Digital Watchdog DW-BJRR2Y260T Blackjack Rack 2U 26-Bay Server with 32GB Dual Processor, RAID 5, 260TB
Special Order Item
This item is available by special order. Lead times may vary. Please contact us for availability and estimated delivery.
Key Features
- Enterprise-grade continuous recording: supports hundreds of IP cameras with up to 600 Mbps throughput for reliable 24/7 surveillance
- High-capacity, fault-tolerant storage: 26 hot-swappable bays with 260TB raw capacity and RAID5 protects recordings from drive failure
- Performance and scalability: dual Intel Xeon processors and 32GB RAM power analytics, multi-stream recording and future expansion with 1GbE/10GbE
- Preloaded VMS and licenses: ships with DW Spectrum IPVMS and eight recording licenses to speed deployment and reduce setup time
- Redundancy and compliance: mirrored 2x240GB SSD OS, dual power supplies, UL listed and NDAA/ONVIF certified for secure, mission-critical installations
Quick Specifications
- Product Model
- DW-BJRR2Y260T
- Brand Name
- Digital Watchdog
- Product Line
- Blackjack
- Product Series
- Rack Y
Frequently Bought Together
Digital Watchdog DW-BJRR2Y260T Blackjack Rack 2U 26-Bay Server with 32GB Dual Processor, RAID 5, 260TB
$55,537.30
10 items selected
Total: $65,177.38
Product Information Tabs
Overview
Built for continuous, enterprise-class video recording and centralized security monitoring, the Digital Watchdog DW-BJRR2Y260T Blackjack Rack 2U 26-Bay Server delivers the capacity and reliability modern surveillance projects demand. Dual Intel Xeon processors and 32GB of RAM handle heavy multi-camera loads and up to 600 Mbps throughput, while 26 hot-swappable drives provide 260TB of raw storage configured with RAID5 for fault-tolerant retention. The system boots from mirrored 2x240GB SSDs (Windows 10 IoT, Windows Server 2019 or Linux Ubuntu), separating the OS from recorded footage for added resilience.
Preloaded with DW Spectrum IPVMS and eight recording licenses, this rack server reduces setup time and simplifies large-scale deployments. With redundant power supplies, 1GbE/10GbE networking options, UL listing and NDAA/ONVIF compliance, the Blackjack Rack is optimized for mission-critical security, retail, campus and municipal surveillance applications. Deploy it as a high-density NVR/server for centralized monitoring, long-term evidence retention, and scalable video analytics. Contact your reseller or add to cart to upgrade your security infrastructure today.
Features
- Enterprise-grade continuous recording: supports hundreds of IP cameras with up to 600 Mbps throughput for reliable 24/7 surveillance
- High-capacity, fault-tolerant storage: 26 hot-swappable bays with 260TB raw capacity and RAID5 protects recordings from drive failure
- Performance and scalability: dual Intel Xeon processors and 32GB RAM power analytics, multi-stream recording and future expansion with 1GbE/10GbE
- Preloaded VMS and licenses: ships with DW Spectrum IPVMS and eight recording licenses to speed deployment and reduce setup time
- Redundancy and compliance: mirrored 2x240GB SSD OS, dual power supplies, UL listed and NDAA/ONVIF certified for secure, mission-critical installations
| General Information | |
|---|---|
| Brand Name | Digital Watchdog |
| Product Line | Blackjack |
| Product Model | DW-BJRR2Y260T |
| Product Series | Rack Y |
| Manufacturer Part Number | DW-BJRR2Y260T |
| Technical Information | |
| Storage Capacity | 2x 240GB SSD (RAID1 mirrored) |
| Controllers | |
| RAID Levels | RAID 5 |
| Environmental Conditions | |
| Operating Humidity | 20-90% RH |
| Operating Temperature (T-T) | 41-104°F |
| Interfaces/Ports | |
| Number of USB Ports | 1 |
| Network & Communication | |
| Ethernet Technology | 1 Gigabit Ethernet, 10 Gigabit SFP+ Fiber |
| Others | |
| Model Number Replaces | DW-BJRR2X224T, DW-BJRR2X260T |
| Physical Characteristics | |
| Weight | 88.2 lb |
| Dimensions | 3.41" x 17.6" x 31.9" |
| Storage | |
| Hard Drive Capacity | 260TB |
| Number of Hard Drives Supported | 26 |
| Miscellaneous | |
| Certifications | CE, FCC, NDAA, ONVIF, TAA, UL Listed |
| Package Contents | Keyboard, Mouse |
| Operating System Compatibility | Windows |
