Ubiquiti USW-Pro-Max-48 UniFi 48-Port Layer 3 Etherlighting Switch with 2.5 GbE
Special Order: typically 2–6 weeks
Ships directly from the manufacturer. This is an estimated lead time, not a guaranteed delivery date.
Availability can change and lead times may be longer. If your project has a deadline, check with us before ordering.
A member of our team will check with the manufacturer and personally reply by email.
Image of 7
Key Features
- Power high-performance cameras and access points with a 720W PoE budget and eight 60W PoE++ ports for demanding security and surveillance deployments
- Deliver faster edge throughput via sixteen 2.5GbE RJ45 ports and four 10Gb SFP+ uplinks to support Wi‑Fi 6, NVRs, and high-resolution monitoring
- Reduce deployment time and troubleshooting with UniFi Etherlighting that illuminates port location, link speed, and native VLAN
- Advanced Layer 3 management in UniFi Network for VLANs, static routing, QoS and segmentation—ideal for secure, multi-site networks and monitoring systems
- Rack‑mount, redundant‑ready design built for continuous operation in critical IT and physical security environments
Quick Specifications
- Product Model
- USW-PRO-MAX-48
- Brand Name
- Ubiquiti
- Product Line
- UniFi
- Product Name
- Ubiquiti Networks Pro Max 48 PoE 48-Port 2.5G / 1G PoE++ Compliant Managed Network Switch
Explore the details
Product information
USW-PRO-MAX-48
Overview
Optimize your site network for security, surveillance and enterprise Wi‑Fi with the Ubiquiti USW‑Pro‑Max‑48 managed switch. This UniFi 48‑port Layer 3 switch combines a 720W PoE budget and high‑power PoE++ ports to reliably power IP cameras, access points and monitoring appliances without extra injectors. Sixteen 2.5GbE RJ45 ports provide increased uplink capacity at the edge, while four 10Gb SFP+ ports enable high‑speed aggregation to core switches or NVRs. UniFi Etherlighting makes rack installs and troubleshooting faster by visually identifying port location, link speed and native VLAN, saving valuable time for IT and security teams. Managed through UniFi Network (v8.0.24+), the USW‑Pro‑Max‑48 supports VLAN segmentation, QoS and Layer 3 routing for secure, resilient deployments across campuses, retail or enterprise sites. Rack‑mountable and DC backup‑ready, it’s built for always‑on infrastructure. Ideal for powering and connecting surveillance systems, access control, and high‑density Wi‑Fi deployments—contact sales or add to your configuration to upgrade your network backbone.
Features
- Power high-performance cameras and access points with a 720W PoE budget and eight 60W PoE++ ports for demanding security and surveillance deployments
- Deliver faster edge throughput via sixteen 2.5GbE RJ45 ports and four 10Gb SFP+ uplinks to support Wi‑Fi 6, NVRs, and high-resolution monitoring
- Reduce deployment time and troubleshooting with UniFi Etherlighting that illuminates port location, link speed, and native VLAN
- Advanced Layer 3 management in UniFi Network for VLANs, static routing, QoS and segmentation—ideal for secure, multi-site networks and monitoring systems
- Rack‑mount, redundant‑ready design built for continuous operation in critical IT and physical security environments
| General Information | |
|---|---|
| Brand Name | Ubiquiti |
| Manufacturer | Ubiquiti Inc. |
| Product Line | UniFi |
| Product Name | Ubiquiti Networks Pro Max 48 PoE 48-Port 2.5G / 1G PoE++ Compliant Managed Network Switch |
| Product Type | Network Switch |
| Product Model | USW-PRO-MAX-48 |
| Product Series | USW Pro Max |
| Manufacturer Part Number | USW-PRO-MAX-48 |
| Technical Information | |
| Material | SGCC Steel |
| Power Consumption | 100W |
| I/O Expansions | |
| Number of SFP+ Slots | 4 |
| Interfaces/Ports | |
| Network (RJ-45) | Yes |
| Total Number of Network Ports | 48 |
| Management & Protocols | |
| Manageable | Yes |
| Network & Communication | |
| Layer Supported | 3 |
| Ethernet Technology | 10 Gigabit Ethernet |
| Physical Characteristics | |
| Weight | 10.8lb |
| Power Description | |
| Frequency | 50 Hz, 60 Hz |
| Power Source | AC, DC |
| Input Voltage | 100-240V AC |
| Product Information | |
| Mount Type | Rack Mount |
| Warranty | |
| Limited Warranty | 1-Year |
| Miscellaneous | |
| Features | (16) 2.5 GbE RJ45 ports, (32) GbE RJ45 ports, (4) 10G SFP ports, DC power backup ready, Etherlighting ports that illuminate to indicate port location, speed/link, and native VLAN/network, Managed with UniFi Network 8.0.24 and later, Pair with UniFi Etherlighting Patch Cables for optimal brightness. |
No matching specifications
Try a different term, such as a connector type or resolution.
Plan your purchase
Is this right for your project?
Confirm the model, required accessories and delivery needs before ordering.
- SKU:
- USW-PRO-MAX-48
- Manufacturer part:
- USW-PRO-MAX-48
How do I confirm compatibility?
Check the specifications and manufacturer documents for your existing system. Send us your model numbers and project requirements if you need help selecting equipment or accessories.
Ask a product specialistWhen will this item ship?
Availability is shown above. Special-order items and project quantities may need additional lead time. Contact us to confirm a delivery date before scheduling installation.
Shipping, freight and delivery detailsWhat should I know about returns?
Returns require an approved RMA. Consult the linked return policy for deadlines and eligibility. For standard non-defective returns, eligible factory-sealed items carry a 15% restocking fee and customer-paid return shipping; open-box and used items are refused. Defective and DOA claims follow the policy's separate terms. Special orders and other exclusions are final sale.
Read return eligibility and exclusionsUbiquiti USW-Pro-Max-48 UniFi 48-Port Layer 3 Etherlighting Switch with 2.5 GbE
USW-PRO-MAX-48
