System Sensor 2W-B Photoelectric i3 Series Smoke Detector, 2-Wire, White
Image of 4
Key Features
- Simplifies installation with plug-in i3 base and Stop-Drop N Lock, allowing pre-wired bases to reduce labor and wiring errors
- Reduces nuisance alarms using photoelectric sensing plus drift compensation and smoothing algorithms for reliable detection
- Speeds maintenance and inspection with wide-angle dual-color LEDs, onboard test switch, EZ Walk loop testing and remote maintenance signaling
- Flexible mounting to octagonal, 4-square, single-gang back boxes or direct ceiling mount (5" diameter, 2" height) for versatile deployments
- UL 268 listed, 2-wire 24V connectivity for seamless integration into fire alarm, security and monitoring systems
Quick Specifications
- Product Model
- 2W-B
- Brand Name
- System Sensor
- Product Name
- i3 2W-B Smoke Detector
- Product Type
- Smoke Detector
Frequently Bought Together
System Sensor 2W-B Photoelectric i3 Series Smoke Detector, 2-Wire, White
$53.77
7 items selected
Total: $370.94
Explore the details
Product information
2W-B
Overview
Built for commercial fire detection and security monitoring, the System Sensor 2W-B Photoelectric i3 smoke detector streamlines installation, reduces false alarms and simplifies ongoing maintenance. The i3 plug-in design lets technicians pre-wire bases and secure the head with the Stop-Drop N Lock attachment, accelerating installs on 2-wire, 24V systems. The photoelectric sensing chamber—backed by drift compensation and smoothing algorithms—minimizes nuisance alarms from dust or steam, improving reliability for surveillance and life-safety systems.
Serviceability is a priority: wide-angle red/green LEDs provide instant condition checks, an onboard test switch supports quick functional tests, and EZ Walk loop testing (with i3-capable panels or the 2W-MOD2 module) verifies loop wiring. Remote maintenance signaling and simplified sensitivity readout make compliance and monitoring easier for building managers and security integrators. UL 268 listing and multiple mounting options ensure code-compliant deployment in offices, schools, healthcare and retail environments.
Choose the System Sensor 2W-B for dependable photoelectric detection in integrated security and monitoring systems — order today or contact us to specify for your next project.
Features
- Simplifies installation with plug-in i3 base and Stop-Drop N Lock, allowing pre-wired bases to reduce labor and wiring errors
- Reduces nuisance alarms using photoelectric sensing plus drift compensation and smoothing algorithms for reliable detection
- Speeds maintenance and inspection with wide-angle dual-color LEDs, onboard test switch, EZ Walk loop testing and remote maintenance signaling
- Flexible mounting to octagonal, 4-square, single-gang back boxes or direct ceiling mount (5" diameter, 2" height) for versatile deployments
- UL 268 listed, 2-wire 24V connectivity for seamless integration into fire alarm, security and monitoring systems
| General Information | |
|---|---|
| Brand Name | System Sensor |
| Manufacturer | Honeywell International, Inc |
| Product Name | i3 2W-B Smoke Detector |
| Product Type | Smoke Detector |
| Product Model | 2W-B |
| Product Series | i3 |
| Country of Origin | MX |
| Manufacturer Part Number | 2WB |
| Technical Information | |
| Sensor Type | Photoelectric |
| Detectable Medium | Fire |
| Sensing Technology | Photoelectric |
| Connectivity Technology | Wired |
| Certifications | |
| UL Listed | Yes |
| Certifications | UL 268 |
| Controls/Indicators | |
| Status Indicators | Yes |
| Physical Characteristics | |
| Color | White |
| Height | 2.00" |
| Form Factor | Ceiling Mount |
| Power Description | |
| Input Voltage | 24V DC |
| Product Information | |
| Diameter | 5.00" |
| Mount Type | Ceiling Mount |
| Miscellaneous | |
| Features | 85 dB sounder, Drift compensation and smoothing algorithms, Dual-color LEDs, Flexible mounting options, Form C relay, In-line terminals, Isolated thermal sensor, Plug-in design (base included), Remote maintenance signaling, Removable cover and chamber, Simplified sensitivity measurement, Stop-Drop N Lock attachment to the base |
