3xLOGIC VX-5M20-B-RIAW-S256 VISIX 5MP Outdoor Bullet Camera with Remote Focus, IR, 6-50mm Lens, 256GB
Special Order: typically 2–6 weeks
Ships directly from the manufacturer. This is an estimated lead time, not a guaranteed delivery date.
Availability can change and lead times may be longer. If your project has a deadline, check with us before ordering.
A member of our team will check with the manufacturer and personally reply by email.
Image of 2
Key Features
- Evidence-grade 5MP imaging (2592 x 1944) for reliable identification and incident review
- Remote-focus 6–50mm varifocal lens with 8.3x optical zoom to speed installation and precisely frame targets
- IR night vision to ~164 ft and 0 lux capability for continuous 24/7 monitoring in low light
- Rugged IP67 / IK09 housing built for outdoor, weatherproof and vandal-resistant security deployments
- Onboard 256GB storage plus VIGIL compatibility for local recording, redundancy and simplified system management
- PoE networking and native support for VIGIL software reduce installation complexity and centralize surveillance operations
Quick Specifications
- Product Model
- VX-5M20-B-RIAW
- Brand Name
- 3xLOGIC
- Product Line
- VISIX
- Product Name
- VISIX 5MP Outdoor Bullet with Remote Focus (6-50mm)
Frequently Bought Together
3xLOGIC VX-5M20-B-RIAW-S256 VISIX 5MP Outdoor Bullet Camera with Remote Focus, IR, 6-50mm Lens, 256GB
$1,051.40
4 items selected
Total: $3,040.51
Explore the details
Product information
VX-5M20-B-RIAW-S256
Overview
Deliver uninterrupted, high-detail outdoor surveillance with the 3xLOGIC VISIX VX-5M20-B-RIAW 5MP outdoor bullet camera. Built for commercial security and critical monitoring, this network camera captures evidence-grade 2592 x 1944 resolution while the 6–50mm varifocal lens (8.3x optical zoom) and remote-focus capability let integrators precisely frame scenes without re-ladding or hardware swaps. Nighttime threats are addressed with integrated IR illumination reaching approximately 164 feet and 0 lux performance for true day/night operation.
Designed for real-world deployments, the VX-5M20 is IP67 and IK09 rated to resist weather and tampering, and supports PoE for streamlined wiring. Onboard 256GB storage and optional VIGIL Server functionality provide local recording and failover redundancy, while native VIGIL Client and View Lite II mobile access simplify remote health monitoring and video retrieval. H.264/H.265 streaming and smart detection features reduce bandwidth and cut false alerts, making it ideal for perimeter protection, parking lots, retail and transportation hubs.
Choose the VX-5M20 for dependable, high-resolution outdoor security—contact us to specify this camera for your next surveillance project.
Features
- Evidence-grade 5MP imaging (2592 x 1944) for reliable identification and incident review
- Remote-focus 6–50mm varifocal lens with 8.3x optical zoom to speed installation and precisely frame targets
- IR night vision to ~164 ft and 0 lux capability for continuous 24/7 monitoring in low light
- Rugged IP67 / IK09 housing built for outdoor, weatherproof and vandal-resistant security deployments
- Onboard 256GB storage plus VIGIL compatibility for local recording, redundancy and simplified system management
- PoE networking and native support for VIGIL software reduce installation complexity and centralize surveillance operations
| General Information | |
|---|---|
| Brand Name | 3xLOGIC |
| Manufacturer | 3xLOGIC Inc. |
| Product Line | VISIX |
| Product Name | VISIX 5MP Outdoor Bullet with Remote Focus (6-50mm) |
| Product Type | Network Camera |
| Product Model | VX-5M20-B-RIAW |
| Manufacturer Part Number | VX-5M20-B-RIAW-S256 |
| Technical Information | |
| Lens Type | Varifocal |
| Night Vision | Yes |
| Optical Zoom | 8.3x |
| Field of View | Diagonal, Horizontal, Vertical |
| Video Formats | H.264, H.265, MJPEG |
| Maximum Aperture | f/1.6 |
| Night Vision Type | Infrared |
| Maximum Frame Rate | 30fps |
| Minimum Focal Length | 6mm |
| Connectivity Technology | Wired |
| Field of View (Vertical) | 24.3° |
| Field of View (Horizontal) | 44.8° |
| Effective Camera Resolution | 5MP |
| Camera | |
| Image Sensor Type | CMOS |
| Wide Dynamic Range | Yes |
| Night Vision Distance | 164.04 ft |
| Certifications | |
| Ingress Protection Rating | IP67 |
| Display & Graphics | |
| Maximum Video Resolution | 2592 x 1944 |
| Environmental Conditions | |
| Operating Humidity | 0.9 |
| Maximum Operating Temperature | 122°F (50°C) |
| Minimum Operating Temperature | -40°F (-40°C) |
| Exposure | |
| Minimum Illumination | 0.06 lux |
| Longest Shutter Speed | 1/15 Second |
| Shortest Shutter Speed | 1/32000 Second |
| Interfaces/Ports | |
| Network (RJ-45) | Yes |
| Lens | |
| Focal Length | 50mm |
| Lens Included | Yes |
| Maximum Focal Length | 50mm |
| Network & Communication | |
| Remote Management | Yes |
| Physical Characteristics | |
| Color | Color |
| Depth | 9.7" |
| Height | 3.8" |
| Weight | 1.98lb |
| Durability | Dust Resistant, Impact Resistant, Vandal Resistant, Waterproof, Weather Resistant, Weatherproof |
| Form Factor | Bullet |
| Power Description | |
| Input Voltage | 12V DC |
| Product Information | |
| Mount Type | Junction Box Mount, Pole Mount |
| Storage | |
| Storage Type | Memory Card/Cloud |
| Recording Formats | HD |
| Video | |
| Maximum Resolution | 1280 x 720 |
| Analog Video Signal Format | CVBS |
| Warranty | |
| Limited Warranty | 4-Year |
| Miscellaneous | |
| Features | Alarm Triggering, Day/Night, Motion Detection, SD Card Local Storage, Smart Object Detection, Tamper Detection, Video Management System, Wide Dynamic Range |
| Indoor/Outdoor | Outdoor |
| Country of Origin | VN |
| Environmentally Friendly | Yes |
| Impact Protection Rating | IK09 |
| Environmental Certification | CE, FCC, UL |
