Hanwha PNM-9031RV P-Series 15MP IR Panoramic Vandal Dome Camera, 4.3mm Fixed Lenses, White (Replaces PNM-9030V)
Key Features
- Reduce camera count and blind spots with a 192° panoramic view for efficient area coverage and lower installation cost
- Capture critical evidence day or night with 15MP resolution and IR night vision up to ~65 ft (20 m)
- Hardened for outdoor use: IP66 weatherproofing and IK10 vandal resistance protect your investment
- Simplify deployment and wiring with PoE+ for power and network over a single cable
- Improve incident response with built-in video analytics and motion detection that generate actionable alerts
Quick Specifications
- Product Model
- PNM-9031RV
- Brand Name
- Hanwha Vision
- Product Name
- 15MP Panoramic Camera
- Product Type
- Network Camera
Frequently Bought Together
Hanwha PNM-9031RV P-Series 15MP IR Panoramic Vandal Dome Camera, 4.3mm Fixed Lenses, White (Replaces PNM-9030V)
$1,652.39
11 items selected
Total: $3,331.38
Product Information Tabs
Overview
Optimize perimeter and facility monitoring with the Hanwha Vision PNM-9031RV P-Series panoramic dome camera. Designed for professional security and surveillance, this network camera delivers a single-camera solution for wide-area coverage—reducing hardware and installation complexity with a 192° panoramic field of view. The PNM-9031RV combines 15MP image clarity with infrared night vision (up to ~65 ft / 20 m) so operators capture usable detail around the clock for investigations and loss prevention. Built-in video analytics and motion detection provide real-time alerts and reduce false positives, helping security teams prioritize responses. Ruggedized IP66 and IK10 ratings ensure reliable outdoor performance in harsh environments, while PoE+ support streamlines installation and lowers deployment costs. Ideal for retail centers, parking facilities, campuses and critical infrastructure, this Hanwha Vision panoramic camera integrates with standard network video systems to enhance situational awareness and monitoring efficiency. Add the PNM-9031RV to your security architecture to consolidate coverage, improve evidence quality, and simplify ongoing operations.
Features
- Reduce camera count and blind spots with a 192° panoramic view for efficient area coverage and lower installation cost
- Capture critical evidence day or night with 15MP resolution and IR night vision up to ~65 ft (20 m)
- Hardened for outdoor use: IP66 weatherproofing and IK10 vandal resistance protect your investment
- Simplify deployment and wiring with PoE+ for power and network over a single cable
- Improve incident response with built-in video analytics and motion detection that generate actionable alerts
| General Information | |
|---|---|
| Brand Name | Hanwha Vision |
| Manufacturer | Hanwha Group |
| Product Name | 15MP Panoramic Camera |
| Product Type | Network Camera |
| Product Model | PNM-9031RV |
| Product Series | P |
| Manufacturer Part Number | PNM-9031RV |
| Technical Information | |
| Lens Type | Fixed |
| Night Vision | Yes |
| Field of View | Horizontal, Vertical |
| Video Formats | H.264, H.265, MJPEG |
| Maximum Aperture | f/1.6 |
| Night Vision Type | Infrared |
| Maximum Frame Rate | 20fps |
| Minimum Focal Length | 4.3mm |
| Connectivity Technology | Wired |
| Field of View (Vertical) | 65° |
| Field of View (Horizontal) | 192° |
| Camera | |
| Image Sensor Type | CMOS |
| Wide Dynamic Range | Yes |
| Night Vision Distance | 65.62 ft |
| Certifications | |
| TAA Compliant | Yes |
| Ingress Protection Rating | IP66 |
| Display & Graphics | |
| Number of Sensors | 4 |
| Maximum Video Resolution | 1600 x 1200 |
| Environmental Conditions | |
| Operating Humidity | 0.95 |
| Maximum Operating Temperature | 131°F (55°C) |
| Minimum Operating Temperature | -40°F (-40°C) |
| Exposure | |
| Longest Shutter Speed | 2 Second |
| Shortest Shutter Speed | 1/12000 Second |
| Interfaces/Ports | |
| Network (RJ-45) | Yes |
| Lens | |
| Focal Length | 4.3mm |
| Lens Included | Yes |
| Maximum Focal Length | 4.3mm |
| Network & Communication | |
| Remote Management | Yes |
| Others | |
| Model Number Replaces | PNM-9030V |
| Physical Characteristics | |
| Color | White |
| Width | 10" |
| Height | 6.7" |
| Weight | 5.73lb |
| Durability | Dustproof, Impact Resistant, Vandal Resistant, Waterproof |
| Form Factor | Dome |
| Power Description | |
| Input Voltage | 12V DC |
| Product Information | |
| Diameter | 10" |
| Mount Type | Pendant Mount |
| Storage | |
| Storage Type | Memory Card |
| Video | |
| Maximum Resolution | 1280 x 720 |
| Warranty | |
| Limited Warranty | 3-Year |
| Miscellaneous | |
| Features | Alarm Triggering, Audio Compression, Audio Detection, Back Light Compensation (BLC), Day/Night, Digital Noise Reduction, Gain Control, Motion Detection, Privacy Masking, SD Card Local Storage, White Balance, Wide Dynamic Range |
| Indoor/Outdoor | Outdoor |
| Country of Origin | KR |
| Impact Protection Rating | IK10 |
