Tripp Lite TLP606 Protect It! 6-Outlet Surge Protector, 6' Cord, 790 Joules, Diagnostic LED, Light Gray Housing

SKU: TLP606 Eaton Tripp Lite
Image of TC-TLP606
Product images for Tripp Lite TLP606 Protect It! 6-Outlet Surge Protector, 6' Cord, 790 Joules, Diagnostic LED, Light Gray Housing. 9 image(s) available. Click on image to view full size.

Key Features

  • Protects workstations, network appliances and security/surveillance equipment from damaging spikes with a 790J surge rating
  • Six NEMA 5-15R outlets (one widely spaced) and a 6' cord give flexible placement and power for multiple devices without blocking adjacent plugs
  • Diagnostic LED instantly shows protection status so you can verify protection for critical monitoring and networking gear
  • EMI/RFI line noise filtering helps reduce interference that can impact surveillance, VOIP and data equipment performance
  • Integrated 15A circuit breaker with automatic shutoff prevents overloads; backed by a lifetime limited warranty and $20,000 connected equipment insurance (US/Canada)

Quick Specifications

Product Model
TLP606
Brand Name
Eaton Tripp Lite
Product Line
Protect It!
Product Name
6-Outlet Economy Surge Protector
View Full Technical Specifications

Explore the details

Product information

TLP606

Overview

Keep critical workstations, network equipment and security gear protected from damaging power surges with the Eaton Tripp Lite TLP606 Protect It! surge protector. Designed for home offices, small businesses and surveillance/monitoring setups, this compact surge protection module delivers 790 joules of surge energy absorption to guard sensitive electronics and networking hardware. Six grounded NEMA 5-15R outlets — including one spaced to accept bulky transformers — let you power multiple devices without blocking ports, while the 6' cord provides flexible placement in racks, desks or wall-mounted stations.

The TLP606 also filters EMI/RFI line noise to help maintain clean power for cameras, recorders and monitoring equipment. A diagnostic LED clearly indicates protection status and an integrated 15A circuit breaker automatically shuts off to prevent overload damage. Conforming to UL 1449 3rd Edition and backed by a lifetime limited warranty plus $20,000 Ultimate Lifetime Insurance (U.S. & Canada), it’s an economical, reliable choice for protecting surveillance, security and networking investments. Add the Eaton Tripp Lite TLP606 to your workstation, network closet or surveillance rack to safeguard equipment — order now.

Features

  • Protects workstations, network appliances and security/surveillance equipment from damaging spikes with a 790J surge rating
  • Six NEMA 5-15R outlets (one widely spaced) and a 6' cord give flexible placement and power for multiple devices without blocking adjacent plugs
  • Diagnostic LED instantly shows protection status so you can verify protection for critical monitoring and networking gear
  • EMI/RFI line noise filtering helps reduce interference that can impact surveillance, VOIP and data equipment performance
  • Integrated 15A circuit breaker with automatic shutoff prevents overloads; backed by a lifetime limited warranty and $20,000 connected equipment insurance (US/Canada)
23 of 23 specifications
Technical specifications for Tripp Lite TLP606 Protect It! 6-Outlet Surge Protector, 6' Cord, 790 Joules, Diagnostic LED, Light Gray Housing
General Information
Brand Name Eaton Tripp Lite
Manufacturer Eaton
Product Line Protect It!
Product Name 6-Outlet Economy Surge Protector
Product Type Surge Suppressor/Protector
Product Model TLP606
Packaged Quantity 1
Manufacturer Part Number TLP606
Technical Information
Output Voltage 120V AC
Application/Usage Residential
Number of Outlets 6
Interfaces/Ports
Receptacles NEMA 5-15R
Physical Characteristics
Color Gray
Depth 1.2"
Width 1.9"
Height 10.8"
Weight 1.01lb
Power Description
Input Voltage 120V AC
Power Handling 1800VA
Surge Energy Rating 790J
Warranty
Limited Warranty Lifetime
Additional Warranty Information $20,000 Ultimate Lifetime Insurance (USA & Canada Only).
Miscellaneous
Country of Origin CN
