AVer PTR535NV1 4K Ultra HD Professional Dual-Lens Auto Tracking PTZ IP Camera, 30x Optical Zoom
Key Features
- Dual-lens 4K system pairs a wide-angle scene view with a 30x optical zoom to capture both room context and high-detail close-ups
- AI-driven auto-tracking and voice tracking keep speakers and moving subjects in frame, reducing the need for manual operation
- Full NDI integration and multi-format outputs (HDMI, H.264/H.265) simplify streaming, recording, and networked surveillance workflows
- Ceiling-mount design with remote management and multi-presenter detection speeds installation and centralized control for AV and security teams
- Industrial-grade imaging and a 5-year limited warranty provide dependable, long-term performance for monitoring, conferencing, and broadcast environments
Quick Specifications
- Brand Name
- AVer
- Product Name
- TR535N Professional Dual-Lens Auto Tracking PTZ Camera
- Product Type
- Surveillance and Network Camera
- Manufacturer Part Number
- PTR535NV1
Product Information Tabs
Overview
Deliver consistent, professional video coverage for conferences, lectures, broadcast and security monitoring with the AVer PTR535NV1 4K Dual-Lens PTZ camera. Designed for AV integrators and security teams, this Video Conference Camera combines a wide-angle lens for full-room context with a dedicated 30x optical zoom head for detailed close-ups—so you never miss a presenter or critical moment. Built-in AI auto-tracking, multi-presenter detection and voice tracking automate camera control to reduce operator workload and improve coverage in live events or surveillance deployments. With native NDI support, HDMI output and H.264/H.265 streaming, the PTR535NV1 integrates easily into networked production, streaming and monitoring systems. The CMOS sensor and 4K resolution deliver sharp imagery in a range of lighting conditions, while remote management and ceiling-mount form factor streamline installation in boardrooms, lecture halls and security control rooms. Backed by a 5-year limited warranty, it’s engineered for continuous use in professional environments. Upgrade your conferencing or surveillance setup with AVer’s PTR535NV1—ideal for live streaming, campus security monitoring, and corporate AV applications.
Features
- Dual-lens 4K system pairs a wide-angle scene view with a 30x optical zoom to capture both room context and high-detail close-ups
- AI-driven auto-tracking and voice tracking keep speakers and moving subjects in frame, reducing the need for manual operation
- Full NDI integration and multi-format outputs (HDMI, H.264/H.265) simplify streaming, recording, and networked surveillance workflows
- Ceiling-mount design with remote management and multi-presenter detection speeds installation and centralized control for AV and security teams
- Industrial-grade imaging and a 5-year limited warranty provide dependable, long-term performance for monitoring, conferencing, and broadcast environments
| General Information | |
|---|---|
| Brand Name | AVer |
| Product Name | TR535N Professional Dual-Lens Auto Tracking PTZ Camera |
| Product Type | Surveillance and Network Camera |
| Manufacturer Part Number | PTR535NV1 |
| Technical Information | |
| Optical Zoom | 30x |
| Field of View | Diagonal, Horizontal, Vertical |
| Video Formats | H.264, H.265, MJPEG |
| Maximum Aperture | f/4.7 |
| Maximum Frame Rate | 60fps |
| Minimum Focal Length | 4.5mm |
| Field of View (Vertical) | 1.4° |
| Field of View (Horizontal) | 2.5° |
| Effective Camera Resolution | 8MP |
| Camera | |
| Image Sensor Type | CMOS |
| Wide Dynamic Range | Yes |
| Environmental Conditions | |
| Operating Humidity | 20-80% |
| Maximum Operating Temperature | 104°F |
| Minimum Operating Temperature | 32°F |
| Exposure | |
| Minimum Illumination | 0.5 lux |
| Longest Shutter Speed | 1/1 Second |
| Shortest Shutter Speed | 1/10000 Second |
| Interfaces/Ports | |
| HDMI | Yes |
| Lens | |
| Focal Length | 4.5-135mm |
| Lens Included | Yes |
| Minimum Aperture | f/1.8 |
| Maximum Focal Length | 135mm |
| Network & Communication | |
| Remote Management | Yes |
| Physical Characteristics | |
| Depth | 8.6" |
| Width | 7.97" |
| Height | 9.87" |
| Weight | 7.93lb |
| Form Factor | Ceiling Mount |
| Power Description | |
| Input Voltage | 100-240V AC, 12V DC |
| Product Information | |
| Mount Type | Ceiling Mount |
| Warranty | |
| Limited Warranty | 5-Year |
| Miscellaneous | |
| Package Contents | 1/4"-20L 6.5 mm Screw (x2), Cable Fixing Plate (x2), Cable Tie (x7), Camera, Ceiling Mount Bracket (x2), DIN 8 to D-Sub 9 Cable, Drilling Paper, M2 x 4 mm Screw (x5), M3 x 6 mm Screw (x3), Power Adapter, Power cord, Quick start guide, remote control, RS-232 In/Out Cable |
