AXIS M7104 4-Channel Video Encoder with Zipstream
Image of 1
Key Features
- Migrate analog cameras to IP quickly: convert up to four analog channels to network video for centralized surveillance and monitoring
- Lower bandwidth and storage costs: Zipstream with H.264/H.265 reduces network load and storage requirements without sacrificing image quality
- Reliable edge recording and analytics: built-in memory card slot plus support for motion detection and active tampering alarms for continuous protection
- Simplified installation and control: PoE support and RS-485/422 PTZ control make deployment and camera management fast and cost-effective
- Secure, standards-based integration: signed firmware, secure boot, ONVIF compatibility, and TAA/NDAA compliance for trusted, enterprise and government deployments
Quick Specifications
- Product Model
- M7104
- Brand Name
- AXIS Communications
- Product Line
- M
- Product Name
- AXIS M7104
Frequently Bought Together
AXIS M7104 4-Channel Video Encoder with Zipstream
$390.22
3 items selected
Total: $1,109.91
Explore the details
Product information
01679-001
Overview
Designed to bring IP benefits to existing analog systems, the Axis Communications AXIS M7104 4-channel video encoder delivers efficient, secure surveillance and remote monitoring for businesses and critical infrastructure. The encoder converts four standard-resolution analog cameras to IP streams, supporting a maximum resolution of 720 x 576 at up to 30 fps, and provides PTZ control over RS-485/422 for versatile camera management. With Zipstream technology and support for H.264/H.265, the M7104 dramatically reduces bandwidth and storage requirements—helping you cut operational costs without compromising image quality.
Built for real-world deployments, the unit includes edge storage via a memory card slot and enables intelligent analytics such as motion detection and active tampering alarm to enhance situational awareness. PoE simplifies cabling and installation, while signed firmware and secure boot protect device integrity. ONVIF compatibility ensures seamless integration with VMS and network systems. Ideal for retail, education, transportation, and government sites, the AXIS M7104 is a cost-effective path to modernize analog estates. Contact sales to specify the encoder for your next security or surveillance project.
Features
- Migrate analog cameras to IP quickly: convert up to four analog channels to network video for centralized surveillance and monitoring
- Lower bandwidth and storage costs: Zipstream with H.264/H.265 reduces network load and storage requirements without sacrificing image quality
- Reliable edge recording and analytics: built-in memory card slot plus support for motion detection and active tampering alarms for continuous protection
- Simplified installation and control: PoE support and RS-485/422 PTZ control make deployment and camera management fast and cost-effective
- Secure, standards-based integration: signed firmware, secure boot, ONVIF compatibility, and TAA/NDAA compliance for trusted, enterprise and government deployments
| General Information | |
|---|---|
| Brand Name | AXIS Communications |
| Manufacturer | Axis Communications |
| Product Line | M |
| Product Name | AXIS M7104 |
| Product Type | Video encoders |
| Product Model | M7104 |
| Product Series | M71 |
| Application/Usage | Video Encoding |
| Country of Origin | PL |
| Manufacturer Part Number | 01679-001 |
| Technical Information | |
| Video Formats | H.264 / AVC, H.265 / HVEC |
| Maximum Frame Rate | 30fps |
| Certifications | |
| TAA Compliant | Yes |
| Certifications | EN 55024, EN 55032 Class A, EN 61000-3-2, EN 61000-3-3, EN 61000-6-1, EN 61000-6-2, FCC Part 15 Subpart B Class A, ICES-3(A)/NMB-3(A), KC KN32 Class A, KC KN35, RCM AS/NZS CISPR 32 Class A, VCCI Class A |
| NDAA Compliant | Yes |
| Certifications & Standards | ONVIF G, ONVIF M, ONVIF S, ONVIF T |
| Display & Graphics | |
| Maximum Video Resolution | 720 x 576 |
| Environmental Conditions | |
| Operating Temperature (T-T) | 0-50°C |
| Product Replacements & Other Alternatives | |
| Model Number Replaces | 0415-004, 0415-021, 0415-044 |
| Miscellaneous | |
| Environmental Certification | IEC 60068-2-1, IEC 60068-2-14, IEC 60068-2-2, IEC 60068-2-27, IEC 60068-2-6, IEC 60068-2-78 |
