Capture Advance R2-HD5MPDME 5MP HD IR Dome Camera, 2.8mm Lens, NDAA Compliant, White (Replaces R2-4MPHDDME)
Key Features
- Capture crisp, actionable 5MP imagery for confident identification and incident review
- Built to withstand harsh conditions (IP66 weatherproof, IK10 impact resistant) for reliable outdoor monitoring
- Continuous 24/7 surveillance with built-in IR night vision up to 65.6 ft for low-light coverage
- NDAA compliant design for government and enterprise deployments, easing procurement and compliance
- Easy integration with existing analog surveillance systems (CVI/TVI/AHD/CVBS) to reduce upgrade costs
- Compact dome form with a 2.8mm fixed lens and multiple mount options for fast installation and flexible coverage
Quick Specifications
- Brand Name
- Capture Advance
- Manufacturer
- Capture Advance
- Product Name
- R2-HD5MPDME 5MP HD Dome Camera, 2.8mm Lens
- Product Type
- Surveillance Camera
Frequently Bought Together
Capture Advance R2-HD5MPDME 5MP HD IR Dome Camera, 2.8mm Lens, NDAA Compliant, White (Replaces R2-4MPHDDME)
$65.99
8 items selected
Total: $2,050.42
Product Information Tabs
Overview
Secure clearer, more reliable coverage across your site with the Capture Advance R2-HD5MPDME 5MP HD IR dome camera. This Capture Advance dome camera is engineered for professional surveillance and monitoring, delivering 2560 x 1920 resolution and a 2.8mm fixed lens to capture fine detail for identification and evidence. Rated IP66 and IK10, it stands up to dust, rain and impact for dependable outdoor or indoor operation. Built-in IR LEDs extend night vision to approximately 65.6 ft, ensuring continuous coverage in low-light and no-light environments. NDAA compliance makes this model a strong choice for government and enterprise projects, while multi-format support (CVI/TVI/AHD/CVBS) and 12V DC power simplify integration into existing CCTV infrastructures. The compact white dome and multiple mounting options reduce installation time and visual disruption. Backed by a 36-month limited warranty, the R2-HD5MPDME offers durable performance and peace of mind. Upgrade your security monitoring strategy—specify this camera for retail, office, industrial sites, or government facilities and order today.
Features
- Capture crisp, actionable 5MP imagery for confident identification and incident review
- Built to withstand harsh conditions (IP66 weatherproof, IK10 impact resistant) for reliable outdoor monitoring
- Continuous 24/7 surveillance with built-in IR night vision up to 65.6 ft for low-light coverage
- NDAA compliant design for government and enterprise deployments, easing procurement and compliance
- Easy integration with existing analog surveillance systems (CVI/TVI/AHD/CVBS) to reduce upgrade costs
- Compact dome form with a 2.8mm fixed lens and multiple mount options for fast installation and flexible coverage
| General Information | |
|---|---|
| Brand Name | Capture Advance |
| Manufacturer | Capture Advance |
| Product Name | R2-HD5MPDME 5MP HD Dome Camera, 2.8mm Lens |
| Product Type | Surveillance Camera |
| Product Model | R2-HD5MPDME |
| Manufacturer Part Number | R2-HD5MPDME |
| Technical Information | |
| Lens Type | Fixed |
| Night Vision | Yes |
| Night Vision Type | Infrared |
| Minimum Focal Length | 2.8mm |
| Connectivity Technology | Wired |
| Effective Camera Resolution | 5MP |
| Camera | |
| Image Sensor Type | CMOS |
| Wide Dynamic Range | No |
| Night Vision Distance | 65.62 ft |
| Certifications | |
| NDAA Compliant | Yes |
| Ingress Protection Rating | IP66 |
| Display & Graphics | |
| Maximum Video Resolution | 2560 x 1920 |
| Lens | |
| Focal Length | 2.8mm |
| Lens Included | Yes |
| Maximum Focal Length | 2.8mm |
| Others | |
| Model Number Replaces | R2-4MPHDDME |
| Physical Characteristics | |
| Color | White |
| Durability | Dustproof, Impact Resistant, Waterproof |
| Form Factor | Dome |
| Power Description | |
| Input Voltage | 12V DC |
| Product Information | |
| Mount Type | Desktop Mount, Rack Mount, Wall Mount |
| Video | |
| Maximum Resolution | 1280 x 720 |
| Analog Video Signal Format | AHD, CVBS, CVI, TVI |
| Warranty | |
| Limited Warranty | 36-Month |
| Miscellaneous | |
| Features | Built-in IR LED, Built-in Joystick, Built-in OSD Function |
| Indoor/Outdoor | Indoor, Outdoor |
| Country of Origin | CN |
| Impact Protection Rating | IK10 |
