Hikvision DS-7308HUHI-F4/N-18TB 8-Channel Turbo HD DVR, HD TVI/HD-AHD/SD-DEF, 18TB
Special Order Item
This item is available by special order. Lead times may vary. Please contact us for availability and estimated delivery.
Key Features
- Centralized, reliable recording for multi-camera systems — 8 channels supported to cover entrances, floors, and perimeter areas
- Long-term storage and fast retrieval with 18TB internal HDD for extended retention and evidence preservation
- Efficient H.265 compression reduces bandwidth and storage costs while preserving detail at up to 2048 x 1536 resolution
- Hybrid Turbo HD compatibility (HD-TVI/HD-AHD/SD-DEF) for seamless integration with existing analog/CCTV infrastructure
- Remote monitoring and management via Ethernet with HDMI/VGA outputs for local display and on-site review
Quick Specifications
- Product Model
- DS-7308HUHI-F4/N
- Brand Name
- Hikvision
- Product Line
- Turbo HD
- Product Name
- Turbo HD DVR
Product Information Tabs
Overview
Designed for small-to-mid sized sites that need dependable, high-quality recording and remote access, the Hikvision DS-7308HUHI-F4/N Turbo HD DVR delivers practical surveillance performance for security teams and integrators. This 8-channel DVR records up to 2048 x 1536 resolution at 30fps and uses H.265 compression to maximize footage retention without sacrificing image clarity. With 18TB of built-in storage, you get extended retention windows for incident investigation and regulatory compliance, reducing the need for frequent offload.
The DS-7308HUHI-F4/N supports HD-TVI, HD-AHD and SD-DEF signals, allowing easy migration from legacy analog systems while offering HDMI and VGA outputs for local monitoring. Networked remote management and Ethernet connectivity give operators real-time viewing, playback and event management from a central console or mobile device. Ideal for retail, office, healthcare or warehouse deployments, this Hikvision video surveillance DVR streamlines monitoring workflows and preserves critical evidence. Contact your reseller to specify this DVR for your next CCTV installation or request a demo.
Features
- Centralized, reliable recording for multi-camera systems — 8 channels supported to cover entrances, floors, and perimeter areas
- Long-term storage and fast retrieval with 18TB internal HDD for extended retention and evidence preservation
- Efficient H.265 compression reduces bandwidth and storage costs while preserving detail at up to 2048 x 1536 resolution
- Hybrid Turbo HD compatibility (HD-TVI/HD-AHD/SD-DEF) for seamless integration with existing analog/CCTV infrastructure
- Remote monitoring and management via Ethernet with HDMI/VGA outputs for local display and on-site review
| General Information | |
|---|---|
| Brand Name | Hikvision |
| Manufacturer | Hikvision |
| Product Line | Turbo HD |
| Product Name | Turbo HD DVR |
| Product Type | Video Surveillance Station |
| Product Model | DS-7308HUHI-F4/N |
| Product Series | DS-73xxHUHI-F4/N |
| Manufacturer Part Number | DS-7308HUHI-F4/N-18TB |
| Technical Information | |
| Video Formats | H.264, H.265 |
| Storage Capacity | 18TB |
| Maximum Frame Rate | 30fps |
| Number of Channels | 8 |
| Video Signal Format | NTSC, PAL |
| Connectivity Technology | Wired |
| Certifications | |
| NDAA Compliant | No |
| Interfaces/Ports | |
| HDMI | Yes |
| Composite Video In | Yes |
| Composite Video Out | Yes |
| Number of VGA Outputs | 1 |
| Network & Communication | |
| Ethernet | Yes |
| Remote Management | Yes |
| Physical Characteristics | |
| Depth | 15" |
| Width | 18" |
| Storage | |
| Optical Drive Type | DVD-Writer |
| Video | |
| Maximum Resolution | 2048 x 1536 |
| Miscellaneous | |
| Country of Origin | CN |
