TRENDnet TI-B541 5-Port Industrial Gigabit PoE++ Powered DIN-Rail Switch with PoE Pass-Through
Image of 5
Key Features
- Deploy where AC power isn't available: PoE++ powered design lets you install the switch in remote or hard-to-reach locations without an AC adapter.
- Reliable device powering: Four Gigabit PoE+ output ports plus a 65W PoE budget provide consistent power for cameras, access points, and VoIP phones.
- Compact, rugged design: IP30-rated metal housing with DIN-rail and wall mounts and an operating range of -40° to 75°C for tough industrial environments.
- PoE pass-through flexibility: One PoE++ input port accepts up to Type 4 (90W) input and passes power downstream to connected devices.
- Secure, standards-based networking: Gigabit performance with Layer 2 switching and IEEE 802.3af/at/bt support for reliable surveillance and security deployments.
- Procurement-ready: NDAA/TAA compliance and TRENDnet lifetime warranty for long-term projects and enterprise procurement peace of mind.
Quick Specifications
- Product Model
- TI-B541
- Brand Name
- TRENDnet
- Product Name
- TI-B541 Ethernet Switch
- Product Type
- Ethernet Switch
Explore the details
Product information
TI-B541
Overview
Quickly add reliable, remote power and Gigabit connectivity for security and surveillance systems with the TRENDnet TI-B541 5-Port Industrial Gigabit PoE++ Powered DIN-Rail Switch. Designed for industrial and edge monitoring applications, this PoE-powered switch needs no AC adapter—ideal for camera towers, outdoor enclosures, and wireless access point installs. The TI-B541 provides one PoE++ input and four Gigabit PoE+ output ports with a 65W PoE budget, enabling you to power multiple IP cameras, VoIP handsets, or wireless devices from a single feed. Built to withstand harsh conditions, its IP30-rated metal housing and -40° to 75°C operating range ensure continuous operation in industrial and transportation environments. With 1 Gbps ports, Layer 2 switching, and PoE pass-through capability, the unit simplifies cabling and reduces the need for local power infrastructure—speeding deployment for security, surveillance, and remote monitoring projects. NDAA/TAA compliance and TRENDnet’s lifetime warranty make it a dependable choice for enterprise and public-sector deployments. Add the TI-B541 to your next security or networking rollout for a compact, rugged PoE solution—ideal for surveillance and industrial networking installations.
Features
- Deploy where AC power isn't available: PoE++ powered design lets you install the switch in remote or hard-to-reach locations without an AC adapter.
- Reliable device powering: Four Gigabit PoE+ output ports plus a 65W PoE budget provide consistent power for cameras, access points, and VoIP phones.
- Compact, rugged design: IP30-rated metal housing with DIN-rail and wall mounts and an operating range of -40° to 75°C for tough industrial environments.
- PoE pass-through flexibility: One PoE++ input port accepts up to Type 4 (90W) input and passes power downstream to connected devices.
- Secure, standards-based networking: Gigabit performance with Layer 2 switching and IEEE 802.3af/at/bt support for reliable surveillance and security deployments.
- Procurement-ready: NDAA/TAA compliance and TRENDnet lifetime warranty for long-term projects and enterprise procurement peace of mind.
| General Information | |
|---|---|
| Brand Name | TRENDnet |
| Manufacturer | TRENDnet |
| Product Name | TI-B541 Ethernet Switch |
| Product Type | Ethernet Switch |
| Product Model | TI-B541 |
| Manufacturer Part Number | TIB541 |
| Technical Information | |
| Material | Metal |
| Power Consumption | 3.90W |
| Media Type Supported | Twisted Pair |
| Maximum Data Transfer Rate | 1 Gbps |
| Certifications | |
| TAA Compliant | Yes |
| NDAA Compliant | Yes |
| Interfaces/Ports | |
| Network (RJ-45) | Yes |
| Total Number of Network Ports | 5 |
| Management & Protocols | |
| Manageable | No |
| Media & Performance | |
| Network Technology | 1000Base-T |
| Network & Communication | |
| Layer Supported | 2 |
| Ethernet Technology | 10 Gigabit Ethernet |
| Networking Standards | IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at, IEEE 802.3bt, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z |
| Physical Characteristics | |
| Depth | 3.1" |
| Width | 4" |
| Height | 1.2" |
| Weight | 5.64oz |
| Power Description | |
| PoE Budget | 65W |
| Power Source | PoE++ |
| PoE (RJ-45) Port | Yes |
| Power over Ethernet (PoE) | Yes |
| Product Information | |
| Mount Type | DIN Rail Mount, Wall Mount |
| Warranty | |
| Limited Warranty | Lifetime |
| Miscellaneous | |
| Country of Origin | TW |
