Altronix TANGO1B PoE-Driven Power Supply with Lithium Battery Backup, Board
Image of 1
Key Features
- Converts 802.3bt PoE to dependable 12V/24V DC power, removing the need for high-voltage wiring or a licensed electrician
- Integrated LiFePO4 battery charger and single-battery backup for continuous operation during power loss
- Up to 75W output to reliably power access control, locks, readers and small surveillance devices
- Compact board-mount design stacks with Altronix sub-assemblies to maximize enclosure space
- Low-power shutdown and battery supervision protect battery life and prevent deep discharge
- NDAA compliant, RoHS and US-made with lifetime limited warranty for long-term system confidence
Quick Specifications
- Product Model
- TANGO1B
- Sector
- Access Control
- Brand Name
- Altronix
- Product Line
- Tango
Frequently Bought Together
Altronix TANGO1B PoE-Driven Power Supply with Lithium Battery Backup, Board
$363.92
10 items selected
Total: $3,565.42
Explore the details
Product information
TANGO1B
Overview
Deliver reliable, code-compliant power to your access control and security devices without running high-voltage circuits. The Altronix TANGO1B PoE-Driven Power Supply with Lithium Battery Backup is a board-mount power solution that converts IEEE802.3bt (4PPoE) input into stable 12V or 24V DC outputs, providing up to 75W of usable power. Built-in LiFePO4 battery charging and single-battery backup ensure continued operation of locks, readers, sensors and telemetry during outages, while battery supervision and low-power shutdown protect battery lifespan. With an input range of 48–57V and support for common midspans, the TANGO1B simplifies installs, eliminates expensive high-voltage wiring, and saves enclosure space by stacking with compatible Altronix sub-assemblies. Ideal for access control, surveillance and remote monitoring applications, this NDAA-compliant, RoHS-certified board is engineered for dependable, long-term performance. Upgrade legacy power racks or deploy new PoE-powered security systems with confidence—choose the TANGO1B for streamlined installation and resilient backup power.
Features
- Converts 802.3bt PoE to dependable 12V/24V DC power, removing the need for high-voltage wiring or a licensed electrician
- Integrated LiFePO4 battery charger and single-battery backup for continuous operation during power loss
- Up to 75W output to reliably power access control, locks, readers and small surveillance devices
- Compact board-mount design stacks with Altronix sub-assemblies to maximize enclosure space
- Low-power shutdown and battery supervision protect battery life and prevent deep discharge
- NDAA compliant, RoHS and US-made with lifetime limited warranty for long-term system confidence
| General Information | |
|---|---|
| Sector | Access Control |
| Brand Name | Altronix |
| Manufacturer | Altronix Corporation |
| Product Line | Tango |
| Product Name | Tango1B PoE Driven Power Supply with Lithium Battery Backup, Board |
| Product Type | Power Supply |
| Product Model | TANGO1B |
| Product Series | Tango |
| Packaged Quantity | 1 |
| Manufacturer Part Number | TANGO1B |
| Technical Information | |
| Output Voltage | 12V DC, 24V DC |
| Certifications | |
| NDAA Compliant | Yes |
| Environmental Conditions | |
| Storage Temperature (T-T) | -4-158°F |
| Operating Temperature (T-T) | 32-120°F |
| Physical Characteristics | |
| Depth | 7.6" |
| Width | 4.1" |
| Height | 1.3" |
| Weight | 11.20oz |
| Power Description | |
| Output Power | 75W |
| Input Voltage | 48-57V |
| Output Current | 3A, 6.25A |
| Product Information | |
| Mount Type | Board Mount |
| Warranty | |
| Limited Warranty | Lifetime |
| Miscellaneous | |
| Country of Origin | US |
| Environmental Certification | RoHS |
