Speco O6MDP4 6MP Indoor / Outdoor 360° Fisheye IP Camera, Smart IR, 1.65mm Lens

SKU: O6MDP4 Speco Technologies
Discount Image of SO-O6MDP4
Product images for Speco O6MDP4 6MP Indoor / Outdoor 360° Fisheye IP Camera, Smart IR, 1.65mm Lens. 1 image(s) available. Click on image to view full size.
NDAA Compliant Sale 9% OFF

Key Features

  • Capture full 360° coverage with a single 6MP fisheye camera, reducing blind spots and the number of cameras required.
  • Mount on ceiling or wall and use on-camera or recorder de-warping for intuitive panoramic or split views that simplify monitoring.
  • Smart IR up to 100' and 0.01 lux sensitivity provide reliable low-light and night surveillance for 24/7 security.
  • IP67-rated weatherproof housing and wide temperature tolerance protect outdoor installations and minimize maintenance.
  • Built-in PoE and efficient H.265 compression lower installation complexity, bandwidth use, and storage costs.

Quick Specifications

Product Model
O6MDP4
Brand Name
Speco Technologies
Product Type
Network Camera
Application/Usage
Commercial Security, Education, Retail, Warehouses
View Full Technical Specifications

Frequently Bought Together

Product Information Tabs

Overview

For comprehensive, cost-effective surveillance coverage, the Speco Technologies O6MDP4 panoramic camera delivers a single-camera solution that replaces multiple fixed cameras. This 6MP fisheye IP camera captures up to a 360° view at 30 fps, letting integrators and security teams monitor large indoor spaces or provide 180° wall views with a single mount. Smart IR with up to 100' range and a sensitive 0.01 lux sensor ensure clear evidence-grade footage in low light, while H.265 compression and onboard microSD support (up to 256GB) reduce network load and storage costs. Designed for real-world deployments, the unit includes PoE (IEEE 802.3af) for simplified cabling and an IP67-rated enclosure to withstand harsh outdoor environments. De-warping can be performed at the camera or recorder for flexible display and analytics integration, making it ideal for retail, transportation hubs, schools, and perimeter monitoring. Backed by a 5-year limited warranty, the O6MDP4 is built for dependable, long-term security monitoring. Add this Speco Technologies panoramic camera to your next project for streamlined installation and wide-area coverage.

Features

  • Capture full 360° coverage with a single 6MP fisheye camera, reducing blind spots and the number of cameras required.
  • Mount on ceiling or wall and use on-camera or recorder de-warping for intuitive panoramic or split views that simplify monitoring.
  • Smart IR up to 100' and 0.01 lux sensitivity provide reliable low-light and night surveillance for 24/7 security.
  • IP67-rated weatherproof housing and wide temperature tolerance protect outdoor installations and minimize maintenance.
  • Built-in PoE and efficient H.265 compression lower installation complexity, bandwidth use, and storage costs.
General Information
Brand Name Speco Technologies
Product Type Network Camera
Application/Usage Commercial Security, Education, Retail, Warehouses
Country of Origin CN
Manufacturer Part Number O6MDP4
Technical Information
Night Vision Yes
Video Formats H.264 / AVC, H.265 / HEVC, MJPEG
Night Vision Type Infrared (IR)
Maximum Frame Rate 30fps
Wide Dynamic Range Yes
Effective Camera Resolution 6MP
Audio
Audio Encoding G.711 µ-law, G.711 A-law
Video Encoding H.264 (AVC), H.265 (HEVC), MJPEG
Camera
Camera Type IP Camera
Image Sensor Type CMOS
Certifications
NDAA Compliant Yes
Ingress Protection Rating IP67
Environmental Conditions
Operating Humidity 95%
Maximum Operating Temperature 140°F
Minimum Operating Temperature -40°F
Exposure
Minimum Illumination 0.0100lux
Longest Shutter Speed 1/3 Second
Shortest Shutter Speed 1/100000 Second
Lens
Focal Length 1.65mm
Lens Included Yes
Memory
SD Card Slot Yes
Network & Communication
Ethernet Technology 10 Mbps (Ethernet), 100 Mbps (Fast Ethernet)
Physical Characteristics
Height 1.82"
Durability Weather Resistant
Form Factor Fisheye
Power Description
Input Voltage 12V DC
Product Information
Diameter 5.11"
Mount Type Ceiling Mount, Wall Mount
Product Replacements & Other Alternatives
Model Number Replaces O6MDP3N
Model Number Alternative DS-2CD3956G2-ISU, DS-2CD6365G0E-IVS 1.27MM
Video
Maximum Resolution 2160 x 2160
Warranty
Limited Warranty 5-Year
Miscellaneous
Features Built-in standard PoE (IEEE 802.3af), Captures up to a 360° view at 30 fps, De-warp views from the camera or recorder, Junction box included, Micro SD card slot up to 256GB (card not included), Provides a 360° view from ceiling or 180° view from wall, Smart IR with range up to 100' (depending on scene reflection)
Indoor/Outdoor Indoor, Outdoor
Environmentally Friendly Yes
Environmental Certification FCC, RoHS
