Potter PFC-6006 Conventional Fire Panel for Small or Fire Sprinkler Systems
Image of 1
Key Features
- Simplify sprinkler and small-system protection with a listed conventional panel designed for easy installation and dependable monitoring
- Configure up to 6 programmable initiating circuits (including Class A/B waterflow and 2-wire smoke) for flexible zone layouts
- Built-in DACT and telephone line support enable reliable remote alarm reporting and remote configuration for central station monitoring
- Integrated 1A power supply with regulated 0.5A notification and 0.5A auxiliary outputs plus battery backup keeps systems operational during outages
- Clear 32-character LCD, status LEDs and event history make troubleshooting and maintenance faster for facilities and security teams
- Compact lockable cabinet with removable PCB and optional remote annunciators reduces installation time and simplifies serviceability
Quick Specifications
- Product Model
- PFC-6006
- Brand Name
- Potter Electric Signal, LLC
- Product Name
- Conventional Fire Panel for Small or Fire Sprinkler Systems
- Product Type
- Fire Alarm Control Panel
Frequently Bought Together
Potter PFC-6006 Conventional Fire Panel for Small or Fire Sprinkler Systems
$500.69
5 items selected
Total: $1,571.60
Explore the details
Product information
PFC-6006-R
Overview
Protect small commercial sites and fire sprinkler systems with the Potter Electric Signal PFC-6006 conventional fire alarm control panel. Built specifically for small-system monitoring, this Potter fire alarm panel delivers dependable notification and easy serviceability while supporting a range of initiating devices. Installers and facilities managers benefit from six programmable initiating circuits — including a selectable Class A or Class B waterflow input and two-wire smoke detector compatibility — plus an on-board DACT for central station reporting. The integrated 1A power supply charges standby batteries (cabinet fits up to two 12V 18AH) and provides regulated 0.5A notification and 0.5A auxiliary outputs with programmable auxiliary behavior. A 32-character LCD, system LEDs and a history buffer give clear status and event information for faster troubleshooting and compliance reporting. Designed for security and life-safety applications where compact footprint and reliable monitoring matter, the PFC-6006 is ideal for sprinkler control, small retail, office, and telecom rooms. Contact your Potter representative or add to cart to specify the PFC-6006 for your next fire protection and security monitoring project.
Features
- Simplify sprinkler and small-system protection with a listed conventional panel designed for easy installation and dependable monitoring
- Configure up to 6 programmable initiating circuits (including Class A/B waterflow and 2-wire smoke) for flexible zone layouts
- Built-in DACT and telephone line support enable reliable remote alarm reporting and remote configuration for central station monitoring
- Integrated 1A power supply with regulated 0.5A notification and 0.5A auxiliary outputs plus battery backup keeps systems operational during outages
- Clear 32-character LCD, status LEDs and event history make troubleshooting and maintenance faster for facilities and security teams
- Compact lockable cabinet with removable PCB and optional remote annunciators reduces installation time and simplifies serviceability
| General Information | |
|---|---|
| Brand Name | Potter Electric Signal, LLC |
| Manufacturer | Potter Electric Signal, LLC |
| Product Name | Conventional Fire Panel for Small or Fire Sprinkler Systems |
| Product Type | Fire Alarm Control Panel |
| Product Model | PFC-6006 |
| Product Series | PFC |
| Country of Origin | US |
| Manufacturer Part Number | PFC-6006-R |
| Technical Information | |
| Panel Control Type | Conventional |
| Connectivity Technology | Wired |
| Number of Standard Zones | 5 |
| Number of Zones Supported | 6 |
| Battery Information | |
| Battery Built-in | Yes |
| Display & Graphics | |
| Display Type | Non-Touchscreen |
| Physical Characteristics | |
| Color | Red |
| Depth | 4.80" |
| Width | 14.30" |
| Height | 18.50" |
| Power Description | |
| Input Voltage | 12V DC |
| Product Information | |
| Display Screen Type | LCD (Liquid Crystal Display) |
| Warranty | |
| Limited Warranty | 5-Year |
| Miscellaneous | |
| Features | 0.5 Amp Auxiliary Power, Programmable as Constant or Resettable, 1 Notification Circuit rated at 0.5 Amps Regulated, 1.0 Amp Power Supply, 2 Wire Smoke Detector Compatibility, 6 Programmable Initiating Device Circuits, Class A or Class B Waterflow Initiating Circuit, Sensor and Cooper/Wheelock, Strobe Synchronization for Potter/AMSECO, Gentex, System |
| Compatibility | 2 Wire Smoke Detector |
