Simply45 S45-1750P Pro Series CAT6/6a STP Shielded External Ground, Pass-Through RJ45 with Cap45 and Bar45
Image of 5
Key Features
- Faster, more reliable terminations that reduce installation time and callbacks by simplifying pass-through wiring for Cat6/6a shielded cables
- Cap45 protection eliminates exposed wire-short risk for safer, compliant connections in commercial and security systems
- Two-piece ProSeries design and Bar45 load bar improve 10G NEXT performance by allowing deeper conductor insertion and better twist retention
- Supports PoE, PoE+ and high-density deployments with UL94 V0 rated materials and performance for 10GBase-T applications
- Engineered for installers: accepts 23AWG conductors and cables up to 8.0mm OD for consistent, professional RJ45 terminations
Quick Specifications
- Product Model
- S45-1750P
- Brand Name
- SimplyBRANDS
- Product Line
- Simply45
- Product Name
- PRO Network Connector
Frequently Bought Together
Simply45 S45-1750P Pro Series CAT6/6a STP Shielded External Ground, Pass-Through RJ45 with Cap45 and Bar45
$119.81
9 items selected
Total: $428.76
Explore the details
Product information
S45-1750P
Overview
Get faster, safer Ethernet terminations for mission-critical networking and security installations with the SimplyBRANDS S45-1750P ProSeries shielded pass-through RJ45 connector. This professional network cable connector is designed for Cat6 and Cat6a STP/F/UTP cables and supports 10GBase-T performance, enabling reliable high-speed links for data, surveillance cameras and monitoring systems. The patented Cap45 covers exposed wire ends to prevent electrical shorts in device sockets, while the Bar45 load bar and two-piece metal shell let installers seat large 23AWG conductors up to 1.20mm and cable diameters up to 8.0mm for improved NEXT and consistent terminations. UL94 V0 rated materials and shielded construction make these plugs ideal for PoE/PoE+/PoE++ power delivery and dense commercial deployments where safety and compliance matter. Whether terminating network drops for security, VoIP, or enterprise switches, the S45-1750P delivers predictable performance and lower rework. Choose SimplyBRANDS ProSeries RJ45 connectors for secure, professional installs — perfect for CCTV, access control, and structured cabling projects. Order now to streamline your terminations and upgrade your network reliability.
Features
- Faster, more reliable terminations that reduce installation time and callbacks by simplifying pass-through wiring for Cat6/6a shielded cables
- Cap45 protection eliminates exposed wire-short risk for safer, compliant connections in commercial and security systems
- Two-piece ProSeries design and Bar45 load bar improve 10G NEXT performance by allowing deeper conductor insertion and better twist retention
- Supports PoE, PoE+ and high-density deployments with UL94 V0 rated materials and performance for 10GBase-T applications
- Engineered for installers: accepts 23AWG conductors and cables up to 8.0mm OD for consistent, professional RJ45 terminations
| General Information | |
|---|---|
| Brand Name | SimplyBRANDS |
| Manufacturer | SIMPLY45 LLC |
| Product Line | Simply45 |
| Product Name | PRO Network Connector |
| Product Type | Network Connector |
| Product Model | S45-1750P |
| Product Series | ProSeries |
| Country of Origin | TW |
| Packaged Quantity | 50 |
| Manufacturer Part Number | S45-1750P |
| Technical Information | |
| Shielding | Yes |
| Cable Type | Category 6, Category 6a |
| Contact Plating | Gold |
| Number of Contacts | 8 |
| Certifications | |
| TAA Compliant | Yes |
| Interfaces/Ports | |
| Connector Type | RJ45 |
| Physical Characteristics | |
| Color | Red |
| Warranty | |
| Limited Warranty | Lifetime |
| Miscellaneous | |
| Features | 50µ Gold |
| Environmentally Friendly | Yes |
