Eaton Tripp Lite SU5000RTMB SmartOnline 5000VA 4500W 208V Online Double-Conversion UPS with Maintenance Bypass, L6-20R/L6-30R Outlets, L6-30P Input, Network Card Included, 3U Rack / Tower
Special Order: typically 2–6 weeks
Ships directly from the manufacturer. This is an estimated lead time, not a guaranteed delivery date.
Availability can change and lead times may be longer. If your project has a deadline, check with us before ordering.
A member of our team will check with the manufacturer and personally reply by email.
Image of 7
Key Features
- Ensures continuous uptime for critical IT, security and surveillance gear with 5kVA/4500W online double-conversion protection
- Hot‑swappable VRLA battery modules and support for up to four external EBMs deliver scalable runtime and fast field serviceability
- Preinstalled network card (WEBCARDLXE) enables 24/7 remote monitoring, SNMP management and automated safe shutdowns for distributed networks
- Built-in manual maintenance bypass allows on-site servicing without interrupting power to connected loads
- Outlet-level control with 2 x L6-20R and 2 x L6-30R provides pure sine-wave power and group-level load management for servers, switches and cameras
Quick Specifications
- Product Model
- SU5000RTMB
- Sector
- Data Comm & Networking
- Brand Name
- Eaton Tripp Lite
- Product Line
- SmartOnline
Frequently Bought Together
Eaton Tripp Lite SU5000RTMB SmartOnline 5000VA 4500W 208V Online Double-Conversion UPS with Maintenance Bypass, L6-20R/L6-30R Outlets, L6-30P Input, Network Card Included, 3U Rack / Tower
$5,601.50
6 items selected
Total: $8,733.58
Explore the details
Product information
SU5000RTMB
Overview
Protect mission-critical systems and edge deployments with the Eaton Tripp Lite SU5000RTMB online UPS. Built as a double-conversion 5kVA/4500W power system, this 208V, 3U rack/tower UPS delivers clean, uninterrupted pure sine-wave power to servers, network switches, surveillance cameras and monitoring appliances—minimizing downtime and preventing data loss. The SU5000RTMB includes hot-swappable VRLA battery modules plus support for external battery packs to extend runtime during prolonged outages, and a manual bypass switch lets technicians service the UPS without disrupting equipment. Integrated network management (WEBCARDLXE) provides SNMP, remote monitoring and automated reboot capabilities ideal for distributed networking and security environments. Outlet-level control with two L6-20R and two L6-30R receptacles enables targeted load shedding to preserve critical functions. Rugged 3U rack/tower form factor, USB/serial communications and dry-contact integration make this Eaton Tripp Lite UPS an effective choice for data centers, branch offices, surveillance and building monitoring systems. Protect your infrastructure—contact us to specify the SU5000RTMB for your next IT, security or edge deployment.
Features
- Ensures continuous uptime for critical IT, security and surveillance gear with 5kVA/4500W online double-conversion protection
- Hot‑swappable VRLA battery modules and support for up to four external EBMs deliver scalable runtime and fast field serviceability
- Preinstalled network card (WEBCARDLXE) enables 24/7 remote monitoring, SNMP management and automated safe shutdowns for distributed networks
- Built-in manual maintenance bypass allows on-site servicing without interrupting power to connected loads
- Outlet-level control with 2 x L6-20R and 2 x L6-30R provides pure sine-wave power and group-level load management for servers, switches and cameras
| General Information | |
|---|---|
| Sector | Data Comm & Networking |
| Brand Name | Eaton Tripp Lite |
| Manufacturer | Eaton |
| Product Line | SmartOnline |
| Product Name | SmartOnline SU5000RTMB 5000VA Rack/tower UPS |
| Product Type | Double Conversion Online UPS |
| Product Model | SU5000RTMB |
| Application/Usage | Commercial, Education, Financial, Healthcare, IT Equipment, Mission Critical Equipment, Network Device |
| Manufacturer Part Number | SU5000RTMB |
| Technical Information | |
| AVR | Yes |
| Phase | Single Phase |
| Hot Swappable | Yes |
| Output Voltage | 200V AC, 208V AC, 220V AC, 230V AC, 240V AC |
| Receptacle Type | Hardwired, NEMA L6-20R, NEMA L6-30R |
| Receptacle Detail | 2 x NEMA L6-20R, 2 x NEMA L6-30R |
| EMI/RFI Noise Filter | Yes |
| Backup/Run Time (Full Load) | 3.0min |
| Backup/Run Time (Half Load) | 11.0min |
| Battery Information | |
| Battery Chemistry | Lead Acid |
| DC System Voltage | 180 |
| Replaceable Battery | Yes |
| Battery Characteristics | VRLA |
| Certifications | |
| Energy Star | Yes |
| Controls/Indicators | |
| Status Indicators | Yes |
| Environmental Conditions | |
| Maximum Operating Temperature | 104.00°F |
| Interfaces/Ports | |
| Serial Port | Yes |
| Management | |
| Alarm | Battery Fault, Low Battery, Overload, Remote Shutdown, Utility Power Failure |
| Network Management | DB-9 RS-232, Dry Contact, Network Card, SNMP, USB |
| Physical Characteristics | |
| Color | Green |
| Depth | 34.00" |
| Width | 17.30" |
| Height | 5.10" |
| Form Factor | Rack Mount, Tower |
| Power Description | |
| Input Voltage | 230V AC |
| Waveform Type | Pure Sine Wave |
| Output Frequency | 60Hz |
| Plug/Connector Type | Hardwired, NEMA L6-30P |
| Product Information | |
| Mount Type | Tower Mount |
| Product Replacements & Other Alternatives | |
| Model Number Replaces | SU5KRT3UHVMB |
| Warranty | |
| Limited Warranty | 2-Year |
| Miscellaneous | |
| Features | Audible Alarm, Built-in Bypass Switch, Cold Start Function, Green Energy Saving |
| Package Contents | Quick Start Guide |
| Environmentally Friendly | Yes |
| Environmental Certification | RoHS |
No matching specifications
Try a different term, such as a connector type or resolution.
Plan your purchase
Is this right for your project?
Confirm the model, required accessories and delivery needs before ordering.
- SKU:
- SU5000RTMB
- Manufacturer part:
- SU5000RTMB
How do I confirm compatibility?
Check the specifications and manufacturer documents for your existing system. Send us your model numbers and project requirements if you need help selecting equipment or accessories.
Ask a product specialistWhen will this item ship?
Availability is shown above. Special-order items and project quantities may need additional lead time. Contact us to confirm a delivery date before scheduling installation.
Shipping, freight and delivery detailsWhat should I know about returns?
Returns require an approved RMA. Consult the linked return policy for deadlines and eligibility. For standard non-defective returns, eligible factory-sealed items carry a 15% restocking fee and customer-paid return shipping; open-box and used items are refused. Defective and DOA claims follow the policy's separate terms. Special orders and other exclusions are final sale.
Read return eligibility and exclusionsEaton Tripp Lite SU5000RTMB SmartOnline 5000VA 4500W 208V Online Double-Conversion UPS with Maintenance Bypass, L6-20R/L6-30R Outlets, L6-30P Input, Network Card Included, 3U Rack / Tower
SU5000RTMB
