Lantronix SISTG1013-211-LRT-B Unmanaged Hardened Gigabit Ethernet Media Converter, 10/100/1000Base-T (RJ-45) 100 m/328' to 1000Base-SX 850nm Multimode (SC)
Special Order: typically 2–6 weeks
Ships directly from the manufacturer. This is an estimated lead time, not a guaranteed delivery date.
Availability can change and lead times may be longer. If your project has a deadline, check with us before ordering.
A member of our team will check with the manufacturer and personally reply by email.
Image of 3
Key Features
- Extend Ethernet links over multimode fiber for reliable security and surveillance connectivity without complex configuration
- Industrial-grade reliability with minus 40C to 75C operation and UL Class 1 Div 2 certification for hazardous locations
- Dual redundant 12–48 VDC power inputs and reverse-polarity/overload protection to maximize uptime
- Plug-and-play unmanaged design with Auto-Negotiation, Auto-MDI/MDIX and 9K jumbo frame support for easy integration
- Compact DIN-rail mountable form factor and low 3.4W power draw reduce rack space and operating costs
Quick Specifications
- Product Model
- SISTG1013-211-LRT-B
- Brand Name
- Lantronix
- Product Name
- Unmanaged Hardened Gigabit Ethernet Media Converter
- Product Type
- Transceiver/Media Converter
Explore the details
Product information
SISTG1013-211-LRT-B
Overview
Extend critical Ethernet links into harsh environments with the Lantronix SISTG1013-211-LRT-B unmanaged hardened Gigabit media converter. Designed for security, surveillance and industrial monitoring applications, this media converter transparently converts 10/100/1000Base-T copper (RJ-45) to 1000Base-SX multimode fiber (850 nm, SC) to deliver long-distance, low-latency Gigabit connectivity to cameras, access control and remote I/O. With an industrial operating range from minus 40C to 75C and dual redundant 12–48 VDC power inputs with reverse-polarity protection, the converter minimizes downtime and keeps critical networks online in extreme conditions. Its plug-and-play, unmanaged design supports Auto-Negotiation, Auto-MDI/MDIX and jumbo frames (9K) for simple integration into existing networks without configuration. Small DIN-rail form factor and UL Class 1 Div 2 certification make it suitable for hazardous locations in oil & gas, manufacturing, or transportation. Backed by a five-year limited warranty and RoHS/WEEE compliance, the Lantronix SISTG1013-211-LRT-B provides a reliable, low-power (3.4W) solution to extend Ethernet over multimode fiber up to 550 m (50/125 μm). Specify it for surveillance camera runs, perimeter security, or remote monitoring links to reduce cabling costs and increase link resilience.
Features
- Extend Ethernet links over multimode fiber for reliable security and surveillance connectivity without complex configuration
- Industrial-grade reliability with minus 40C to 75C operation and UL Class 1 Div 2 certification for hazardous locations
- Dual redundant 12–48 VDC power inputs and reverse-polarity/overload protection to maximize uptime
- Plug-and-play unmanaged design with Auto-Negotiation, Auto-MDI/MDIX and 9K jumbo frame support for easy integration
- Compact DIN-rail mountable form factor and low 3.4W power draw reduce rack space and operating costs
| General Information | |
|---|---|
| Brand Name | Lantronix |
| Manufacturer | Transition Networks, Inc |
| Product Name | Unmanaged Hardened Gigabit Ethernet Media Converter |
| Product Type | Transceiver/Media Converter |
| Product Model | SISTG1013-211-LRT-B |
| Product Series | SISTG10xx-211-LRT-B |
| Maximum Distance | 1804.46' |
| Manufacturer Part Number | SISTG1013-211-LRT-B |
| Technical Information | |
| Fiber Optic Mode | Multimode |
| Power Consumption | 3.40W |
| Media Type Supported | Optical Fiber, Twisted Pair |
| Interfaces/Ports | |
| Network (RJ-45) | Yes |
| Number of Ports | 2 |
| Number of SC Ports | 1 |
| Number of Network (RJ-45) Ports | 1 |
| Media & Performance | |
| Network Technology | 10/100/1000Base-T, 1000Base-SX |
| Fiber Optic Wavelength | 850 nm |
| Network & Communication | |
| Ethernet Technology | Gigabit Ethernet |
| Others | |
| Model Number Replaces | SISTG1013-111-LRT |
| Physical Characteristics | |
| Depth | 3.9" |
| Width | 1.2" |
| Height | 4.3" |
| Weight | 15.52oz |
| Power Description | |
| Power Source | Power Supply |
| Product Information | |
| Mount Type | Rail Mount |
| Warranty | |
| Limited Warranty | 5-Year |
| Miscellaneous | |
| Country of Origin | TW |
| Environmentally Friendly | Yes |
| Environmental Certification | RoHS, WEEE |
