Digital Watchdog DWC-MPH2W28TW MEGApix IVA 2.1MP Mini Pinhole IP Camera, 2.8 mm Fixed Lens, White

SKU: DWC-MPH2W28TW Digital Watchdog

Special Order Item

This item is available by special order. Lead times may vary. Please contact us for availability and estimated delivery.

Digital Watchdog DWC-MPH2W28TW MEGApix IVA 2.1MP Mini Pinhole IP Camera, 2.8mm Fixed Lens
Product images for Digital Watchdog DWC-MPH2W28TW MEGApix IVA 2.1MP Mini Pinhole IP Camera, 2.8 mm Fixed Lens, White. 4 image(s) available. Click on image to view full size.
NDAA Compliant

Key Features

  • Discreet, tamper-resistant pinhole design for covert ATM and retail surveillance
  • Built-in IVA analytics and Smart DNR reduce false alarms and improve evidence quality
  • True WDR and 2.1MP/1080p resolution deliver clear images in challenging lighting and glare
  • NDAA-compliant and ONVIF-conformant for secure, standards-based deployments
  • H.265/H.264 triple-codec streaming and smart recording optimize bandwidth and storage

Quick Specifications

Product Model
DWC-MPH2W28TW
Brand Name
Digital Watchdog
Product Line
MEGApix
Product Series
MPH2
View Full Technical Specifications

Frequently Bought Together

Product Information Tabs

Overview

Protect high-risk points like ATMs, teller windows and retail counters with a compact, professional-grade covert camera designed for reliable close-range monitoring. The Digital Watchdog MEGApix DWC-MPH2W28TW mini pinhole IP camera delivers 2.1MP (1080p) resolution at 30fps and a 2.8mm fixed lens to capture sharp facial and transaction detail without drawing attention. Integrated IVA (Intelligent Video Analytics) reduces false alarms and pairs seamlessly with DW Spectrum IPVMS, enabling rule-based recording and efficient event management.

Built for demanding security environments, the camera offers True Wide Dynamic Range (WDR) for balanced exposure in mixed lighting, Smart DNR for cleaner low-light images, and NDAA compliance for procurement-ready installations. Support for H.265/H.264 and ONVIF profile S ensures flexible network integration and lower storage costs, while a rugged aluminum die-cast housing resists tampering. Whether you’re upgrading ATM monitoring, covert retail loss-prevention, or branch security, this MEGApix pinhole camera delivers discreet, high-quality surveillance. Add the DWC-MPH2W28TW to your security strategy or contact us for integration and deployment guidance.

Features

  • Discreet, tamper-resistant pinhole design for covert ATM and retail surveillance
  • Built-in IVA analytics and Smart DNR reduce false alarms and improve evidence quality
  • True WDR and 2.1MP/1080p resolution deliver clear images in challenging lighting and glare
  • NDAA-compliant and ONVIF-conformant for secure, standards-based deployments
  • H.265/H.264 triple-codec streaming and smart recording optimize bandwidth and storage
General Information
Brand Name Digital Watchdog
Product Line MEGApix
Product Model DWC-MPH2W28TW
Product Series MPH2
Manufacturer Part Number DWC-MPH2W28TW
Supported Network Protocols IPv4
Technical Information
Material Aluminum Die-cast, Plastic
Lens Type Fixed
Protocols DDNS, DHCP, DNS, FTP, HTTP, HTTPs, ICMP, NTP, RTP (UDP/TCP), RTSP, SMTP, SNMPv1/v2/v3 (MIB-2), SSL, TCP/IP, UDP, Zeroconf (AutoIP)
Programmable Yes
Field of View Horizontal, Vertical
Video Formats H.264, MJPEG
Output Voltage 12V DC
Motion Detection Yes
Maximum Frame Rate 30fps
American Wire Gauge 18AWG
Effective Camera Resolution 2MP
Audio
Memory Card Slot Yes
Camera
Image Sensor Type CMOS
Wide Dynamic Range Yes
Certifications
NDAA Compliant Yes
Display & Graphics
Image Sensor Size 1/2.8"
Environmental Conditions
Operating Humidity 10-90% (Non-condensing)
Operating Temperature (T-T) -4-122°F
Exposure
Minimum Illumination 0.065 lux (color)
Shortest Shutter Speed Off, x10, x2, x3, x5, x6, x7.5
Lens
Focus Modes Auto, Manual
Focal Length 2.8mm
Media & Performance
Network Technology 10 Base-T Ethernet, 100 Base-T Ethernet
Physical Characteristics
Color White
Weight 0.92 lb
Form Factor Pinhole
TBD
Amperage 300mA
Warranty
Limited Warranty 5-Year
Miscellaneous
Certifications CE, FCC, NDAA, UL Listing
Country of Origin KR
