Bosch NDM-7703-AL FLEXIDOME Multi 7000i x 5MP Outdoor HDR Dome Camera, 3.7-7.7mm Lens, White

SKU: NDM-7703-AL Bosch
Bosch Flexidome 20 Megapixel Outdoor 4K Network Camera - Monochrome, Color - Dome
Product images for Bosch NDM-7703-AL FLEXIDOME Multi 7000i x 5MP Outdoor HDR Dome Camera, 3.7-7.7mm Lens, White. 1 image(s) available. Click on image to view full size.
NDAA Compliant TAA Compliant

Key Features

  • Multi-directional coverage with four independent 5MP sensors, delivering up to 20MP combined detail for fewer blind spots and better evidence capture.
  • Single network connection and single VMS license reduces infrastructure, IP management and total cost of ownership for large-site surveillance.
  • Built-in Bosch IVA and Camera Trainer AI improves event detection and reduces false alarms, streamlining monitoring and incident response.
  • Robust outdoor design (IP66, IK10) and wide operating temperature ensure reliable 24/7 perimeter and street-level security in harsh conditions.
  • Varifocal 3.7–7.7mm lens with 2.1x optical zoom and HDR imaging preserves critical details in challenging light for effective identification and monitoring.

Quick Specifications

Product Model
NDM-7703MP-AL
Brand Name
Bosch
Product Line
FLEXIDOME
Product Name
Fixed dome20 mPMP3 mP.7 mP-7 mP.7 mPmm IP66 mPIR
View Full Technical Specifications

Frequently Bought Together

Product Information Tabs

Overview

Cover wide areas with one rugged unit — ideal for traffic intersections, building corners and campus perimeter monitoring. The Bosch FLEXIDOME Multi 7000i 5MP outdoor HDR dome camera delivers four independent 5MP imagers that combine into up to 20MP of effective coverage, reducing the need for multiple cameras while maintaining forensic-level detail. A 3.7–7.7mm varifocal lens with 2.1x optical zoom and HDR captures clear images in mixed lighting, while built-in infrared extends night monitoring to roughly 98 ft. Bosch’s on-board IVA and Camera Trainer AI add smart analytics for accurate motion detection and reduced false alarms, and H.265 compression lowers bandwidth and storage costs. Rated IP66 and IK10, this multi-directional camera is purpose-built for outdoor security, vandal resistance and continuous operation across wide temperature ranges. Simplify deployments with a single IP address and VMS license while improving situational awareness. Ideal for security, surveillance and monitoring applications — deploy the FLEXIDOME Multi 7000i to strengthen perimeter protection and traffic monitoring today.

Features

  • Multi-directional coverage with four independent 5MP sensors, delivering up to 20MP combined detail for fewer blind spots and better evidence capture.
  • Single network connection and single VMS license reduces infrastructure, IP management and total cost of ownership for large-site surveillance.
  • Built-in Bosch IVA and Camera Trainer AI improves event detection and reduces false alarms, streamlining monitoring and incident response.
  • Robust outdoor design (IP66, IK10) and wide operating temperature ensure reliable 24/7 perimeter and street-level security in harsh conditions.
  • Varifocal 3.7–7.7mm lens with 2.1x optical zoom and HDR imaging preserves critical details in challenging light for effective identification and monitoring.
General Information
Brand Name Bosch
Manufacturer Bosch
Product Line FLEXIDOME
Product Name Fixed dome20 mPMP3 mP.7 mP-7 mP.7 mPmm IP66 mPIR
Product Type Camera
Product Model NDM-7703MP-AL
Product Series 7000i
Packaged Quantity 1
Manufacturer Part Number F.01U.389.265
Technical Information
Lens Type Varifocal
Night Vision Yes
Optical Zoom 2.1x
Field of View 180° - 360°
Video Formats H.264, H.265, MJPEG
Maximum Aperture f/1.9
Night Vision Type Infrared
Maximum Frame Rate 30fps
Minimum Focal Length 3mm
Connectivity Technology Wired
Effective Camera Resolution 20MP
Camera
Image Sensor Type CMOS
Wide Dynamic Range Yes
Night Vision Distance 98.43 ft
Certifications
TAA Compliant Yes
NDAA Compliant Yes
Ingress Protection Rating IP66
Display & Graphics
Number of Sensors 4
Maximum Video Resolution 3840 x 2160
Environmental Conditions
Operating Humidity 1
Maximum Operating Temperature 131°F (55°C)
Minimum Operating Temperature -58°F (-50°C)
Exposure
Longest Shutter Speed 1/25 Second
Shortest Shutter Speed 1/15000 Second
Interfaces/Ports
Network (RJ-45) Yes
Lens
Focal Length 3.7-7.7mm
Lens Included Yes
Maximum Focal Length 7.7mm
Network & Communication
Remote Management Yes
Physical Characteristics
Color White
Height 5.4"
Weight 22oz
Durability Dustproof, Impact Resistant, Vandal Resistant, Waterproof
Form Factor Dome
Power Description
Input Voltage 24V AC
Product Information
Diameter 10.8"
Mount Type Surface Mount
Storage
Storage Type Memory Card
Recording Formats HD
Video
Maximum Resolution 1280 x 720
Miscellaneous
Features Built-in Infrared Illuminator, Built-in Microphone, Day/Night
Indoor/Outdoor Outdoor
Impact Protection Rating IK10
