Alarm Controls SLP-5M DPDT Momentary Switch Monitoring, Control Station
Special Order: typically 2–6 weeks
Ships directly from the manufacturer. This is an estimated lead time, not a guaranteed delivery date.
Availability can change and lead times may be longer. If your project has a deadline, check with us before ordering.
A member of our team will check with the manufacturer and personally reply by email.
Image of 6
Key Features
- Provides monitored, illuminated DPDT momentary switching for reliable control and clear status feedback of electrified locks
- Built-in hi-bright LED (operates on 12 or 24V AC/DC) improves visibility and integrates with monitoring systems
- DPDT switch contacts rated 3A at 35VDC / 120VAC for dependable operation of locks and control circuits
- Fits standard single- to 4-gang wall plates with a shallow 1-1/2" depth for fast retrofit and clean installations
- Custom legends plus green and yellow LED options allow site-specific labeling and intuitive status indication
Quick Specifications
- Product Model
- SLP-5M
- Brand Name
- Alarm Controls by ASSA ABLOY
- Product Line
- Â
- Product Name
- SLP Monitor and Control Stations
Explore the details
Product information
SLP-5M
Overview
Put control and monitoring where you need it most. The Alarm Controls by ASSA ABLOY SLP-5M control station delivers a compact, professional solution for access control, security stations and monitoring panels. Its illuminated DPDT momentary switch provides instantaneous control while offering visible status feedback — ideal for supervising one or more electrified locks. The built-in hi-bright LED runs on 12 or 24V AC/DC to match common security and surveillance power supplies, while switch contacts rated at 3A (35VDC / 120VAC) ensure dependable switching of lock and auxiliary circuits.
Designed for installers and security integrators, the SLP-5M mounts on standard single- to 4-gang wall plates with only a 1-1/2" mounting depth for quick retrofits. Colored, pre-terminated leads and optional green/yellow LEDs reduce installation time and support clear system diagnostics. Whether integrating with an access control system or providing local lock release and monitoring at a security desk, the SLP-5M offers a durable, serviceable control panel accessory. Specify the SLP-5M for reliable lock control, monitoring and streamlined installation — contact us to configure custom legends or place an order.
Features
- Provides monitored, illuminated DPDT momentary switching for reliable control and clear status feedback of electrified locks
- Built-in hi-bright LED (operates on 12 or 24V AC/DC) improves visibility and integrates with monitoring systems
- DPDT switch contacts rated 3A at 35VDC / 120VAC for dependable operation of locks and control circuits
- Fits standard single- to 4-gang wall plates with a shallow 1-1/2" depth for fast retrofit and clean installations
- Custom legends plus green and yellow LED options allow site-specific labeling and intuitive status indication
| General Information | |
|---|---|
| Brand Name | Alarm Controls by ASSA ABLOY |
| Manufacturer | Alarm Controls by ASSA ABLOY |
| Product Line | Â |
| Product Name | SLP Monitor and Control Stations |
| Product Type | Control Station |
| Product Model | SLP-5M |
| Product Series | Â |
| Country of Origin | US |
| Manufacturer Part Number | SLP-5M |
| Physical Characteristics | |
| Color | Green, Red, Yellow |
| Power Description | |
| Input Voltage | 120V AC, 35V DC |
| Miscellaneous | |
| Features | 1/2" red LED operates on 12 or 24 VAC or VDC, Components mounted on standard single - four gang electrical wall plate, Custom switch legends available, Depth behind plate is 1-1/2", Designed to release or secure and monitor one electric lock, DPDT illuminated latching push button with hi-brightness built-in LED, Green and yellow LEDs available, Switch and LED terminated with colored leads, Switch contacts rated 3 Amps at 35VDC or 120VAC, Switch LED operates on 12 or 24 VAC or VDC |
