Altronix NetWaySP4B Dual 1G Fiber SFP, 4x 10/100/1000 PoE/PoE+, configurable for 2x 60W Hi-PoE; Hardened, Switch Board Only, LINQ
Special Order: typically 2–6 weeks
Ships directly from the manufacturer. This is an estimated lead time, not a guaranteed delivery date.
Availability can change and lead times may be longer. If your project has a deadline, check with us before ordering.
A member of our team will check with the manufacturer and personally reply by email.
Image of 1
Key Features
- Deliver reliable, centralized power for surveillance and access control with 120W total PoE budget and configurable Hi-PoE (2x 60W) for PTZ cameras
- Extend networks over fiber with dual 1G SFP uplinks while providing four 10/100/1000 PoE/PoE+ ports for edge devices
- Reduce onsite service visits using LINQ remote power control and fault diagnostics to troubleshoot cameras and network endpoints fast
- Hardened board-mount design rated -40 to 167°F for outdoor enclosures and demanding security installations
- VLAN support, UL listing and NDAA compliance help secure and simplify enterprise surveillance and monitoring deployments
Quick Specifications
- Product Model
- NETWAYSP4B
- Brand Name
- Altronix
- Product Line
- NetWay Spectrum
- Product Name
- 4-port PoE+ Switch Board
Frequently Bought Together
Altronix NetWaySP4B Dual 1G Fiber SFP, 4x 10/100/1000 PoE/PoE+, configurable for 2x 60W Hi-PoE; Hardened, Switch Board Only, LINQ
$567.40
11 items selected
Total: $5,085.88
Explore the details
Product information
NETWAYSP4B
Overview
For security and surveillance professionals who need a compact, rugged fiber-to-PoE solution, the Altronix NetWaySP4B media converter/switchboard delivers dependable power and network connectivity at the edge. This Altronix 4-port PoE/PoE+ switchboard provides up to 120W total PoE budget and supports two configurable 60W Hi-PoE ports for power-hungry PTZ cameras or edge devices. Dual 1G SFP uplinks extend fiber runs to remote locations while four 10/100/1000 Ethernet ports feed IP cameras, access control panels and network sensors. LINQ technology enables remote power cycling and diagnostics, minimizing truck rolls and speeding troubleshooting in critical monitoring applications. The hardened board-mount design operates from -40 to 167°F, is UL listed and NDAA compliant, making it ideal for perimeter security, transportation hubs, and industrial surveillance. Note: requires an external 56VDC power supply. Optimize your security network with a compact, reliable media converter built for real-world deployments—add the NetWaySP4B to your next surveillance or monitoring project.
Features
- Deliver reliable, centralized power for surveillance and access control with 120W total PoE budget and configurable Hi-PoE (2x 60W) for PTZ cameras
- Extend networks over fiber with dual 1G SFP uplinks while providing four 10/100/1000 PoE/PoE+ ports for edge devices
- Reduce onsite service visits using LINQ remote power control and fault diagnostics to troubleshoot cameras and network endpoints fast
- Hardened board-mount design rated -40 to 167°F for outdoor enclosures and demanding security installations
- VLAN support, UL listing and NDAA compliance help secure and simplify enterprise surveillance and monitoring deployments
| General Information | |
|---|---|
| Brand Name | Altronix |
| Manufacturer | Altronix Corporation |
| Product Line | NetWay Spectrum |
| Product Name | 4-port PoE+ Switch Board |
| Product Type | Transceiver/Media Converter |
| Product Model | NETWAYSP4B |
| Product Series | NetWay Spectrum |
| Country of Origin | US |
| Manufacturer Part Number | NETWAYSP4B |
| Technical Information | |
| Power Consumption | 120W |
| Media Type Supported | Optical Fiber, Twisted Pair |
| Certifications | |
| NDAA Compliant | Yes |
| Environmental Conditions | |
| Storage Temperature (T-T) | -40-185°F |
| Operating Temperature (T-T) | -40-167°F |
| I/O Expansions | |
| Expansion Slot Type | SFP |
| Number of SFP Slots | 2 |
| Number of Total Expansion Slots | 2 |
| Interfaces/Ports | |
| Network (RJ-45) | Yes |
| Media & Performance | |
| Network Technology | 1000Base-X |
| Network & Communication | |
| Ethernet Technology | Gigabit Ethernet |
| Physical Characteristics | |
| Depth | 0.6" |
| Width | 4.5" |
| Height | 5.6" |
| Power Description | |
| Power Source | AC Power |
| Input Voltage | 48-57V |
| Power over Ethernet (PoE) | Yes |
| Product Information | |
| Length | 5.6" |
| Mount Type | Board Mount |
| Warranty | |
| Limited Warranty | Lifetime |
