Lantronix SM48TAT4XA-RP-OZ 48-Port Gigabit POE+ Switch with (4) 1G/10G SFP+, Single
Special Order: typically 2–6 weeks
Ships directly from the manufacturer. This is an estimated lead time, not a guaranteed delivery date.
Availability can change and lead times may be longer. If your project has a deadline, check with us before ordering.
A member of our team will check with the manufacturer and personally reply by email.
Image of 3
Key Features
- Power up dense deployments: 48 PoE+ Gigabit ports with an 820W budget to reliably power IP cameras, access points and VoIP phones without extra power injectors
- Future-proof uplinks: Four 1G/10G SFP+ slots provide high-speed aggregation for NVRs, servers and backbone links to support surveillance and monitoring traffic
- Secure, segmented networks: Layer 3 switching with 802.1X, RADIUS/TACACS+, VLANs and ACLs simplifies secure segmentation for security and IT environments
- Scalable performance: Managed feature set (QoS, jumbo frames, LLDP, PTP) ensures low-latency streaming for video surveillance and real-time monitoring
- Energy-efficient, rack-ready design: 1U hot-swappable build with IEEE 802.3az support and lifetime limited warranty for reliable, low-maintenance operation
Quick Specifications
- Product Model
- SM48TAT4XA-RP
- Brand Name
- Lantronix
- Product Name
- SM48TAT4XA-RP Ethernet Switch
- Product Type
- Ethernet Switch
Explore the details
Product information
SM48TAT4XA-RP-OZ
Overview
Build a secure, high-capacity PoE infrastructure for surveillance, access control and enterprise Wi‑Fi with the Lantronix SM48TAT4XA-RP managed switch. This 48-port Gigabit PoE+ switch delivers an 820W PoE budget to power dozens of cameras and wireless access points while eliminating the need for separate power injectors. Four 1G/10G SFP+ uplink slots provide flexible, high-speed aggregation to NVRs, core switches or cloud gateways for smooth video streaming and monitoring.
As a Lantronix managed network switch, the SM48TAT4XA-RP includes Layer 3 routing, advanced VLAN and ACL controls, 802.1X authentication, RADIUS/TACACS+ and SSH/SSL security to protect sensitive surveillance and security data. Support for jumbo frames (up to 10240 bytes), IEEE 1588v2 timing and QoS ensures low-latency delivery for high-resolution video and telemetry. The rack-mountable, energy-efficient design simplifies deployments in server rooms and telecom closets and comes with a lifetime limited warranty for long-term peace of mind.
Ideal for security integrators and IT teams, this Lantronix PoE+ switch streamlines installations for CCTV, access control and monitoring systems — contact us to specify the right configuration for your deployment.
Features
- Power up dense deployments: 48 PoE+ Gigabit ports with an 820W budget to reliably power IP cameras, access points and VoIP phones without extra power injectors
- Future-proof uplinks: Four 1G/10G SFP+ slots provide high-speed aggregation for NVRs, servers and backbone links to support surveillance and monitoring traffic
- Secure, segmented networks: Layer 3 switching with 802.1X, RADIUS/TACACS+, VLANs and ACLs simplifies secure segmentation for security and IT environments
- Scalable performance: Managed feature set (QoS, jumbo frames, LLDP, PTP) ensures low-latency streaming for video surveillance and real-time monitoring
- Energy-efficient, rack-ready design: 1U hot-swappable build with IEEE 802.3az support and lifetime limited warranty for reliable, low-maintenance operation
| General Information | |
|---|---|
| Brand Name | Lantronix |
| Manufacturer | Lantronix, Inc |
| Product Name | SM48TAT4XA-RP Ethernet Switch |
| Product Type | Ethernet Switch |
| Product Model | SM48TAT4XA-RP |
| Product Series | SM48TAT4XA-RP |
| Manufacturer Part Number | SM48TAT4XARPOZ |
| Technical Information | |
| Power Consumption | 15.4000W |
| Media Type Supported | Optical Fiber, Twisted Pair |
| I/O Expansions | |
| Shared SFP Slot | No |
| Expansion Slot Type | SFP+ |
| Number of SFP+ Slots | 4 |
| Number of Total Expansion Slots | 4 |
| Interfaces/Ports | |
| Modular | Yes |
| Network (RJ-45) | Yes |
| Total Number of Network Ports | 48 |
| Management & Protocols | |
| Manageable | Yes |
| Media & Performance | |
| Network Technology | 10/100/1000Base-T, 10GBase-X |
| Network & Communication | |
| Layer Supported | 3 |
| Ethernet Technology | 10 Gbps |
| Networking Standards | IEEE 802.1ad, IEEE 802.1p, IEEE 802.3ad |
| Physical Characteristics | |
| Depth | 14.80" |
| Width | 17.40" |
| Height | 1.70" |
| Power Description | |
| PoE Budget | 820.0W |
| Power Source | PoE (Power over Ethernet) |
| Input Voltage | 100-240V AC |
| PoE (RJ-45) Port | Yes |
| Warranty | |
| Limited Warranty | Lifetime |
| Miscellaneous | |
| Features | Hot-swappable |
| Package Contents | SM48TAT4XA-RP Ethernet Switch1 x AC Power Supply1 x 19" Rack Mount BracketPower Cord Australia |
| Environmentally Friendly | Yes |
| Environmental Certification | REACH, RoHS, WEEE |
No matching specifications
Try a different term, such as a connector type or resolution.
Plan your purchase
Is this right for your project?
Confirm the model, required accessories and delivery needs before ordering.
- SKU:
- SM48TAT4XA-RP-OZ
- Manufacturer part:
- SM48TAT4XA-RP-OZ
How do I confirm compatibility?
Check the specifications and manufacturer documents for your existing system. Send us your model numbers and project requirements if you need help selecting equipment or accessories.
Ask a product specialistWhen will this item ship?
Availability is shown above. Special-order items and project quantities may need additional lead time. Contact us to confirm a delivery date before scheduling installation.
Shipping, freight and delivery detailsWhat should I know about returns?
Returns require an approved RMA. Consult the linked return policy for deadlines and eligibility. For standard non-defective returns, eligible factory-sealed items carry a 15% restocking fee and customer-paid return shipping; open-box and used items are refused. Defective and DOA claims follow the policy's separate terms. Special orders and other exclusions are final sale.
Read return eligibility and exclusionsLantronix SM48TAT4XA-RP-OZ 48-Port Gigabit POE+ Switch with (4) 1G/10G SFP+, Single
SM48TAT4XA-RP-OZ
