Hanwha XNB-8003/KEX Series 6MP AI Box IP Camera, Lens Not Included, Black, TAA Compliant
Special Order Item
This item is available by special order. Lead times may vary. Please contact us for availability and estimated delivery.
Key Features
- AI-driven analytics (person, vehicle, face, license plate) reduce false alarms and speed incident response
- 6MP resolution with 0.003 lux low-light sensitivity and 120dB WDR for clear, actionable surveillance day or night
- H.265 + WiseStream III reduce bandwidth and storage costs without sacrificing image detail for long-term monitoring
- C-/CS-mount box design lets integrators choose lenses to match focal length needs (lens not included)
- TAA-compliant build and rugged operating range for government, enterprise and critical infrastructure deployments
Quick Specifications
- Product Model
- XNB-8003/KEX
- Brand Name
- Hanwha Vision
- Product Name
- 6MP Box AI Camera
- Product Type
- Box Camera
Product Information Tabs
Overview
Optimize perimeter and facility surveillance with the Hanwha Vision XNB-8003/KEX 6MP AI box camera. Built for professional security and monitoring, this box camera combines a 6MP sensor, industry-leading low-light sensitivity (down to 0.003 lux) and 120dB WDR so operators get clear, usable video in challenging lighting. The onboard NPU runs deep-learning analytics in real time to accurately detect and classify people, vehicles, faces and license plates—significantly reducing nuisance alarms from shadows, weather or animals.
Delivering H.265 video and WiseStream III compression, the XNB-8003/KEX minimizes network and storage load while preserving critical evidence quality. The C-/CS-mount housing supports manual lenses (lens not included), giving integrators the flexibility to tailor FOV and focal length to each installation. With RJ-45 network connectivity, TF card storage support, TAA compliance and a 3-year limited warranty, this Hanwha Vision box camera is ideal for government, retail, campus and industrial surveillance systems. Contact your rep to specify the XNB-8003/KEX for your next security or monitoring project.
Features
- AI-driven analytics (person, vehicle, face, license plate) reduce false alarms and speed incident response
- 6MP resolution with 0.003 lux low-light sensitivity and 120dB WDR for clear, actionable surveillance day or night
- H.265 + WiseStream III reduce bandwidth and storage costs without sacrificing image detail for long-term monitoring
- C-/CS-mount box design lets integrators choose lenses to match focal length needs (lens not included)
- TAA-compliant build and rugged operating range for government, enterprise and critical infrastructure deployments
| General Information | |
|---|---|
| Brand Name | Hanwha Vision |
| Manufacturer | Hanwha Vision |
| Product Name | 6MP Box AI Camera |
| Product Type | Box Camera |
| Product Model | XNB-8003/KEX |
| Product Series | X |
| Manufacturer Part Number | XNB-8003/KEX |
| Technical Information | |
| Lens Type | Manual |
| Video Formats | H.264, H.265, MJPEG |
| Lens Mount Type | C-Mount, CS-Mount |
| Maximum Aperture | f/1.2 |
| Maximum Frame Rate | 30fps |
| Connectivity Technology | Wired |
| Effective Camera Resolution | 6MP |
| Camera | |
| Image Sensor Type | CMOS |
| Wide Dynamic Range | Yes |
| Certifications | |
| TAA Compliant | Yes |
| Display & Graphics | |
| Maximum Video Resolution | 3328 x 1872 |
| Environmental Conditions | |
| Operating Humidity | 95% RH (Non-condensing) |
| Maximum Operating Temperature | 131°F |
| Minimum Operating Temperature | -14°F |
| Exposure | |
| Minimum Illumination | 0.003 lux |
| Longest Shutter Speed | 1/12000 Second |
| Shortest Shutter Speed | 2 Second |
| Interfaces/Ports | |
| Network (RJ-45) | Yes |
| Lens | |
| Lens Included | Yes |
| Network & Communication | |
| Remote Management | Yes |
| Physical Characteristics | |
| Color | Black |
| Depth | 6.48" |
| Width | 3.19" |
| Height | 2.64" |
| Weight | 1.94lb |
| Power Description | |
| Input Voltage | 12V DC |
| Product Information | |
| Mount Type | Box Mount |
| Storage | |
| Storage Type | Memory Card |
| Video | |
| Maximum Resolution | 1280 x 720 |
| Analog Video Signal Format | CVBS |
| Warranty | |
| Limited Warranty | 3-Year |
| Miscellaneous | |
| Features | Back Light Compensation (BLC), Day/Night, Defog, Digital Noise Reduction, Face Detection, Fog Reduction, Highlight Compensation (HLC), Motion Detection, Privacy Masking, Shock Detection, Tamper Detection, Vehicle Detection, Wide Dynamic Range |
| Country of Origin | KR |
