JBL Professional PD6200/66-WH Speaker, Two-Way Mid-High Horn-Loaded Loudspeaker, White
Special Order Item
This item is available by special order. Lead times may vary. Please contact us for availability and estimated delivery.
Key Features
- Deliver consistent, high-impact coverage with precise 60° x 60° pattern control for clear audio across auditoriums, houses of worship, and arenas.
- High continuous output and intelligible projection (300W RMS, 116 dB sensitivity) to ensure speech and music cut through ambient noise for effective PA and security announcements.
- Horn-loaded design with rotatable PT waveguides provides predictable off-axis response and flexible installation in either vertical or horizontal orientation.
- Built for installed sound: dual-input Speakon and covered barrier strip plus 20 M10 suspension points for versatile rigging and reliable long-term performance.
- Compact, white finish blends into architectural environments while supporting critical monitoring, surveillance PA, and live sound reinforcement needs.
Quick Specifications
- Product Model
- PD6200/66
- Brand Name
- JBL Professional
- Product Name
- PD6200/66 High Output Two-Way Mid/High Frequency Loudspeaker
- Product Type
- Speaker
Product Information Tabs
Overview
The JBL Professional PD6200/66-WH is a two-way mid-high horn-loaded loudspeaker engineered to deliver high-output, controlled directivity where intelligibility and pattern control matter most. Ideal for performing arts centers, theaters, houses of worship, sports venues and security/public-address systems, this installed speaker provides focused 60° x 60° coverage to keep announcements and program audio clear and consistent across large spaces. With 300W RMS power handling, 116 dB sensitivity and a usable response from 240 Hz to 16 kHz, the PD6200/66 delivers the headroom and clarity required for speech, live music and critical monitoring. The design pairs a high-power 8" cone midrange compression driver and a neodymium HF driver with rotatable PT waveguides for smooth off-axis response and flexible mounting in either orientation. Installation is simplified with Speakon and covered barrier-strip inputs, plus twenty M10 suspension points for secure rigging. Whether upgrading an installed sound system, adding reliable security PA for crowd management, or enhancing surveillance monitoring rooms with intelligible audio, the JBL PD6200/66-WH provides professional performance and durability. Contact our sales team to specify and order for your venue or security application.
Features
- Deliver consistent, high-impact coverage with precise 60° x 60° pattern control for clear audio across auditoriums, houses of worship, and arenas.
- High continuous output and intelligible projection (300W RMS, 116 dB sensitivity) to ensure speech and music cut through ambient noise for effective PA and security announcements.
- Horn-loaded design with rotatable PT waveguides provides predictable off-axis response and flexible installation in either vertical or horizontal orientation.
- Built for installed sound: dual-input Speakon and covered barrier strip plus 20 M10 suspension points for versatile rigging and reliable long-term performance.
- Compact, white finish blends into architectural environments while supporting critical monitoring, surveillance PA, and live sound reinforcement needs.
| General Information | |
|---|---|
| Brand Name | JBL Professional |
| Manufacturer | Harman International Industries, Inc |
| Product Name | PD6200/66 High Output Two-Way Mid/High Frequency Loudspeaker |
| Product Type | Speaker |
| Product Model | PD6200/66 |
| Product Series | PD |
| Manufacturer Part Number | PD6200/66-WH |
| Technical Information | |
| Impedance | 8 ohms |
| Sensitivity | 116dB |
| Crossover Type | 2-way |
| Application/Usage | Auditorium, Club, House of Worship, Performing Arts Center, Sport Center, Theatre |
| Audio | |
| RMS Output Power | 300W |
| Maximum Frequency Response | 16 kHz |
| Minimum Frequency Response | 240Hz |
| Physical Characteristics | |
| Size | 1.50" |
| Color | White |
| Depth | 27.8" |
| Width | 26.5" |
| Height | 39" |
| Weight | 129.63lb |
| Miscellaneous | |
| Features | High power 200 mm (8 in) dual-coil CMCD Cone Midrange Compression Driver provides high sensitivity and high continuous SPL capability along with low distortion, extended bandwidth and improved phase coherence, Large format neodymium HF driver provides clear, intelligible high frequency projection, Large PT Progressive Transition waveguides provide excellent pattern control, low distortion at high SPL levels and smooth frequency response, Rotatable waveguides allow either horizontal or vertical cabinet orientation |
| Country of Origin | MX |
