AXIS 30W Outdoor Ready IP66-/IP67-Rated Midspan
Image of 1
Key Features
- Reliable outdoor PoE delivery: supplies up to 30W per port so security cameras and network devices run continuously without needing local power.
- Rugged, weatherproof design: IP66/67 and NEMA 4X rating protect equipment from rain, dust and harsh environments for long-term outdoor deployments.
- Built-in surge protection: AC and PoE surge protection (up to 6 kV) reduces downtime and equipment damage from outdoor electrical events.
- Broad compatibility and standards support: IEEE 802.3af/at compliance enables seamless integration with Axis and third-party surveillance, monitoring and networking gear.
- Flexible mounting and extreme-temp operation: pole or wall mount options and -40 to 149°F range simplify installation across transportation, perimeter security and remote sites.
Quick Specifications
- Product Model
- 30W
- Brand Name
- AXIS Communications
- Product Name
- AXIS 30W OUTDOOR MIDSPAN
- Product Type
- Power over Ethernet
Frequently Bought Together
AXIS 30W Outdoor Ready IP66-/IP67-Rated Midspan
$297.55
10 items selected
Total: $2,837.55
Explore the details
Product information
01944-001
Overview
Deliver reliable outdoor power to networked security and surveillance devices with the AXIS 30W Outdoor Ready IP66-/IP67-Rated Midspan. Designed by Axis Communications as a purpose-built PoE device, this midspan injects up to 30W of power over Ethernet to cameras, access points and other monitoring gear without replacing existing switches. The IP66/67 and NEMA 4X enclosure withstands rain, dust and corrosive conditions while an extended operating range (-40 to 149°F) supports installations in extreme climates. Compatible with IEEE 802.3af and 802.3at standards, the midspan interoperates with Axis and third-party PoE equipment for straightforward integration into security and networking projects. Integrated surge protection on both AC and PoE ports (protection up to 6kV) mitigates outdoor surge risks and helps maintain uptime for critical monitoring systems. With pole and wall-mount options and railway compliance for transit environments, this midspan is ideal for perimeter security, traffic monitoring and remote surveillance sites. Specify the AXIS 30W Outdoor Midspan to simplify outdoor PoE deployments and protect your investment — contact your Axis reseller or order today.
Features
- Reliable outdoor PoE delivery: supplies up to 30W per port so security cameras and network devices run continuously without needing local power.
- Rugged, weatherproof design: IP66/67 and NEMA 4X rating protect equipment from rain, dust and harsh environments for long-term outdoor deployments.
- Built-in surge protection: AC and PoE surge protection (up to 6 kV) reduces downtime and equipment damage from outdoor electrical events.
- Broad compatibility and standards support: IEEE 802.3af/at compliance enables seamless integration with Axis and third-party surveillance, monitoring and networking gear.
- Flexible mounting and extreme-temp operation: pole or wall mount options and -40 to 149°F range simplify installation across transportation, perimeter security and remote sites.
| General Information | |
|---|---|
| Brand Name | AXIS Communications |
| Manufacturer | Axis Communications |
| Product Name | AXIS 30W OUTDOOR MIDSPAN |
| Product Type | Power over Ethernet |
| Product Model | 30W |
| Manufacturer Part Number | 01944-001 |
| Certifications | |
| NDAA Compliant | Yes |
| Ingress Protection Rating | IP67 |
| Environmental Conditions | |
| Operating Temperature (T-T) | -40-65°C |
| Interfaces/Ports | |
| Input Ports | 10/100/1000Base-T |
| Output Ports | PoE |
| Management & Protocols | |
| Security Features | GS-Mark, IEC/EN 60950-1, IEC/EN 60950-22, IEC/EN 62368-1, UL 60950-1, UL 60950-22 |
| Others | |
| Model Number Replaces | 5030-231, 5030-234 |
| Physical Characteristics | |
| Depth | 5.5" |
| Width | 6.7" |
| Height | 2.4" |
| Weight | 3.09lb |
| Form Factor | Pole Mount, Wall Mount |
| Power Description | |
| PoE Budget | 30W |
| Input Voltage | 120V AC, 230V AC |
| Maximum Frequency | 60 Hz |
| Minimum Frequency | 50Hz |
| Maximum Output Power | 30W |
| Maximum Output Voltage | 54 V DC |
| Power over Ethernet (PoE) | Yes |
| Product Information | |
| Mount Type | Pole Mount, Wall Mount |
| Protection Type | Surge Protection |
| Warranty | |
| Limited Warranty | 3-Year |
| Miscellaneous | |
| Certifications | EAC, EN 55024, EN 55032 Class B, EN 61000-3-2, EN 61000-3-3, EN 61000-6-1, EN 61000-6-2, FCC Part 15 Subpart B Class B, ICES-3(B)/NMB-3(B), RCM AS/NZS CISPR 32 Class B, VCCI Class B |
| Country of Origin | CN |
| Environmental Certification | IEC/EN 60529 IP67, NEMA 250 Type 4X |
