Essex PEB-2SBLANK PEB Series Single Gang Piezoelectric No Graphics Switch, Stainless-Steel Faceplate

Ensure dependable, tamper-resistant door-release control for high-traffic or vandal-prone environments. The Essex Electronics PEB-2SBLANK piezoelectric door release button combines industrial-grade durability with flexible integration for access control, security and surveillance projects. Its stainless-steel single-gang faceplate and IP66 all-weather rating protect epoxy-encapsulated electronics from the elements and physical abuse, reducing downtime and maintenance costs. The unit supports 24V DC operation and offers both normally open and normally closed contacts, plus an adjustable 1–40 second output timer to meet varied egress and lock-release requirements. Selectable bi-color illumination (red/green/off), with external control capability, gives technicians and monitoring systems clear visual status for system monitoring and remote diagnostics. UL 294 compliance and a limited lifetime warranty make this switch a reliable choice for commercial buildings, transit stations, healthcare and correctional facilities. Add the PEB-2SBLANK to your access control or surveillance deployment to improve security, simplify wiring and deliver consistent performance under heavy use.

• Rugged stainless-steel faceplate and piezoelectric switch deliver long-term, low-maintenance door release control in vandal-prone and high-traffic areas
• IP66 all-weather rating and epoxy-encapsulated electronics ensure reliable performance outdoors and in harsh environments
• Selectable bi-color illumination (red/green/off) with external control provides clear status feedback for security and monitoring systems
• Dual outputs (N.O. and N.C.) and adjustable 1–40 second timer simplify integration with electric strikes, magnetic locks, and REX inputs
• UL 294 access control compliance and limited lifetime warranty give system integrators confidence in safety and longevity
