp Lite N206-SB01-IND Waterproof Electrical Junction Box, Surface Mount, Industrial, Single Gang, IP68, 2 Cutouts
$15.23
22 items selected
Total: $744.33
Explore the details
Product information
N206-SB01-IND
Overview
Protect critical cabling at the network edge with the Eaton Tripp Lite N206-SB01-IND Waterproof Electrical Junction Box — a purpose-built surface-mount enclosure for outdoor networking, security and surveillance applications. The IP68-rated box delivers dust-tight protection and can withstand immersion (1.5 m for 60 minutes), so Ethernet, USB 3.0 and camera connections remain operational in rain, basements or washdown environments. Constructed from high-impact polycarbonate (UL94V-0) and fitted with flexible rubber gaskets and two M16 knockout ports, it creates a reliable, watertight feed for Cat5e/6 and industrial USB cabling while simplifying installations with included cable glands and mounting hardware. TAA-compliance and a lifetime warranty make it a dependable choice for federal, commercial and industrial projects. Use this Tripp Lite junction box to safeguard surveillance cameras, access control, digital signage and remote monitoring nodes — order now to harden your network endpoints and reduce downtime.
Features
- IP68-rated protection keeps network and surveillance connections safe from dust and up to 1.5m water immersion — ideal for outdoor and flood-prone sites
- Rugged, UL94V-0 polycarbonate housing resists impact and UV exposure to extend service life in harsh industrial environments
- Two M16 knockout cutouts with included cable glands provide a secure, watertight feed for Cat5e/6, USB 3.0 and other low-voltage cables
- Surface-mount design with included hardware simplifies installation on walls or equipment enclosures for fast field deployments
- TAA-compliant and backed by a lifetime warranty for federal procurement and long-term reliability in security and monitoring systems
- Designed to work with Tripp Lite industrial bulkhead couplers and keystone jacks for turnkey networking and surveillance cabling solutions
| General Information | |
|---|---|
| Brand Name | Eaton Tripp Lite |
| Manufacturer | Eaton |
| Product Name | N206-SB01-IND Waterproof Electrical Junction Box |
| Product Type | Mounting Box |
| Product Model | N206-SB01-IND |
| Application/Usage | Surface |
| Country of Origin | TW |
| Packaged Quantity | 1 |
| Manufacturer Part Number | N206-SB01-IND |
| Certifications | |
| TAA Compliant | Yes |
| Physical Characteristics | |
| Color | White |
| Width | 17.50" |
| Height | 33.30" |
| Material | PC |
| Warranty | |
| Limited Warranty | Lifetime |
| Miscellaneous | |
| Features | Cat5/5e, Cat6 |
| Environmentally Friendly | Yes |
| Environmental Certification | RoHS |
