JBL Professional PD6212/95-WH 12" Two-Way Horn-Loaded Loudspeaker, White

SKU: PD621295-WH MPN: PD6212/95-WH JBL Professional

Special Order Item

This item is available by special order. Lead times may vary. Please contact us for availability and estimated delivery.

Image of JF-PD621295W
Product images for JBL Professional PD6212/95-WH 12" Two-Way Horn-Loaded Loudspeaker, White. 3 image(s) available. Click on image to view full size.

Key Features

  • Deliver clear, high-impact sound for large venues with 300W RMS and 114 dB sensitivity — ideal for theaters, houses of worship and sports facilities
  • Precision horn-loaded design and PT waveguides provide focused coverage and consistent off-axis response for intelligible speech and music in challenging acoustics
  • Rotatable low- and high-frequency waveguides let you mount the speaker vertically or horizontally to match venue layouts and arraying requirements
  • Flexible installation with 20 M10 suspension points, Speakon and barrier-strip inputs, and selectable bi-amp/passive operation for system integrators
  • Smooth HF extension to 16 kHz and robust 12" LF driver minimize distortion at high SPLs, improving paging, monitoring and security/ surveillance audio clarity

Quick Specifications

Product Model
PD6212/95
Brand Name
JBL Professional
Product Name
PD6212/95 Speaker
Product Type
Speaker
View Full Technical Specifications

Product Information Tabs

Overview

For high-output installed sound where speech intelligibility and controlled coverage matter, the JBL Professional PD6212/95 two-way horn-loaded loudspeaker delivers dependable performance. Engineered for large auditoriums, performing arts centers, houses of worship and sports venues, this PD Series speaker combines a 12" horn-loaded low-frequency transducer and a neodymium HF compression driver to produce clear program and paging audio. With 300W RMS power handling, 114 dB sensitivity and frequency response extending to 16 kHz (with useful low-frequency output to ~90 Hz), it provides the punch and clarity needed for music and spoken word. Large PT Progressive Transition waveguides and rotatable horns give precise pattern control and uniform off-axis response, simplifying array design and reducing coverage gaps. Installers benefit from 20 M10 rigging points, Speakon and covered barrier-strip inputs, and switchable bi-amp/passive crossover modes — all designed for fast integration into installed sound, security paging and monitoring systems. Specify the PD6212/95 for reliable, high-SPL performance in demanding venues; contact your integrator or order today to build a full-range system with subwoofers for extended bass response.

Features

  • Deliver clear, high-impact sound for large venues with 300W RMS and 114 dB sensitivity — ideal for theaters, houses of worship and sports facilities
  • Precision horn-loaded design and PT waveguides provide focused coverage and consistent off-axis response for intelligible speech and music in challenging acoustics
  • Rotatable low- and high-frequency waveguides let you mount the speaker vertically or horizontally to match venue layouts and arraying requirements
  • Flexible installation with 20 M10 suspension points, Speakon and barrier-strip inputs, and selectable bi-amp/passive operation for system integrators
  • Smooth HF extension to 16 kHz and robust 12" LF driver minimize distortion at high SPLs, improving paging, monitoring and security/ surveillance audio clarity
General Information
Brand Name JBL Professional
Manufacturer Harman International Industries, Inc
Product Name PD6212/95 Speaker
Product Type Speaker
Product Model PD6212/95
Product Series PD
Manufacturer Part Number PD6212/95-WH
Technical Information
Impedance 8 ohms
Sensitivity 114dB
Speaker Size 12"
Crossover Type 2-way
Application/Usage Auditorium, Club, House of Worship, Performing Arts Center, Sport Center, Theatre
Audio
RMS Output Power 300W
Maximum Frequency Response 16 kHz
Minimum Frequency Response 90Hz
Physical Characteristics
Size 12"
Color White
Depth 27.8"
Width 26.5"
Height 39"
Weight 152.12lb
Miscellaneous
Features 300 mm (12 in) horn-loaded LF and largeformat HF driver, high sensitivity design with high continuous SPL capability, Large PT Progressive Transition waveguides provide broad band pattern control, low distortion at high SPL levels and smooth frequency response, Rotatable low and high frequency waveguide allow either horizontal or vertical cabinet orientation, Sophisticated, steep-slope passive crossover network with switchable bi-amp/passive crossover modes
Indoor/Outdoor Outdoor
Country of Origin MX
