Intellinet 508261 Industrial 8-Port Gigabit Ethernet PoE+ Switch with 2 SFP Ports, IP40-Rated Metal Housing, DIN-Rail Mount
Special Order Item
This item is available by special order. Lead times may vary. Please contact us for availability and estimated delivery.
Image of 4
Key Features
- Simplifies deployments by delivering data and up to 240W PoE power to eight devices, reducing cabling and installation time for security and surveillance systems.
- Rugged IP40 metal housing and wide -40 to 75°C operating range ensure reliable, continuous operation in harsh industrial and outdoor monitoring environments.
- Two SFP uplinks provide flexible fiber connectivity for long-distance links and network segmentation, future-proofing your infrastructure.
- DIN-rail mountable slim design saves cabinet space and enables quick installation and maintenance in control rooms and enclosures.
- Redundant DC inputs and industrial-grade components increase uptime and provide stable power to cameras, access control, and IoT devices critical to business operations.
Quick Specifications
- Product Model
- 508261
- Brand Name
- Intellinet
- Manufacturer Part Number
- 508261
Frequently Bought Together
Intellinet 508261 Industrial 8-Port Gigabit Ethernet PoE+ Switch with 2 SFP Ports, IP40-Rated Metal Housing, DIN-Rail Mount
$292.72
3 items selected
Total: $470.30
Product Information Tabs
Overview
Built for mission-critical security, surveillance and industrial monitoring, the Intellinet 508261 Industrial 8-Port Gigabit Ethernet PoE+ Switch delivers reliable power and data in demanding environments. This Intellinet network switch powers up to eight PoE/PoE+ devices with a combined 240W budget—enough to support high-performance cameras, access controllers and wireless APs while eliminating the need for separate power wiring. The IP40-rated metal housing and extended -40 to 75°C operating range protect hardware in dusty, temperature-variable installations, ensuring continuous operation where downtime is not an option.
Two SFP ports enable fiber uplinks for long-distance connections and flexible network design, while DIN-rail mounting simplifies deployment in industrial racks and enclosures. IEEE 802.3at/af compatibility and gigabit auto-sensing ports deliver predictable throughput and plug-and-play integration with existing infrastructure. Ideal for security integrators, facility managers and systems designers, this switch balances power, endurance and expandability to support modern surveillance and monitoring networks. Choose the Intellinet 508261 to reduce installation cost, increase network resilience and accelerate deployment—order today or contact sales to specify for your next security or monitoring project.
Features
- Simplifies deployments by delivering data and up to 240W PoE power to eight devices, reducing cabling and installation time for security and surveillance systems.
- Rugged IP40 metal housing and wide -40 to 75°C operating range ensure reliable, continuous operation in harsh industrial and outdoor monitoring environments.
- Two SFP uplinks provide flexible fiber connectivity for long-distance links and network segmentation, future-proofing your infrastructure.
- DIN-rail mountable slim design saves cabinet space and enables quick installation and maintenance in control rooms and enclosures.
- Redundant DC inputs and industrial-grade components increase uptime and provide stable power to cameras, access control, and IoT devices critical to business operations.
| General Information | |
|---|---|
| Brand Name | Intellinet |
| Manufacturer Part Number | 508261 |
| Technical Information | |
| Material | Metal |
| Power Consumption | 255W |
| I/O Expansions | |
| Number of SFP+ Slots | 2 |
| Network & Communication | |
| Ethernet Technology | Ethernet, Fast Ethernet, Gigabit Ethernet |
| Networking Standards | IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at, IEEE 802.3i, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z |
| Physical Characteristics | |
| Width | 3.98" |
| Height | 1.38" |
| Power Description | |
| PoE Budget | 240W |
| Power Source | PoE |
| Input Voltage | 45-57V |
| Product Information | |
| Length | 7.48" |
| Warranty | |
| Limited Warranty | 3-Year |
| Miscellaneous | |
| Features | 10/100/1000 auto-sensing ports that automatically detect optimal network speeds, IEEE 802.3at/af-compliant RJ45 PoE/PoE+ output ports, IP40 slim-type metal housing to withstand harsh industrial conditions, Option for DIN-rail installation, Power output up to 30W per port, Provides power and data connections for up to eight PoE network devices, Saves installation costs by delivering data and power over existing network cables, Two redundant DC inputs (45 – 57 V) with I/O terminal block, Two small form-factor pluggable GBIC module slots (SFP) |
| Environmentally Friendly | Yes |
| Environmental Certification | CE, FCC |
