JBL Professional PD6212/66-WH 12" Two-Way Horn-Loaded Loudspeaker, White
Special Order Item
This item is available by special order. Lead times may vary. Please contact us for availability and estimated delivery.
Image of 3
Key Features
- High-output 12-inch horn-loaded design delivers projection and clarity so speech and music stay intelligible even in large venues
- Precision 60° x 60° pattern control reduces spill and improves arrayability for consistent coverage in theaters, houses of worship, and sports facilities
- High sensitivity (116 dB) and 300W continuous capability provide sustained SPL with low distortion and low power compression for reliable performance
- Rotatable HF/LF waveguides and multiple M10 suspension points simplify installation in horizontal or vertical orientations and support flexible rigging
- Weather-resistant enclosure and versatile input options (Speakon and barrier strip) allow indoor/outdoor and security paging or monitoring deployments
Quick Specifications
- Product Model
- PD6212/66
- Brand Name
- JBL Professional
- Product Name
- PD6212/66 High Output Two-Way Full-Range Loudspeaker with 1 x 12" LF
- Product Type
- Speaker
Product Information Tabs
Overview
Deliver high-impact, intelligible sound with excellent pattern control across mid-to-large venues using the JBL Professional PD6212/66 12-inch two-way horn-loaded loudspeaker. Designed as a high-output installed sound solution, this JBL Professional speaker combines a 12-inch horn-loaded low-frequency transducer with a neodymium compression driver to achieve 116 dB sensitivity and 300W RMS handling for sustained, low-distortion SPL. The Precision Directivity™ 60° x 60° waveguide keeps coverage tight and predictable, reducing unwanted reflections and improving speech intelligibility for auditoriums, performing arts centers, and houses of worship. Rotatable waveguides, a weather-resistant cabinet, and twenty M10 suspension points make the PD6212/66 easy to deploy in horizontal or vertical orientations, indoors or outdoors. Use in bi-amped systems or passive configurations with DSP to tune frequency response and integrate with public address, security paging, or surveillance monitoring systems. With Speakon and covered barrier-strip inputs, this loudspeaker is built for professional installs that demand reliability and controlled coverage. Specify the PD6212/66 for your next installed audio, security paging, or monitoring project — contact sales to configure or add to cart.
Features
- High-output 12-inch horn-loaded design delivers projection and clarity so speech and music stay intelligible even in large venues
- Precision 60° x 60° pattern control reduces spill and improves arrayability for consistent coverage in theaters, houses of worship, and sports facilities
- High sensitivity (116 dB) and 300W continuous capability provide sustained SPL with low distortion and low power compression for reliable performance
- Rotatable HF/LF waveguides and multiple M10 suspension points simplify installation in horizontal or vertical orientations and support flexible rigging
- Weather-resistant enclosure and versatile input options (Speakon and barrier strip) allow indoor/outdoor and security paging or monitoring deployments
| General Information | |
|---|---|
| Brand Name | JBL Professional |
| Manufacturer | Harman International Industries, Inc |
| Product Name | PD6212/66 High Output Two-Way Full-Range Loudspeaker with 1 x 12" LF |
| Product Type | Speaker |
| Product Model | PD6212/66 |
| Product Series | PD |
| Manufacturer Part Number | PD6212/66-WH |
| Technical Information | |
| Material | Titanium |
| Impedance | 8 ohms |
| Sensitivity | 116dB |
| Crossover Type | 2-way |
| Application/Usage | Amusement Park, Auditorium, Club, House of Worship, Music Venue, Performing Arts Center, Sport Center, Theatre |
| Audio | |
| RMS Output Power | 300W |
| Maximum Frequency Response | 16 kHz |
| Minimum Frequency Response | 90Hz |
| Physical Characteristics | |
| Size | 12" |
| Color | White |
| Depth | 27.8" |
| Width | 27.2' |
| Height | 39" |
| Weight | 133lb |
| Durability | Weather Resistant |
| Miscellaneous | |
| Features | 300 mm (12 in) horn-loaded LF and largeformat HF driver, high sensitivity design with high continuous SPL capability, Large PT Progressive Transition waveguides provide broad band pattern control, low distortion at high SPL levels and smooth frequency response, Rotatable low and high frequency waveguide allow either horizontal or vertical cabinet orientation, Sophisticated, steep-slope passive crossover network with switchable bi-amp/passive crossover modes |
| Indoor/Outdoor | Outdoor |
| Country of Origin | MX |
