Hikvision DS-2DE3404W-DE Value Series 4MP WDR Mini PTZ Dome IP Camera, 2.8-12mm Lens, White

SKU: DS-2DE3404W-DE Hikvision

Special Order Item

This item is available by special order. Lead times may vary. Please contact us for availability and estimated delivery.

Hikvision DS-2DE3404W-DE Value Series 4MP WDR Mini PTZ Dome IP Camera, 2.8-12mm Lens
Product images for Hikvision DS-2DE3404W-DE Value Series 4MP WDR Mini PTZ Dome IP Camera, 2.8-12mm Lens, White. 1 image(s) available. Click on image to view full size.

Key Features

  • Deliver actionable, evidence-grade video with 4MP resolution for clearer identification and incident review
  • Pan/tilt control plus 4x optical zoom (2.8–12mm) to monitor large outdoor areas and zoom in on critical details
  • 120 dB WDR and 3D DNR for usable footage in high-contrast or low-light scenes, reducing false alarms and missed events
  • Built for outdoor resilience with IP66 weatherproofing and IK10 impact resistance for uninterrupted surveillance in harsh environments
  • Built-in motion detection, SD card local storage and remote management for faster response, flexible retention and easy network integration

Quick Specifications

Product Model
DS-2DE3404W-DE(T5)
Brand Name
Hikvision
Product Name
4 MP Network Mini PTZ Dome Camera
Product Type
Network Camera
View Full Technical Specifications

Product Information Tabs

Overview

Secure large outdoor perimeters with clear, actionable video from the Hikvision DS-2DE3404W-DE Mini PTZ Dome IP Camera. This compact Hikvision PTZ security camera delivers 4MP resolution and 120 dB wide dynamic range to produce sharp, usable footage even in high-contrast lighting—helping security teams identify people and incidents faster. The varifocal 2.8–12mm lens with 4x optical zoom and smooth pan/tilt control lets you cover wide areas and quickly focus on points of interest without losing image quality. Designed for real-world deployments, the unit features IP66 weatherproofing and IK10 impact resistance for reliable outdoor performance, plus H.265 compression and SD card support to optimize storage and bandwidth. Integrated motion detection, HTTPS and password protection simplify monitoring and remote management, making it easy to integrate into existing NVRs and network video systems. Ideal for parking lots, retail perimeters, campuses and industrial sites, the DS-2DE3404W-DE provides dependable surveillance for operational security needs. Contact us to add this mini PTZ dome camera to your security system or request a quote.

Features

  • Deliver actionable, evidence-grade video with 4MP resolution for clearer identification and incident review
  • Pan/tilt control plus 4x optical zoom (2.8–12mm) to monitor large outdoor areas and zoom in on critical details
  • 120 dB WDR and 3D DNR for usable footage in high-contrast or low-light scenes, reducing false alarms and missed events
  • Built for outdoor resilience with IP66 weatherproofing and IK10 impact resistance for uninterrupted surveillance in harsh environments
  • Built-in motion detection, SD card local storage and remote management for faster response, flexible retention and easy network integration
General Information
Brand Name Hikvision
Manufacturer Hikvision
Product Name 4 MP Network Mini PTZ Dome Camera
Product Type Network Camera
Product Model DS-2DE3404W-DE(T5)
Product Series DeepInView
Manufacturer Part Number DS-2DE3404W-DE
Technical Information
Lens Type Varifocal
Field of View Diagonal, Horizontal, Vertical
Video Formats H.264, H.265, MJPEG
Maximum Aperture f/1.5
Maximum Frame Rate 30fps
Minimum Focal Length 2.8mm
Connectivity Technology Wired
Field of View (Vertical) 50.9°
Field of View (Horizontal) 93.8°
Effective Camera Resolution 4MP
Camera
Image Sensor Type CMOS
Wide Dynamic Range Yes
Certifications
TAA Compliant No
NDAA Compliant No
Ingress Protection Rating IP66
Display & Graphics
Maximum Video Resolution 2560 x 1440
Environmental Conditions
Operating Humidity 0.9
Maximum Operating Temperature 149°F (65°C)
Minimum Operating Temperature -22°F (-30°C)
Exposure
Longest Shutter Speed 1/1 Second
Shortest Shutter Speed 1/30000 Second
Interfaces/Ports
Network (RJ-45) Yes
Lens
Focal Length 2.8-12mm
Lens Included Yes
Maximum Focal Length 12mm
Network & Communication
Remote Management Yes
Physical Characteristics
Color White
Weight 2.09lb
Durability Dust Resistant, Impact Resistant, Vandal Resistant, Waterproof
Form Factor PTZ
Power Description
Input Voltage 12V DC
Product Information
Diameter 5.5"
Mount Type Ceiling Mount, Corner Mount, Pole Mount, Wall Mount
Storage
Storage Type Memory Card
Video
Maximum Resolution 4MP
Miscellaneous
Features 3D Digital Noise Reduction, Back Light Compensation (BLC), Cross Line Detection, Day/Night, Highlight Compensation (HLC), HTTPS Encryption, Motion Detection, Password Protection, SD Card Local Storage, Wide Dynamic Range
Indoor/Outdoor Outdoor
Country of Origin CN
Environmentally Friendly Yes
Impact Protection Rating IK10
Environmental Certification REACH, RoHS, WEEE
