Hanwha ANE-L7012R 4MP Super-Compact Flateye Camera, 3mm Fixed Lens, IR 20m, WDR 120 dB, IP67, IK10, White
Image of 3
Key Features
- Super-compact design for discreet installation while delivering clear 4MP surveillance images
- Wide 3mm fixed lens and 98°+ field of view to cover larger areas with fewer cameras, reducing hardware costs
- True WDR (120 dB) and IR illumination up to 20m for reliable day/night monitoring in challenging lighting
- Rugged IP67 and IK10 ratings ensure dependable outdoor and high-risk area operation with minimal maintenance
- On-board analytics, PoE and microSD support enable intelligent edge monitoring, simplified installation, and local backup
Quick Specifications
- Brand Name
- Hanwha Vision
- Manufacturer
- Hanwha Group
- Product Name
- 4MP Super-Compact IR Flateye Camera
- Product Type
- Network Camera
Frequently Bought Together
Hanwha ANE-L7012R 4MP Super-Compact Flateye Camera, 3mm Fixed Lens, IR 20m, WDR 120 dB, IP67, IK10, White
$145.73
8 items selected
Total: $1,557.32
Product Information Tabs
Overview
Optimize site security with the Hanwha Vision ANE-L7012R super-compact turret (flateye) camera — designed for professional surveillance where space, image quality and reliability matter. This network camera delivers crisp 4MP resolution through a 3mm fixed lens and a wide field of view, letting you monitor larger zones with fewer units. Built-in WDR (120 dB) and IR illumination up to 20 meters keep critical details visible in high-contrast scenes and complete darkness, improving evidence capture and reducing false alarms. Robust IP67 weatherproofing and IK10 impact resistance mean long-term performance outdoors or in exposed installations. PoE simplifies wiring and deployment, while on-board analytics and microSD local storage enable intelligent edge monitoring and fast incident response. Ideal for retail, entrances, parking, transportation hubs and enterprise perimeter monitoring, the ANE-L7012R balances compact form with proven Hanwha Vision reliability. Contact sales to specify this turret camera for your next security or monitoring project and streamline installation and system integration.
Features
- Super-compact design for discreet installation while delivering clear 4MP surveillance images
- Wide 3mm fixed lens and 98°+ field of view to cover larger areas with fewer cameras, reducing hardware costs
- True WDR (120 dB) and IR illumination up to 20m for reliable day/night monitoring in challenging lighting
- Rugged IP67 and IK10 ratings ensure dependable outdoor and high-risk area operation with minimal maintenance
- On-board analytics, PoE and microSD support enable intelligent edge monitoring, simplified installation, and local backup
| General Information | |
|---|---|
| Brand Name | Hanwha Vision |
| Manufacturer | Hanwha Group |
| Product Name | 4MP Super-Compact IR Flateye Camera |
| Product Type | Network Camera |
| Product Model | ANE-L7012R |
| Manufacturer Part Number | ANE-L7012R |
| Technical Information | |
| Lens Type | Fixed |
| Night Vision | Yes |
| Field of View | Diagonal, Horizontal, Vertical |
| Video Formats | H.264, H.265, MJPEG |
| Maximum Aperture | f/1.6 |
| Night Vision Type | Infrared |
| Maximum Frame Rate | 30fps |
| Minimum Focal Length | 3mm |
| Connectivity Technology | Wired |
| Field of View (Vertical) | 54.2° |
| Field of View (Horizontal) | 98.3° |
| Effective Camera Resolution | 4MP |
| Camera | |
| Image Sensor Type | CMOS |
| Wide Dynamic Range | Yes |
| Night Vision Distance | 65.62 ft |
| Certifications | |
| Ingress Protection Rating | IP67 |
| Display & Graphics | |
| Maximum Video Resolution | 1600 x 1200 |
| Environmental Conditions | |
| Operating Humidity | 0.95 |
| Maximum Operating Temperature | 131°F (55°C) |
| Minimum Operating Temperature | -22°F (-30°C) |
| Exposure | |
| Longest Shutter Speed | 1/5 Second |
| Shortest Shutter Speed | 1/12000 Second |
| Interfaces/Ports | |
| Network (RJ-45) | Yes |
| Lens | |
| Focal Length | 3mm |
| Lens Included | Yes |
| Maximum Focal Length | 3mm |
| Network & Communication | |
| Remote Management | Yes |
| Physical Characteristics | |
| Color | White |
| Weight | 1.39 lb |
| Durability | Dustproof, Impact Resistant, Waterproof |
| Form Factor | Flateye |
| Product Information | |
| Diameter | 4.9" |
| Mount Type | Backbox Mount, Ceiling Mount, Conduit Mount, Flush Mount, Gang Box Mount, Pendant Mount, Wall Mount |
| Storage | |
| Storage Type | Memory Card |
| Video | |
| Maximum Resolution | 1280 x 720 |
| Miscellaneous | |
| Features | Automatic White Balance, Back Light Compensation (BLC), Built-in Mechanical ICR, Day/Night, Digital Noise Reduction, Gain Control, Motion Detection, Privacy Masking, SD Card Local Storage, Tamper Detection, Wide Dynamic Range |
| Impact Protection Rating | IK10 |
