PulseAudio ARC Digital Audio Extender
Image of 10
Key Features
- Send TV/display audio back to a central amplifier or soundbar over a single CAT5e/6 run, simplifying installs and cutting cabling costs
- ARC Backup Plan with SPDIF fallback keeps audio flowing when display ARC is absent or unreliable, ensuring uninterrupted monitoring or playback
- Transmitter/receiver design with HDMI in/out and RJ45 makes integration with AV, security and surveillance systems fast and reliable
- Long-range performance up to 492' (150 m) enables centralized audio processing for digital signage, conference rooms, retail and control-room deployments
- Compact, USB-powered units and a 2-year limited warranty reduce downtime and simplify placement for installers and integrators
Quick Specifications
- Product Model
- PAEXARC1
- Brand Name
- PulseAudio
- Product Name
- ARC Digital Audio Extender
- Product Type
- Audio Extender Transmitter/Receiver
Frequently Bought Together
PulseAudio ARC Digital Audio Extender
$124.53
11 items selected
Total: $6,810.82
Explore the details
Product information
PAEXARC1
Overview
Route return audio from a display back to a remote amplifier or audio rack without running bulky HDMI cable runs. The PulseAudio ARC Digital Audio Extender (PAEXARC1) is an HDMI audio extender designed for AV integrators, security installers and IT teams who need reliable audio return over structured cabling. Using a single CAT5e/6 twisted-pair link the PAEXARC1 carries ARC audio up to 492' (150 m), preserving soundbar, amplifier and monitoring audio for digital signage, conferencing, surveillance and control-room applications. When a display lacks ARC support or ARC settings fail, the built-in "ARC Backup Plan" uses SPDIF to maintain a clean, digital audio feed so your security monitoring and AV workflows stay uninterrupted. Featuring HDMI in/out, dual RJ-45 networking connectivity and USB power, the transmitter/receiver design integrates easily into existing AV and networking infrastructures. Backed by a 2-year limited warranty, the PAEXARC1 helps reduce maintenance and installation time. Add the PulseAudio PAEXARC1 to your AV or security deployment to centralize audio management and improve system reliability—contact your integrator or order today.
Features
- Send TV/display audio back to a central amplifier or soundbar over a single CAT5e/6 run, simplifying installs and cutting cabling costs
- ARC Backup Plan with SPDIF fallback keeps audio flowing when display ARC is absent or unreliable, ensuring uninterrupted monitoring or playback
- Transmitter/receiver design with HDMI in/out and RJ45 makes integration with AV, security and surveillance systems fast and reliable
- Long-range performance up to 492' (150 m) enables centralized audio processing for digital signage, conference rooms, retail and control-room deployments
- Compact, USB-powered units and a 2-year limited warranty reduce downtime and simplify placement for installers and integrators
| General Information | |
|---|---|
| Brand Name | PulseAudio |
| Manufacturer | Vanco International, Inc |
| Product Name | ARC Digital Audio Extender |
| Product Type | Audio Extender Transmitter/Receiver |
| Product Model | PAEXARC1 |
| Manufacturer Part Number | PAEXARC1 |
| Technical Information | |
| Cable Type | Category 6 |
| Media Type Supported | Twisted Pair |
| Connectivity Technology | Wired |
| Maximum Operating Distance | 492.13' |
| Number of Input Devices Supported | 1 |
| Number of Output Devices Supported | 1 |
| Interfaces/Ports | |
| Network (RJ-45) | Yes |
| Number of USB Ports | 2 |
| Number of HDMI Inputs | 1 |
| Number of HDMI Outputs | 1 |
| Number of Network (RJ-45) Ports | 2 |
| Physical Characteristics | |
| Color | Black |
| Width | 2.8" |
| Height | 0.8" |
| Weight | 0.4lb |
| Product Information | |
| Length | 3.5" |
| Warranty | |
| Limited Warranty | 2-Year |
| Miscellaneous | |
| Country of Origin | CA |
