TP-Link SG6654X Omada Campus 48-Port Gigabit Stackable L3 Managed Switch with (6) 10G Slots
Special Order: typically 2–6 weeks
Ships directly from the manufacturer. This is an estimated lead time, not a guaranteed delivery date.
Availability can change and lead times may be longer. If your project has a deadline, check with us before ordering.
A member of our team will check with the manufacturer and personally reply by email.
Image of 5
Key Features
- Scalable campus performance: stack up to 8 units to expand bandwidth and simplify network growth without redesigning topology
- High-throughput aggregation: 48 Gigabit access ports plus 6×10G SFP+ uplinks and 216 Gbps switching to support heavy traffic for surveillance and monitoring
- Resilient operations: dual internal power supplies, VRRP and ERPS for continuous uptime in critical enterprise and ISP environments
- Advanced routing & segmentation: full L3 support (OSPF, RIP, PIM, ECMP) to optimize traffic flow and improve application responsiveness
- Enterprise-grade security: ACLs, 802.1X authentication, port security and DoS protection to harden networks carrying sensitive data and video streams
- Centralized management and visibility: Omada SDN/cloud and CLI/Web/SNMP options for streamlined configuration, monitoring and troubleshooting
Quick Specifications
- Product Model
- SG6654X
- Brand Name
- TP-Link
- Product Line
- Omada
- Product Name
- Omada 48-Port Gigabit Stackable L3 Managed Switch with 6 10G Slots
Explore the details
Product information
SG6654X
Overview
Designed for campus, enterprise edge and ISP convergence layers, the TP-Link SG6654X delivers scalable, resilient networking that keeps critical services — security, surveillance and monitoring — running smoothly. This TP-Link L3 managed switch combines 48 Gigabit RJ45 access ports with six 10G SFP+ uplinks and a 216 Gbps switching fabric to handle aggregated video, VoIP and data traffic without bottlenecks. Physical stacking of up to 8 units and dual internal power supplies provide built-in redundancy and simplified expansion for growing deployments.
The SG6654X offers full L3 routing (OSPF, RIP, PIM) and advanced security features including ACLs and 802.1X to segment traffic and protect sensitive systems. Centralized Omada SDN/cloud management plus traditional CLI, Web and SNMP interfaces give network teams the visibility and control needed for proactive monitoring and rapid troubleshooting. Rack-mountable and built from rugged metal, this switch is optimized for dense connectivity in campus cores, surveillance aggregation points and ISP distribution layers. Contact our sales team to evaluate the SG6654X for your next secure, high-performance network deployment.
Features
- Scalable campus performance: stack up to 8 units to expand bandwidth and simplify network growth without redesigning topology
- High-throughput aggregation: 48 Gigabit access ports plus 6×10G SFP+ uplinks and 216 Gbps switching to support heavy traffic for surveillance and monitoring
- Resilient operations: dual internal power supplies, VRRP and ERPS for continuous uptime in critical enterprise and ISP environments
- Advanced routing & segmentation: full L3 support (OSPF, RIP, PIM, ECMP) to optimize traffic flow and improve application responsiveness
- Enterprise-grade security: ACLs, 802.1X authentication, port security and DoS protection to harden networks carrying sensitive data and video streams
- Centralized management and visibility: Omada SDN/cloud and CLI/Web/SNMP options for streamlined configuration, monitoring and troubleshooting
| General Information | |
|---|---|
| Brand Name | TP-Link |
| Product Line | Omada |
| Product Name | Omada 48-Port Gigabit Stackable L3 Managed Switch with 6 10G Slots |
| Product Type | Switch |
| Manufacturer Part Number | SG6654X |
| Technical Information | |
| Material | Metal |
| Network Switch Type | L2, L3, Managed |
| Certifications | |
| TAA Compliant | No |
| Interfaces/Ports | |
| Total Number of Network Ports | 48 |
| Management & Protocols | |
| Manageable | Yes |
| Network & Communication | |
| Ethernet Technology | Gigabit Ethernet |
| Networking Standards | IEEE 802.1 |
| Physical Characteristics | |
| Color | Black |
| Depth | 15" |
| Width | 17.3" |
| Height | 1.7" |
| Power Description | |
| Frequency | 50 Hz, 60 Hz |
| Input Voltage | 100-240V AC |
| Product Information | |
| Mount Type | Rack Mount |
| Miscellaneous | |
| Package Contents | 2× Power Cords, Quick installation guide, Rackmount kit, RJ45 Console Cable |
