Hikvision DS-2AE7232TI-A Pro Series TurboHD 2MP 7" Outdoor WDR Speed Dome PTZ Analog Camera, 4.8-153mm Lens, White

SKU: DS-2AE7232TI-A Hikvision
Hikvision Turbo HD DS-2AE7232TI-A 2 Megapixel Surveillance Camera - Dome - TAA Compliant
Product images for Hikvision DS-2AE7232TI-A Pro Series TurboHD 2MP 7" Outdoor WDR Speed Dome PTZ Analog Camera, 4.8-153mm Lens, White. 1 image(s) available. Click on image to view full size.

Key Features

  • Extend visible range and capture fine detail across large sites with 32× optical zoom (4.8–153mm) and up to 150 m (490 ft) IR for reliable long-range monitoring.
  • Maintain clear images in challenging lighting with 2MP Full HD resolution and 120 dB True WDR for accurate surveillance day or night.
  • Reduce patrol hours with 3D intelligent positioning and auto-tracking to follow targets and automate event response.
  • Integrate quickly into existing systems via multi‑protocol TurboHD analog outputs (TVI/AHD/CVI/CVBS) for flexible deployment.
  • Built for outdoor security: IP66 weatherproof housing and wide operating temperature range for durable 24/7 perimeter protection.

Quick Specifications

Brand Name
Hikvision
Manufacturer
Hikvision
Product Name
2 MP 32× Outdoor TurboHD PTZ Speed Dome
Product Type
Analog Camera
View Full Technical Specifications

Frequently Bought Together

This Item
Hikvision DS-2AE7232TI-A Pro Series TurboHD 2MP 7" Outdoor WDR Speed Dome PTZ Analog Camera, 4.8-153mm Lens, White

Hikvision DS-2AE7232TI-A Pro Series TurboHD 2MP 7" Outdoor WDR Speed Dome PTZ Analog Camera, 4.8-153mm Lens, White

$928.60

Frequently Bought Together (6 items)

7 items selected

Total: $2,351.15

Product Information Tabs

Overview

Designed for demanding outdoor security and perimeter monitoring, the Hikvision DS-2AE7232TI-A TurboHD 2MP PTZ Speed Dome delivers long-range, high-detail surveillance for critical infrastructure, campuses, and transportation hubs. This Hikvision PTZ security camera pairs Full HD (1920×1080) imaging with a powerful 32× optical zoom (4.8–153mm) and up to 150 m IR, so operators can identify license plates, faces or incidents across expansive areas without losing clarity. True 120 dB WDR handles backlit or high-contrast scenes, while 3D intelligent positioning and auto-tracking reduce manual intervention and speed incident response. Multi‑protocol analog outputs (TVI/AHD/CVI/CVBS) simplify upgrades to TurboHD systems, and an IP66-rated, weather-resistant enclosure ensures continuous monitoring in harsh outdoor environments. Ideal for commercial security, municipal surveillance, and industrial sites, this PTZ dome streamlines installation and maximizes situational awareness. Contact your sales representative to specify mounts and power options or add this Hikvision PTZ camera to your next surveillance deployment.

Features

  • Extend visible range and capture fine detail across large sites with 32× optical zoom (4.8–153mm) and up to 150 m (490 ft) IR for reliable long-range monitoring.
  • Maintain clear images in challenging lighting with 2MP Full HD resolution and 120 dB True WDR for accurate surveillance day or night.
  • Reduce patrol hours with 3D intelligent positioning and auto-tracking to follow targets and automate event response.
  • Integrate quickly into existing systems via multi‑protocol TurboHD analog outputs (TVI/AHD/CVI/CVBS) for flexible deployment.
  • Built for outdoor security: IP66 weatherproof housing and wide operating temperature range for durable 24/7 perimeter protection.
General Information
Brand Name Hikvision
Manufacturer Hikvision
Product Name 2 MP 32× Outdoor TurboHD PTZ Speed Dome
Product Type Analog Camera
Product Model DS-2AE7232TI-A
Product Series Turbo HD Cameras
Manufacturer Part Number DS-2AE7232TI-A
Technical Information
Lens Type Varifocal
Night Vision Yes
Field of View Horizontal
Maximum Aperture f/1.2
Night Vision Type Infrared
Maximum Frame Rate 30fps
Minimum Focal Length 4.8mm
Connectivity Technology Wired
Field of View (Horizontal) 54.2°
Effective Camera Resolution 2MP
Camera
Image Sensor Type CMOS
Wide Dynamic Range No
Night Vision Distance 492.13 ft
Certifications
TAA Compliant No
NDAA Compliant No
Ingress Protection Rating IP66
Display & Graphics
Maximum Video Resolution 1920 x 1080
Environmental Conditions
Operating Humidity 0.9
Maximum Operating Temperature 149°F (65°C)
Minimum Operating Temperature -22°F (-30°C)
Exposure
Longest Shutter Speed 1/1 Second
Shortest Shutter Speed 1/10000 Second
Lens
Focal Length 3.6mm
Lens Included Yes
Minimum Aperture f/4.4
Maximum Focal Length 153mm
Others
Model Number Replaces DS-2AE7230TI-A
Physical Characteristics
Color White
Height 13.9"
Weight 9.92lb
Durability Dust Resistant, Waterproof
Form Factor PTZ
Power Description
Input Voltage 24V AC
Product Information
Diameter 8.7"
Mount Type Ceiling Mount, Corner Mount, Pole Mount, Wall Mount
Storage
Recording Formats Full HD
Video
Maximum Resolution 2MP
Analog Video Signal Format AHD, CVBS, CVI, TVI
Miscellaneous
Features Auto Gain Control, Auto Tracking, Automatic White Balance, Back Light Compensation (BLC), Built-in HLC, Day/Night, Privacy Masking, Surge Protection
Indoor/Outdoor Outdoor
Country of Origin CN
