Eaton Tripp Lite NGI-U05POE4 5-Port Unmanaged Industrial Gigabit Ethernet Switch, 30W
Special Order: typically 2–6 weeks
Ships directly from the manufacturer. This is an estimated lead time, not a guaranteed delivery date.
Availability can change and lead times may be longer. If your project has a deadline, check with us before ordering.
A member of our team will check with the manufacturer and personally reply by email.
Image of 6
Key Features
- Deliver reliable power and data over one cable: PoE+ ports supply up to 30W per port with a 120W budget to power cameras, wireless access points and sensors without extra outlets.
- Hardened for industrial use: rugged metal housing and DIN-rail mounting minimize downtime on factory floors, warehouses and outdoor security enclosures.
- Plug-and-play simplicity: unmanaged Gigabit ports with auto-negotiation, auto MDI/MDI-X and MAC learning enable fast deployments with no configuration.
- Space-saving, wide-temperature operation: compact footprint and -10° to 60°C range keep critical monitoring and surveillance networks running in harsh environments.
- Enterprise-grade reliability: IEEE-compliant switching with flow control and a 3-year limited warranty supports continuous operation for security and operational technology applications.
Quick Specifications
- Product Model
- NGI-U05POE4
- Brand Name
- Eaton Tripp Lite
- Product Name
- NGI-U05POE4 Ethernet Switch
- Product Type
- Ethernet Switch
Frequently Bought Together
Eaton Tripp Lite NGI-U05POE4 5-Port Unmanaged Industrial Gigabit Ethernet Switch, 30W
$483.02
27 items selected
Total: $846.65
Explore the details
Product information
NGI-U05POE4
Overview
Power and connect your security and monitoring devices with the Eaton Tripp Lite NGI-U05POE4 5-Port Unmanaged Industrial Gigabit Ethernet Switch. Designed for surveillance, access control and edge networking, this compact PoE+ switch delivers up to 30W per PoE port and a 120W total budget, letting you install IP cameras, wireless access points and IoT sensors without separate power runs. Five auto-negotiating 10/100/1000 Mbps ports provide Gigabit backbone performance while unmanaged operation and automatic MAC learning and MDI/MDI-X make installation fast and maintenance-free. The rugged metal housing, DIN-rail mount and -10° to 60°C operating range ensure dependable operation on factory floors, in transportation hubs and other harsh environments. TAA compliance and a 3-year limited warranty simplify procurement for government and enterprise projects. Ideal for security, surveillance, industrial monitoring and wireless edge deployments, the NGI-U05POE4 brings robust PoE distribution and reliable Gigabit switching to mission-critical networks—deploy it today to streamline installations and reduce infrastructure costs.
Features
- Deliver reliable power and data over one cable: PoE+ ports supply up to 30W per port with a 120W budget to power cameras, wireless access points and sensors without extra outlets.
- Hardened for industrial use: rugged metal housing and DIN-rail mounting minimize downtime on factory floors, warehouses and outdoor security enclosures.
- Plug-and-play simplicity: unmanaged Gigabit ports with auto-negotiation, auto MDI/MDI-X and MAC learning enable fast deployments with no configuration.
- Space-saving, wide-temperature operation: compact footprint and -10° to 60°C range keep critical monitoring and surveillance networks running in harsh environments.
- Enterprise-grade reliability: IEEE-compliant switching with flow control and a 3-year limited warranty supports continuous operation for security and operational technology applications.
| General Information | |
|---|---|
| Brand Name | Eaton Tripp Lite |
| Manufacturer | Eaton |
| Product Name | NGI-U05POE4 Ethernet Switch |
| Product Type | Ethernet Switch |
| Product Model | NGI-U05POE4 |
| Manufacturer Part Number | NGI-U05POE4 |
| Technical Information | |
| Material | Metal |
| Application/Usage | Commercial, Residential |
| Power Consumption | 14W |
| Network Switch Type | Unmanaged |
| Media Type Supported | Twisted Pair |
| Certifications | |
| TAA Compliant | Yes |
| Interfaces/Ports | |
| Network (RJ-45) | Yes |
| Total Number of Network Ports | 5 |
| Management & Protocols | |
| Manageable | No |
| Media & Performance | |
| Network Technology | 10/100/1000Base-T |
| Network & Communication | |
| Layer Supported | 2 |
| Ethernet Technology | 10 Gigabit Ethernet |
| Networking Standards | IEEE 802.1p, IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z |
| Physical Characteristics | |
| Depth | 4.7" |
| Width | 2" |
| Height | 6.3" |
| Weight | 1.90lb |
| Power Description | |
| PoE Budget | 120W |
| PoE (RJ-45) Port | Yes |
| Warranty | |
| Limited Warranty | 3-Year |
| Miscellaneous | |
| Country of Origin | TW |
| Environmentally Friendly | Yes |
