Capture Advance R2-HD5MPMODM 5MP HD IR Dome Camera, 2.8-12mm Lens, NDAA Compliant, White, (Replaces R2-4MPHDMODM)
Key Features
- Deliver clear, actionable evidence with 5MP resolution for improved identification and incident review
- Flexible 2.8–12mm varifocal lens lets you tailor the field of view to reduce blind spots and installation costs
- Reliable 24/7 monitoring with IR night vision up to 98.43 ft for low-light and no-light conditions
- Built to perform outdoors and in high-risk areas with IP66 weatherproofing and IK10 vandal resistance
- Seamless integration into existing systems via multi-format support (CVI/TVI/AHD/CVBS) and 12V DC power
- NDAA-compliant design and a 36-month warranty provide procurement confidence and long-term peace of mind
Quick Specifications
- Product Model
- R2-HD5MPMODM
- Brand Name
- Capture Advance
- Product Name
- Advance R2-HD5MPMODM 5 MP 2.8-12mm HD Dome Camera
- Product Type
- Surveillance Camera
Frequently Bought Together
Capture Advance R2-HD5MPMODM 5MP HD IR Dome Camera, 2.8-12mm Lens, NDAA Compliant, White, (Replaces R2-4MPHDMODM)
$153.59
9 items selected
Total: $2,759.91
Explore the details
Product information
R2-HD5MPMODM
Overview
Upgrade your site security with the Capture Advance 5MP HD IR Dome Camera — a durable, NDAA-compliant surveillance solution built for reliable 24/7 monitoring. This dome camera captures detailed 2560 x 1920 footage so security teams can quickly identify people, vehicles, and events. The 2.8–12mm varifocal lens gives installers and integrators the flexibility to set a wide overview or a focused long-range view without swapping hardware, cutting deployment time and cost. Integrated IR illumination extends visibility to roughly 98.43 ft, ensuring consistent performance through dusk and complete darkness. Rated IP66 and IK10, the housing resists weather, dust, and vandal attempts, making it ideal for retail, warehouses, parking areas, and critical infrastructure. Multi-format compatibility (CVI/TVI/AHD/CVBS) simplifies integration with existing DVRs and hybrid systems, while NDAA compliance supports secure procurement. Backed by a 36-month warranty, this Capture Advance dome camera is a practical choice for businesses that need dependable security, surveillance, and monitoring. Contact us to configure this camera for your network or add it to your next site upgrade.
Features
- Deliver clear, actionable evidence with 5MP resolution for improved identification and incident review
- Flexible 2.8–12mm varifocal lens lets you tailor the field of view to reduce blind spots and installation costs
- Reliable 24/7 monitoring with IR night vision up to 98.43 ft for low-light and no-light conditions
- Built to perform outdoors and in high-risk areas with IP66 weatherproofing and IK10 vandal resistance
- Seamless integration into existing systems via multi-format support (CVI/TVI/AHD/CVBS) and 12V DC power
- NDAA-compliant design and a 36-month warranty provide procurement confidence and long-term peace of mind
| General Information | |
|---|---|
| Brand Name | Capture Advance |
| Manufacturer | Capture Advance |
| Product Name | Advance R2-HD5MPMODM 5 MP 2.8-12mm HD Dome Camera |
| Product Type | Surveillance Camera |
| Product Model | R2-HD5MPMODM |
| Country of Origin | CN |
| Manufacturer Part Number | R2-HD5MPMODM |
| Technical Information | |
| Night Vision | Yes |
| Night Vision Type | Infrared (IR) |
| Minimum Focal Length | 2.80mm |
| Connectivity Technology | Wired |
| Effective Camera Resolution | 5MP |
| Camera | |
| Image Sensor Type | CMOS |
| Night Vision Distance | 98.43' |
| Certifications | |
| NDAA Compliant | Yes |
| Ingress Protection Rating | IP66 |
| Lens | |
| Focal Length | 2.8-12mm |
| Lens Included | Yes |
| Maximum Focal Length | 12.00mm |
| Physical Characteristics | |
| Color | White |
| Durability | Dustproof, Impact Resistant, Waterproof |
| Form Factor | Dome |
| Power Description | |
| Input Voltage | 12V DC |
| Product Information | |
| Mount Type | Desktop Mount, Rack Mount, Wall Mount |
| Product Replacements & Other Alternatives | |
| Model Number Replaces | R2-4MPHDMODM |
| Video | |
| Maximum Resolution | 1280 x 720 |
| Analog Video Signal Format | CVBS, CVI, TVI |
| Warranty | |
| Limited Warranty | 36-Month |
| Miscellaneous | |
| Features | Built-in IR LED |
| Indoor/Outdoor | Indoor, Outdoor |
| Impact Protection Rating | IK10 |
