Crown NCDI1000VM CDi1000 2-Channel 500W Power Amplifier, 70V/140V, Ohms
Image of 2
Key Features
- Flexible output options (2/4/8 Ω plus 70V/140V) let you deploy the amplifier for paging, distributed audio and security/surveillance systems without extra transformers
- Two-channel 500W performance provides reliable headroom and low THD for clear voice and music reproduction in monitoring and installed-sound applications
- Built-in DSP, intuitive front-panel LCD and USB/Ethernet control simplify setup, remote monitoring and large-scale system configuration
- Lightweight, rack-friendly design with a switch-mode universal power supply reduces installation time and supports global voltages
- Environmentally conscious WEEE compliance and a 3-year limited warranty deliver long-term reliability and peace of mind
Quick Specifications
- Product Model
- 1000
- Brand Name
- Crown by Harman
- Product Name
- Two-channel, 500W4, 70V/140V Power Amplifier
- Product Type
- Amplifier
Explore the details
Product information
NCD1000
Overview
Deliver dependable, install-ready power to commercial audio, paging and security systems with the Crown by Harman CDi1000 two-channel power amplifier. Designed for integrators, this pro amplifier supplies 2 x 500W (at 4 Ω) and selectable 70V/140V constant-voltage outputs so you can drive low-impedance speakers or large distributed networks without extra hardware. With industry-grade DSP, an intuitive front-panel LCD, and USB/Ethernet connectivity, the CDi1000 makes configuration, monitoring and remote management fast and repeatable for surveillance, monitoring and installed-sound projects. The switch-mode universal power supply and 22 lb chassis keep rack weight down and support 120/230V operation for global deployments. Delivering clean audio with 0.1% THD across a 20 Hz–20 kHz band, the CDi1000 is ideal for voice clarity in paging, situational awareness in security environments and background music in commercial venues. Backed by WEEE compliance and a 3-year limited warranty, it’s a dependable choice for long-term installations. Choose the CDi1000 for scalable, manageable audio that integrates seamlessly into monitoring and surveillance systems—order now or contact us for system design support.
Features
- Flexible output options (2/4/8 Ω plus 70V/140V) let you deploy the amplifier for paging, distributed audio and security/surveillance systems without extra transformers
- Two-channel 500W performance provides reliable headroom and low THD for clear voice and music reproduction in monitoring and installed-sound applications
- Built-in DSP, intuitive front-panel LCD and USB/Ethernet control simplify setup, remote monitoring and large-scale system configuration
- Lightweight, rack-friendly design with a switch-mode universal power supply reduces installation time and supports global voltages
- Environmentally conscious WEEE compliance and a 3-year limited warranty deliver long-term reliability and peace of mind
| General Information | |
|---|---|
| Brand Name | Crown by Harman |
| Manufacturer | Harman International Industries, Inc |
| Product Name | Two-channel, 500W4, 70V/140V Power Amplifier |
| Product Type | Amplifier |
| Product Model | 1000 |
| Product Series | CDi |
| Manufacturer Part Number | NCDI1000VM |
| Technical Information | |
| Impedance | 4Ohm |
| Audio Channels | 2 |
| Audio | |
| Maximum Frequency Response | 20kHz |
| Minimum Frequency Response | 20Hz |
| Total Harmonic Distortion (THD) | 0.1% – 0.5% |
| Certifications | |
| TAA Compliant | No |
| Energy & Performance | |
| Operating Power Consumption | 1200W |
| Interfaces/Ports | |
| Number of USB Ports | 1 |
| Physical Characteristics | |
| Color | Black, Silver |
| Depth | 12.3" |
| Width | 19.0" |
| Height | 3.5" |
| Weight | 22.00lb |
| Power Description | |
| Input Voltage | 120V AC, 230V AC |
| Product Replacements & Other Alternatives | |
| Model Number Replaces | CDI1000 |
| Warranty | |
| Limited Warranty | 3-Year |
| Miscellaneous | |
| Features | Digital Signal Processing, Lightweight |
| Environmentally Friendly | Yes |
| Environmental Certification | WEEE |
