Luminys N5T-8LAV 8MP Turret Camera, 2.7-12mm Varifocal Lens
Key Features
- Crystal-clear 8MP imaging for sharper identification and fewer false positives during security monitoring
- LumiLuxSmart dual illumination (IR + adjustable white-light) for covert surveillance or visible deterrence with motion-based activation
- Motorized 2.7–12mm varifocal lens enables fast on-site field-of-view adjustment for perimeter, entrance, or wide-area coverage
- Embedded video analytics (face detection, people counting, line crossing, intrusion) reduces operator workload and accelerates incident response
- IP67-rated, NDAA-compliant housing with extended-range power options for reliable outdoor deployments and simplified installations
Quick Specifications
- Product Model
- N5T-8LAV
- Brand Name
- Luminys
- Product Line
- LumiLuxSmart
- Product Name
- 8MP Network LumiLuxSmart Turret Camera (Vari-Focal)
Frequently Bought Together
Luminys N5T-8LAV 8MP Turret Camera, 2.7-12mm Varifocal Lens
$424.31
9 items selected
Total: $1,722.01
Product Information Tabs
Overview
Designed for demanding low-light security environments, the Luminys N5T-8LAV 8MP turret camera delivers clear, actionable surveillance so integrators and security teams can detect, verify and respond faster. The 8MP sensor captures high-resolution detail at up to 3840 x 2160, while the motorized 2.7–12mm varifocal lens lets you precisely tailor coverage for entrances, parking lots or retail aisles. Luminys’s LumiLuxSmart dual-illumination seamlessly switches between IR and adjustable white-light LEDs — with motion-activated white light for visible deterrence and energy-efficient IR for covert monitoring. Built-in analytics including face detection, people counting and intrusion/line-crossing alerts streamline monitoring and reduce false alarms, and efficient H.265 encoding lowers bandwidth and storage costs. Rugged IP67 construction and NDAA compliance make the N5T-8LAV ideal for outdoor and critical infrastructure installations. If you need dependable, flexible surveillance with powerful analytics and low-light performance, the N5T-8LAV is ready for perimeter, campus, retail or parking deployments—contact your Luminys reseller or add to your system design today.
Features
- Crystal-clear 8MP imaging for sharper identification and fewer false positives during security monitoring
- LumiLuxSmart dual illumination (IR + adjustable white-light) for covert surveillance or visible deterrence with motion-based activation
- Motorized 2.7–12mm varifocal lens enables fast on-site field-of-view adjustment for perimeter, entrance, or wide-area coverage
- Embedded video analytics (face detection, people counting, line crossing, intrusion) reduces operator workload and accelerates incident response
- IP67-rated, NDAA-compliant housing with extended-range power options for reliable outdoor deployments and simplified installations
| General Information | |
|---|---|
| Brand Name | Luminys |
| Product Line | LumiLuxSmart |
| Product Name | 8MP Network LumiLuxSmart Turret Camera (Vari-Focal) |
| Product Type | IP Camera |
| Product Model | N5T-8LAV |
| Product Series | N5-L Mainstream |
| Manufacturer Part Number | N5T-8LAV |
| Technical Information | |
| Lens Type | Varifocal |
| Night Vision | Yes |
| Field of View | Diagonal, Horizontal, Vertical |
| Video Formats | H.264, H.265, MJPEG |
| Maximum Aperture | f/1.2 |
| Night Vision Type | Infrared (IR) |
| Maximum Frame Rate | 30fps |
| Minimum Focal Length | 2.7mm |
| Effective Camera Resolution | 8MP |
| Camera | |
| Camera Type | Turret |
| Image Sensor Type | CMOS |
| Wide Dynamic Range | Yes |
| Night Vision Distance | 131' |
| Certifications | |
| NDAA Compliant | Yes |
| Ingress Protection Rating | IP67 |
| Display & Graphics | |
| Maximum Video Resolution | 3840 x 2160 |
| Environmental Conditions | |
| Operating Humidity | 0.95 |
| Maximum Operating Temperature | 140°F |
| Minimum Operating Temperature | -22°F |
| Exposure | |
| Minimum Illumination | 0 lux, 0.0004, 0.0007 |
| Longest Shutter Speed | 1/3 Second |
| Shortest Shutter Speed | 1/100000 Second |
| Lens | |
| Focal Length | 2.7-12mm |
| Lens Included | Yes |
| Maximum Focal Length | 12mm |
| Others | |
| Model Number Replaces | N85FJ6Z |
| Physical Characteristics | |
| Height | 5.6" |
| Weight | 2.0lb |
| Form Factor | Turret |
| Power Description | |
| Input Voltage | 12V DC |
| Product Information | |
| Diameter | 5.6" |
| Storage | |
| Storage Type | Memory Card |
| Miscellaneous | |
| Environmental Certification | FCC, IC, UL |
