Securitron PDB-8F8R2 Access Control Power Board with Fire Alarm Interface, Amp, Glass Fused Output with Relays
Special Order: typically 2–6 weeks
Ships directly from the manufacturer. This is an estimated lead time, not a guaranteed delivery date.
Availability can change and lead times may be longer. If your project has a deadline, check with us before ordering.
A member of our team will check with the manufacturer and personally reply by email.
Image of 1
Key Features
- Centralize and simplify lock & reader power: distributes protected continuous and relay-controlled outputs to reduce wiring complexity and speed installations.
- Fire-safe shutdown and compliance: EOL fire alarm interface master trigger de-energizes enabled outputs for coordinated emergency response and code-friendly integration.
- Flexible input and relay control: accepts universal 12–28VDC and supports low-current open-collector, N/O or N/C inputs for versatile access control logic and monitoring.
- Robust protection and serviceability: heavy-duty relays, selectable fuses or PTC breakers and 10A output capacity protect devices and minimize downtime.
- Scalable for enterprise security: isolate control and main lock power for separate supplies, making it ideal for commercial, campus and multi-door security systems.
Quick Specifications
- Product Model
- PDB-8F8R2
- Sector
- Access Control
- Brand Name
- Securitron by ASSA ABLOY
- Product Name
- Relay
Frequently Bought Together
Securitron PDB-8F8R2 Access Control Power Board with Fire Alarm Interface, Amp, Glass Fused Output with Relays
$108.54
6 items selected
Total: $429.43
Explore the details
Product information
PDB-8F8R2
Overview
Streamline power distribution and emergency response for your access control network with the Securitron by ASSA ABLOY PDB-8F8R2 Access Control Power Board. Designed for security, surveillance and monitoring environments, this access power controller provides eight heavy-duty relays with individual inputs and status LEDs so each door or device can be managed, monitored and serviced independently. The board accepts a universal 12–28VDC input (nominal 12–24VDC) and supplies protected outputs with a 10A capacity to reliably power locks, maglocks and peripheral devices.
Integrating seamlessly with fire alarm systems, the EOL resistor fire interface master trigger can de-energize enabled outputs for safe egress during alarms. Installers benefit from selectable fuse or PTC protection, N/O or N/C relay configurations, and the option to isolate control power from main lock power for flexible system architectures. Backed by Securitron’s MagnaCare lifetime replacement, the PDB-8F8R2 reduces field service time and improves uptime. Ideal for commercial buildings, campuses and enterprise security rooms — contact sales or add to cart to upgrade your access control power distribution and monitoring setup.
Features
- Centralize and simplify lock & reader power: distributes protected continuous and relay-controlled outputs to reduce wiring complexity and speed installations.
- Fire-safe shutdown and compliance: EOL fire alarm interface master trigger de-energizes enabled outputs for coordinated emergency response and code-friendly integration.
- Flexible input and relay control: accepts universal 12–28VDC and supports low-current open-collector, N/O or N/C inputs for versatile access control logic and monitoring.
- Robust protection and serviceability: heavy-duty relays, selectable fuses or PTC breakers and 10A output capacity protect devices and minimize downtime.
- Scalable for enterprise security: isolate control and main lock power for separate supplies, making it ideal for commercial, campus and multi-door security systems.
| General Information | |
|---|---|
| Sector | Access Control |
| Brand Name | Securitron by ASSA ABLOY |
| Manufacturer | ASSA ABLOY |
| Product Name | Relay |
| Product Type | Relay |
| Application/Usage | Fire Alarm Control Panel |
| Country of Origin | US |
| Manufacturer Part Number | PDB-8F8R2 |
| Technical Information | |
| Amperage | 10.00A |
| Physical Characteristics | |
| Depth | 41.66cm |
| Width | 4.80" |
| Height | 3.80" |
| Power Description | |
| Output Current | 10.0000A |
| Maximum Input Current | 2.00A |
| Product Replacements & Other Alternatives | |
| Model Number Replaces | PDD-8ACI-2A |
