Vanco PA-EXTDA PulseAudio Digital-Analog Audio Extender Over CAT5e/CAT6
Image of 6
Key Features
- Extend analog (3.5mm) and digital (Toslink/Coax) audio over a single CAT5e/CAT6 run to simplify cabling for AV, security and surveillance installations
- POC-powered design lets the receiver power the transmitter for cleaner, faster installs with fewer power outlets required
- Triple-synchronized outputs (TOSLINK, COAX, RCA L+R) deliver consistent audio to soundbars, recorders and monitoring equipment without reconfiguration
- Long-range performance: analog up to 557ft (170m) and digital up to 951ft (290m) for flexible placement in distributed audio and monitoring systems
- Supports PCM, DTS and Dolby formats to preserve source fidelity across commercial AV, security and networked surveillance setups
Quick Specifications
- Product Model
- PA-EXTDA
- Brand Name
- Vanco
- Product Name
- Digital-Analog Audio Extender (Transmitter and Receiver)
- Product Type
- Audio Extender Transmitter/Receiver
Explore the details
Product information
PA-EXTDA
Overview
Deliver clear, flexible audio across long distances with the Vanco PA-EXTDA PulseAudio Digital-Analog Audio Extender. Designed for integrators and facility managers, this audio extender converts and transmits both analog (3.5mm) and digital (Toslink/Coax) signals over a single CAT5e/CAT6 cable, reducing cable clutter and installation time in security, surveillance, retail and corporate AV environments. With POC technology the transmitter can be powered by the receiver, eliminating the need for a separate power outlet at the source and simplifying deployments in racks, closets or remote zones. The PA-EXTDA offers synchronized TOSLINK, COAX and RCA outputs and preserves PCM, DTS and Dolby formats so audio quality is maintained for monitoring stations, recorders and end-point speakers. Long-range capabilities—analog up to 557ft (170m) and digital up to 951ft (290m)—make it ideal for distributed audio, CCTV audio feeds, and networked monitoring where dependable performance matters. Upgrade your audio distribution with a compact, professional-grade solution from Vanco—perfect for AV pros and security integrators. Add the PA-EXTDA to your next project for reliable audio extension over existing network cabling.
Features
- Extend analog (3.5mm) and digital (Toslink/Coax) audio over a single CAT5e/CAT6 run to simplify cabling for AV, security and surveillance installations
- POC-powered design lets the receiver power the transmitter for cleaner, faster installs with fewer power outlets required
- Triple-synchronized outputs (TOSLINK, COAX, RCA L+R) deliver consistent audio to soundbars, recorders and monitoring equipment without reconfiguration
- Long-range performance: analog up to 557ft (170m) and digital up to 951ft (290m) for flexible placement in distributed audio and monitoring systems
- Supports PCM, DTS and Dolby formats to preserve source fidelity across commercial AV, security and networked surveillance setups
| General Information | |
|---|---|
| Brand Name | Vanco |
| Manufacturer | Vanco International, Inc |
| Product Name | Digital-Analog Audio Extender (Transmitter and Receiver) |
| Product Type | Audio Extender Transmitter/Receiver |
| Product Model | PA-EXTDA |
| Country of Origin | CN |
| Manufacturer Part Number | PA-EXTDA |
| Technical Information | |
| Cable Type | Category 6 |
| Media Type Supported | Coaxial, Twisted Pair |
| Connectivity Technology | Wired |
| Maximum Operating Distance | 951' |
| Interfaces/Ports | |
| Network (RJ-45) | Yes |
| Number of USB Ports | 2 |
| Number of Network (RJ-45) Ports | 2 |
| Physical Characteristics | |
| Color | Black |
| Width | 3.10" |
| Height | 0.80" |
| Weight | 0.50lb |
| Dimensions | 88mm x 80mm x 21.5mm |
| Product Information | |
| Length | 3.50" |
| Warranty | |
| Limited Warranty | 2-Year |
| Miscellaneous | |
| Package Contents | Digital-Analog Audio Extender (Transmitter and Receiver), Power Adapter (12VDC, 1A), Mounting Ears and Screws, 8 Plastic Cushions, Product Manual |
