Vigitron VI30208U Hardened Managed 12-Port, L2+, 90W PoE, 1G Industrial Ring Switch
Special Order: typically 2–6 weeks
Ships directly from the manufacturer. This is an estimated lead time, not a guaranteed delivery date.
Availability can change and lead times may be longer. If your project has a deadline, check with us before ordering.
A member of our team will check with the manufacturer and personally reply by email.
Image of 4
Key Features
- Deliver reliable, high-power PoE to demanding devices (up to 90W per port, 480W total) so PTZ and multi-sensor cameras never lose power.
- Hardened industrial design with -40°C to 75°C operation and 6kV surge protection to keep security and surveillance networks running in harsh environments.
- Rapid Ring (G.8032 V1/V2) and dual power inputs provide fast failover and uninterrupted uptime for critical monitoring applications.
- Gigabit and 2.5G fiber uplinks plus 22 Gbps switch fabric ensure smooth, low-latency video transport for high-megapixel cameras.
- Built-in PoE monitoring, auto recheck and programmable startup delay simplify remote maintenance and automatic recovery of connected devices.
Quick Specifications
- Product Model
- VI30208U
- Brand Name
- Vigitron
- Product Line
- MaxiiNet
- Product Type
- Ethernet Switch
Explore the details
Product information
VI30208U
Overview
For mission-critical security and surveillance deployments, the Vigitron VI30208U Hardened Managed 12-Port L2+ PoE Industrial Ring Switch delivers dependable power and resilient network performance. Designed for outdoor and industrial monitoring, this Vigitron network switch supplies up to 90W per port on six ports with a 480W PoE budget—ideal for PTZ and high-power cameras—while jumbo frame support and a 22 Gbps switch fabric ensure smooth transmission of high-megapixel video. Hardened aluminum construction, -40°C to 75°C operating range, dual 48–57V DC inputs and 6kV port surge protection mean your security system stays online in extreme conditions. Advanced features like PoE port monitoring, auto recheck, programmable startup delay and G.8032 V1/V2 Rapid Ring protocol provide fast failover and simplified remote management for continuous monitoring. With flexible 1G copper and 1G/2.5G fiber uplinks, the VI30208U integrates easily into modern surveillance networks and access control systems. Deploy the VI30208U where uptime matters most—city surveillance, transportation hubs, industrial sites and critical infrastructure. Contact us or order now to harden and power your security network.
Features
- Deliver reliable, high-power PoE to demanding devices (up to 90W per port, 480W total) so PTZ and multi-sensor cameras never lose power.
- Hardened industrial design with -40°C to 75°C operation and 6kV surge protection to keep security and surveillance networks running in harsh environments.
- Rapid Ring (G.8032 V1/V2) and dual power inputs provide fast failover and uninterrupted uptime for critical monitoring applications.
- Gigabit and 2.5G fiber uplinks plus 22 Gbps switch fabric ensure smooth, low-latency video transport for high-megapixel cameras.
- Built-in PoE monitoring, auto recheck and programmable startup delay simplify remote maintenance and automatic recovery of connected devices.
| General Information | |
|---|---|
| Brand Name | Vigitron |
| Product Line | MaxiiNet |
| Product Type | Ethernet Switch |
| Manufacturer Part Number | VI30208U |
| Technical Information | |
| Power Consumption | 6.0000W |
| Physical Characteristics | |
| Width | 6.60" |
| Height | 2.00" |
| Weight | 1.90lb |
| Material | Aluminum |
| Power Description | |
| Input Voltage | 48-57V DC |
| Product Information | |
| Length | 4.40" |
| Mount Type | Desktop Mount, DIN Rail Mount |
| Product Replacements & Other Alternatives | |
| Model Number Replaces | VI30208 |
| Miscellaneous | |
| Features | 4 x 1G PoE copper, 2 x independent copper, 2 x 1G/2.5G independent Fiber uplink ports, 90W IEEE 802.3bt compliant PoE on 6 ports, 480W PoE budget, IEEE 802.3bt class 0-8 PoE up to 90W per port, Jumbo frame programing at all bandwidth settings, Redundant 48-57V DC up to 500W back up power input |
| Environmentally Friendly | Yes |
| Environmental Certification | CE, FCC, RoHS, WEEE |
