Vigitron Vi22401U MaxiiPower 1-Port PoE Midspan with Built-In Power Supply, 60W

SKU: VI22401U Vigitron
Vigitron Vi22401U MaxiiPower 1-Port 60W IEEE 802.3bt PoE Midspan with Built-In Power Supply
Product images for Vigitron Vi22401U MaxiiPower 1-Port PoE Midspan with Built-In Power Supply, 60W. 5 image(s) available. Click on image to view full size.

Key Features

  • Powers high-performance PoE devices up to 60W so you can deploy megapixel cameras and wireless APs without separate power infrastructure
  • Built-in 65W universal power supply and Gigabit Ethernet deliver reliable, high-throughput connectivity for surveillance and monitoring systems
  • Rugged, compact power brick tolerates -20°C to 50°C for easy installation in outdoor enclosures and harsh environments
  • Automatic PD detection, over-current protection and built-in surge protection reduce downtime and protect your security network
  • Simplifies installation and lowers total cost of ownership by centralizing power delivery for single-port PoE applications

Quick Specifications

Product Model
Vi22401U
Brand Name
Vigitron
Product Line
MaxiiPower
Product Name
Single Port 60W IEEE 802.3bt PoE Midspan
View Full Technical Specifications

Explore the details

Product information

VI22401U

Overview

Deliver reliable, high-power PoE to critical security and surveillance devices with the Vigitron Vi22401U PoE Midspan injector. Designed for CCTV, IP camera and remote monitoring deployments, this single-port midspan supplies up to 60W per port (IEEE 802.3bt / 802.3af/at compatible) using a built-in 65W universal power supply and full Gigabit Ethernet throughput. That means you can power high-megapixel cameras and UPoE-capable equipment without sacrificing network performance. The compact power-brick design and wide operating range (-20°C to 50°C) make the Vi22401U ideal for weatherproof enclosures and outdoor installations, while automatic PD sensing, over-current protection and integrated surge protection safeguard your investment and reduce maintenance. Easy to integrate and TAA status noted, this midspan minimizes infrastructure complexity and lowers deployment costs for IT and security teams. Perfect for retail, transportation, campus and city surveillance projects—add the Vigitron Vi22401U to your next monitoring or access control rollout to streamline power delivery and improve system reliability.

Features

  • Powers high-performance PoE devices up to 60W so you can deploy megapixel cameras and wireless APs without separate power infrastructure
  • Built-in 65W universal power supply and Gigabit Ethernet deliver reliable, high-throughput connectivity for surveillance and monitoring systems
  • Rugged, compact power brick tolerates -20°C to 50°C for easy installation in outdoor enclosures and harsh environments
  • Automatic PD detection, over-current protection and built-in surge protection reduce downtime and protect your security network
  • Simplifies installation and lowers total cost of ownership by centralizing power delivery for single-port PoE applications
26 of 26 specifications
Technical specifications for Vigitron Vi22401U MaxiiPower 1-Port PoE Midspan with Built-In Power Supply, 60W
General Information
Brand Name Vigitron
Manufacturer Vigitron, Inc
Product Line MaxiiPower
Product Name Single Port 60W IEEE 802.3bt PoE Midspan
Product Type PoE Injector
Product Model Vi22401U
Country of Origin CN
Packaged Quantity 1
Manufacturer Part Number VI22401U
Certifications
TAA Compliant No
Interfaces/Ports
Input Ports Gigabit Ethernet, IEC 60320 C14
Output Ports Gigabit Ethernet
Physical Characteristics
Color Black
Width 2.60"
Height 1.90"
Weight 15.20oz
Material Extruded Aluminum
Form Factor Power Brick
Power Description
Input Voltage 120V AC, 230V AC
Maximum Output Power 60.00W
Maximum Output Voltage 54V
Product Information
Length 6.20"
Protection Type Over Current, Surge Protection
Product Replacements & Other Alternatives
Model Number Replaces VI22401
Miscellaneous
Environmentally Friendly Yes
Environmental Certification RoHS, WEEE
