TP-Link S4500-8GHP2F Omada Pro 8-Port PoE+ Gigabit Smart Switch with 2 SFP Slots
Special Order: typically 2–6 weeks
Ships directly from the manufacturer. This is an estimated lead time, not a guaranteed delivery date.
Availability can change and lead times may be longer. If your project has a deadline, check with us before ordering.
A member of our team will check with the manufacturer and personally reply by email.
Image of 5
Key Features
- Simplify deployments with 8 PoE+ Gigabit ports and a 150W PoE budget to power cameras, Wi‑Fi access points and VoIP phones from a single device
- Centralized management via Omada Pro SDN for fast provisioning, remote monitoring and reduced maintenance overhead
- Two SFP uplinks provide flexible fiber connectivity and scalable backbone options for branch offices and surveillance systems
- Advanced L2/L2+ QoS, VLAN and static routing optimize voice/video traffic and ensure smooth, low-latency monitoring and VoIP calls
- Enterprise-grade security features (ACL, IP-MAC-Port binding, 802.1X) protect network segments and connected security devices from unauthorized access
Quick Specifications
- Product Model
- S4500-8GHP2F
- Brand Name
- TP-Link
- Product Line
- Omada Pro
- Product Name
- Omada Pro 8-Port PoE+ Gigabit Smart Switch with 2 SFP Slots
Explore the details
Product information
S4500-8GHP2F
Overview
Designed for access-layer deployments that require reliable power and intelligent management, the TP-Link Omada Pro S4500-8GHP2F PoE+ Gigabit Smart Switch delivers a turnkey solution for security, surveillance and enterprise Wi‑Fi networks. With eight 802.3af/at PoE+ Gigabit ports and a 150W total PoE budget, it powers IP cameras, wireless access points and VoIP phones while simplifying cabling and installation. Two Gigabit SFP slots give you flexible fiber uplinks for long-distance backbone connections or aggregation to core switches.
Built for business environments, this managed switch integrates with the Omada Pro SDN Controller for centralized provisioning, monitoring and policy enforcement. L2/L2+ features such as 802.1Q VLANs, IGMP snooping, static routing and advanced QoS prioritize surveillance and voice traffic to eliminate jitter and dropped frames. Robust security controls — including ACL, IP-MAC-Port binding and 802.1X — help isolate sensitive monitoring equipment and prevent unauthorized access.
Compact, rack- or desktop-mountable and metal-built for durability, the S4500-8GHP2F is ideal for retail, education, and enterprise sites that need dependable PoE and network segmentation. Deploy it to power and secure your cameras, APs and phones — contact our team or add to cart to get started.
Features
- Simplify deployments with 8 PoE+ Gigabit ports and a 150W PoE budget to power cameras, Wi‑Fi access points and VoIP phones from a single device
- Centralized management via Omada Pro SDN for fast provisioning, remote monitoring and reduced maintenance overhead
- Two SFP uplinks provide flexible fiber connectivity and scalable backbone options for branch offices and surveillance systems
- Advanced L2/L2+ QoS, VLAN and static routing optimize voice/video traffic and ensure smooth, low-latency monitoring and VoIP calls
- Enterprise-grade security features (ACL, IP-MAC-Port binding, 802.1X) protect network segments and connected security devices from unauthorized access
| General Information | |
|---|---|
| Brand Name | TP-Link |
| Manufacturer | TP-LINK Technologies Co., Ltd |
| Product Line | Omada Pro |
| Product Name | Omada Pro 8-Port PoE+ Gigabit Smart Switch with 2 SFP Slots |
| Product Type | Switch |
| Product Model | S4500-8GHP2F |
| Manufacturer Part Number | S4500-8GHP2F |
| Technical Information | |
| Material | Metal |
| Power Consumption | 174.20W |
| Network Switch Type | Managed, PoE, Smart |
| Media Type Supported | Optical Fiber, Twisted Pair |
| Certifications | |
| TAA Compliant | No |
| I/O Expansions | |
| Expansion Slot Type | SFP |
| Number of SFP Slots | 2 |
| Number of Total Expansion Slots | 2 |
| Interfaces/Ports | |
| Total Number of Network Ports | 8 |
| Management & Protocols | |
| Manageable | Yes |
| Media & Performance | |
| Network Technology | 10/100/1000Base-T, 1000Base-X |
| Network & Communication | |
| Layer Supported | 2 |
| Ethernet Technology | Gigabit Ethernet |
| Networking Standards | IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at, IEEE 802.3i, IEEE 802.3u, IEEE 802.3z |
| Physical Characteristics | |
| Color | Silver |
| Depth | 7.1" |
| Width | 11.6" |
| Height | 1.7" |
| Power Description | |
| Frequency | 50Hz, 60Hz |
| PoE Budget | 150W |
| Power Source | AC, PoE+, Power Supply |
| Input Voltage | 120V AC, 230V AC |
| PoE (RJ-45) Port | Yes |
| Product Information | |
| Mount Type | Desktop Mount, Rack Mount |
